Cold Extraction Infusing Brewer

Table of Contents

Specifications and requirements ....................................... 2
Weights and Capacities .................................................... 2
Positioning and Installation ............................................... 3
Touch display .................................................................... 8
After Production ................................................................ 9
Sanitation .......................................................................... 9
Sanitizing Solution ............................................................. 9
Programing Menu Layout ................................................ 10
PROGRAM ...................................................................... 11
User's Guide and Operator Instructions
Baby Hardtank
fe tc o .c o m
Internet: www.fetco.com
Phone: (800) 338-2699 (US & Canada)
(847) 719-3000
Fax: (847) 719-3001
Email: sales@fetco.com
techsupport@fetco.com
WASH 11
SANITATION ................................................................... 11
CALIBRATION ................................................................. 14
Hard Tank table of authorities ......................................... 16
Parts Diagrams ................................................................ 16
Baby Hard Tank electrical assembly ............................... 15
Wiring Diagram ................................................................ 18
P232
March 2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Baby Hardtank IHT-2205 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fetco Baby Hardtank IHT-2205

  • Page 1: Table Of Contents

    User’s Guide and Operator Instructions www.fetco.com Baby Hardtank Cold Beverage Infusion Brewer FETCO Commercial Beverage Equipment Contact Information Internet: www.fetco.com FETCO® Phone: (800) 338-2699 (US & Canada) Food Equipment Technologies Company (847) 719-3000 600 Rose Road Fax: (847) 719-3001 fe tc o .c o m Lake Zurich •...
