CBS-1251; CBS-1252 and CBS-1253 Extractor Plus Brewing System
CBS-1251 & CBS-1252 1½ gallon brewer with FETCO 1½ Gallon L4D dispensers (sold separately) CBS-2153 2 gallon Extractor Plus Brewers
CONTACT INFORMATION
FETCO® FOOD EQUIPMENT TECHNOLOGIES COMPANY
600 ROSE ROAD
LAKE ZURICH • IL • 60047-0429 • USA
ON THE WEB: fetco.cofee
©2020-2021 FETCO
PATENTS:https://www.fetco.com/pl,pages,patents,74.html
Coffee Brewer: CBS-1250 series
TABLE OF CONTENTS
Specifications and Requirements .................................. 2
Electrical Configurations ................................................ 3
Enter Programming ........................................................ 5
Programing Menu Layout ............................................... 5
Starting The Brew .......................................................... 6
A Program ...................................................................... 7
B General ....................................................................... 8
C Service Inputs ............................................................. 9
D Service Outputs .......................................................... 9
E Calibration ................................................................. 10
F Service Menu ............................................................ 10
User's Guide and Operator Instructions
FETCO PLUS
Commercial Beverage Equipment
®
fetco.com
PHONE: (800) 338-2699 (US & CANADA)
(847) 719-3000 (All Countries)
FAX: (847) 719-3001
EMAIL:sales@fetco.com
orders@fetco.com (to order parts and equipment)
techsupport@fetco.com (all service queries)
P213
REV. 000
F Error Codes .............................................................. 11
G Counters ................................................................... 12
H Save & Exit ............................................................... 13
Operator Training ......................................................... 14
Parts Diagram CBS-1251 ............................................ 18
Parts Diagrams CBS-1252 and CBS-1253 .................. 20
CBS-1251 Tank Assembly ........................................... 22
CBS-1252 and CBS1253 Tank Assembly ................... 24
Quick connect spray head assembly ........................... 26
Wiring Diagrams .......................................................... 27
November 2021
Advertisement
Table of Contents
Related Manuals for Fetco Extractor Plus CBS-1251
Summary of Contents for Fetco Extractor Plus CBS-1251
-
Page 1: Table Of Contents
CBS-1251; CBS-1252 and CBS-1253 Extractor Plus Brewing System FETCO PLUS Commercial Beverage Equipment ® CBS-1251 & CBS-1252 1½ gallon brewer with FETCO 1½ Gallon L4D dispensers (sold separately) CBS-2153 2 gallon Extractor Plus Brewers PHONE: (800) 338-2699 (US & CANADA) CONTACT INFORMATION (847) 719-3000 (All Countries) FETCO®... -
Page 2: Specifications And Requirements
Rough-In Drawings 1201.00053.00 (CBS-1251) 1201.00052.00 (CBS-2152) [Numbers in parenthesis are centimeters] CBS-1251 Front CBS-1252 Front CBS-1253 Front Side (all) Back (all) Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 2... -
Page 3: Electrical Configurations
11.3-15.0 31.8-36.6 30.0 gal/114 liters Sold as 3 phase CBS-1253PLUS Twin 2 Gallon-8 Liter Coffee Brewers continued on following page Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 3... - Page 4 3=NEMA 6-15P 4=NEMA 6-30P X=120 or 240 5= CEE 7/7 dual side Dual Voltage Schuko 2 gallon 6=UK1-13P 7= AUSTRALIAN Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 4...
-
Page 5: Enter Programming
Override Rt BBL Copy Batch: From PASTE: To Top and middle batches are permanent SEE BOX on the following page for all “A” menus Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021... -
Page 6: Starting The Brew
#1 to enter any changes as EXIT in previous position brewer has progamming for A1 required table one row of buttons Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 6... -
Page 7: A Program
Copy To Batch? A91.1 (1-6) PULSE BREW note. FETCO CBS-1200V+ brewers are factory programmed to pulse 2 cycles per minute brew time Changing the brew time only will increase the pulses but will not change the volume of brew water delivered Go to fetco.com for the latest versions of all information... -
Page 8: B General
(Not recommended) Unit will operate at lower temperature Allows brewing at any temperature above 77°C/170°F Below 70°C/170°F The brewer will display “HEATING” Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021... -
Page 9: C Service Inputs
LEDs under buttons Adjust LED button LED Brightness Brightness=60% 20-100% brightness only-Not for the screen display LCD Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 9... -
Page 10: E Calibration
Override Lt BBL NO/YES YES or NO lock Toggle +/- Disables brew basket Override Rt BBL NO/YES YES or NO lock Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 10... -
Page 11: F Error Codes
Brew basket must be in place BSKT Insert brew basket into brewer rails to This is a enable brewer SAFETY FEATURE Insert Brew Basket Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 11... -
Page 12: G Counters
Batch 60 Cycles [LT] Menu button selection Total brews-right side bottom button Count and activation count CBS-1251&CBS-1252 Batch 60 Cycles Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 12... -
Page 13: H Save & Exit
3) When setting brewer model The software sets equipment to brewer defaults 4) When loading from USB (Reprograms settings) (SETTING F9) 5) When restoring defaults (Reloads to defaults ) (SETTING E10) Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 13... -
Page 14: Operator Training
5. Do not attempt to move hot beverage equipment once it is filled. Drain equipment before moving. 6. FETCO commercial coffee brewers prepare large amounts of coffee or tea in a single batch using very hot water 7. Commercial coffee brewers provide very hot water from the spray head, brew basket and faucet when it is pulled. - Page 15 4. Brewers in this series wire differently in regard to a neutral wire. Review the wire diagrams. 5. The electrical diagram is located in the User’s Guide and online at www.fetco.com. 6. Make sure of the tight grounding of the equipment and use the external ground bolt.
- Page 16 Do not operate if unit has been submerged or saturated with water. Labels and warnings for hot beverage equipment For BACK PANEL of equipment (1046.00035.00) Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 16...
- Page 17 1102.00065.00 ASY, RED handle Optional HANDLE W/MAGNET colored 1102.00066.00 ASY, GREEN handle Optional HANDLE W/MAGNET colored 1102.00067.00 ASY, ORANGE handle Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 17...
-
Page 18: Parts Diagram Cbs-1251
Parts Diagram CBS-1251 Drawing 1101.00572.00 Parts CBS-1251 #6 Part Number1102.00471.00 ELECTRICAL COMPONENT LATTICE Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 18... - Page 19 LOCKNUT, SKINTOP, 3/4" NPT, BLACK HEX 1044.00013.00 LABEL EQUIPOTENTIALITY, CE 1052.00027.00 EMI FILTER, THREE LINE 30A, 250/440VAC 1084.00012.00 NUT, HEX, #6-32 MACHINE SCREW Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 19...
-
Page 20: Parts Diagrams Cbs-1252 And Cbs-1253
Parts Diagrams CBS-1252 and CBS-1253 Parts lists for CBS-1252 1-1/2 gallon Drawing 1101.00573.00 CBS-1252 2 gallon Drawing 1101.00592.00 #6 Part Number1102.00471.00 ELECTRICAL COMPONENT LATTICE Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 20... - Page 21 LOCKNUT, SKINTOP, 3/4" NPT, BLACK HEX 1044.00013.00 LABEL EQUIPOTENTIALITY, CE 1052.00050.00 EMI FILTER, 25A, 250/440VAC, 50/60Hz 1084.00012.00 NUT, HEX, #6-32 MACHINE SCREW Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 21...
-
Page 22: Cbs-1251 Tank Assembly
GROMMET, SILICONE, BLANK 1022.00068.00 INSULATION, TANK FRONT, CBS-2151 1022.00069.00 INSULATION, TANK BACK, CBS-2151 1082.00136.00 BRASS SCREW, #8-32 X 1/4", PHILLIPS PAN HEAD Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 22... - Page 23 LABEL, DANGER, HIGH VOLTAGE 1022.00068.00 INSULATION, TANK FRONT, CBS-2151 1022.00069.00 INSULATION, TANK BACK, CBS-2151 1082.00136.00 BRASS SCREW, #8-32 X 1/4", PHILLIPS PAN HEAD Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 23...
-
Page 24: Cbs-1252 And Cbs1253 Tank Assembly
LABEL, DANGER, HIGH VOLTAGE 1022.00070.00 INSULATION, TANK FRONT, CBS-2152 1022.00071.00 INSULATION, TANK BACK, CBS-2152 1082.00136.00 BRASS SCREW, #8-32 X 1/4", PHILLIPS PAN HEAD Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 24... - Page 25 LABEL, DANGER, HIGH VOLTAGE 1022.00070.00 INSULATION, TANK FRONT, CBS-2152 1022.00071.00 INSULATION, TANK BACK, CBS-2152 1082.00136.00 BRASS SCREW, #8-32 X 1/4", PHILLIPS PAN HEAD Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 25...
-
Page 26: Quick Connect Spray Head Assembly
O-RING, 13/16"OD X 11/16"ID X 1/16" TH, FOR QUICK CONNECT 1024.00098.00 VENT TUBE, CBS- EXTRACTOR SERIES 1023.00344.00 PLUG INSERT, QUICK CONNECT Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 26... -
Page 27: Wiring Diagrams
Wiring Diagrams CBS-1251 PLUS Wiring diagram 1401.00196.10 SKU: E1251US-1B230-PM110; heaters 2 X 3.0 kW SKU: E1251IN-1B230-PM110; heaters 2 X 3.0 kW Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 27... - Page 28 CBS-1251 Plus Wiring Diagram 1401.00197.10 SKU E1251IN-1B140-PM110; heaters 1 X 4.0 kW SKU E1251IN-1B150-PM110 ; heaters 1 X 5.0 kW Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 28...
- Page 29 SKU E1253US-UB230-PM110 Heaters 2 X 3.0 kW single phase; 3 X 3.0 kW three phase SKU E1253US-UB250-PM110 Heaters 2 X 5.0 kW single phase; 3 X 5.0 kW three phase Go to fetco.com for the latest versions of all information User Guide & Operator instructions...
- Page 30 CBS-1252 Plus Wiring Diagram 1401.00199.10 SKU E1252IN-1B230-PM110; heaters 2 X 3.0 kW SKU E1252IN-1B250-PM110, heaters 2 X 5.0 kW Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 30...
- Page 31 SKU E1252IN-3B340-PM110; heaters 3 X 4.0 kW 220/380 or 240/415 SKU E1252IN-3B350-PM110; heaters 3 X 5.0 kW 220/380 or 240/415 Go to fetco.com for the latest versions of all information User Guide & Operator instructions P213e0 NOVEMBER 2021 Page 31...
- Page 32 End of section notes...
