USER MANUAL Table of Contents Safety Information What’s Included Specifications Main Power Connection DMX Connection Output Connection Display Settings DMX Profile Size And Weight Parts Cleaning Installation Warranty Customer Service... -
Page 2: Safety Information
12mm can’t enter . And there is NO protection against water from entering the fixture.. What is Included 1pc Tetra Driver 16 fixture 1pc Seetronics SAC3FCA Connection to Nema 5-15 Connection Cable... -
Page 3: Specifications
Specifications Part Numbers Fixture 5072 - Tetra Driver 16 Mechanical Specifications Housing: Aluminum Display: Digital IP Rating: IP20 Fastening System: Rack Mount, Removable Clamp Mounts, Rear Rail Removable Mounts DMX Connection: 5 Pin XLR In and Out & rj45 In and Out... -
Page 4: Main Power Connection
Mega Lite dealer item #P-DMX-T. 12V Sensor By-Pass Once the Tetra Driver 16 receives a DC 12V input signal all dimmer channels will go to a full position and by pass DMX Control. Once 12V signal is removed the DMX Control will reengaged. -
Page 5: Output Connection
Position 5 Voltage + Black Max Power Link Configuration Each Tetra Driver 16 Port can connect up to 60W of power. Do not connect more than 60W or their will be voltage drop or driver failure (example) Item Number Size... -
Page 6: Display Settings
Mega Lite Menu Enter Tetra 16 Down Display Lock: The display for the Tetra Driver 16 factory setting is lock screen function to unlock the display press and hold the Menu & Enter buttons for 3 seconds DMX Mode Port... - Page 7 Prog 01 Prog 01 Dimmer System Mode Auto: Auto mode allows you to (ST Color 1) (000) (Auto) access the pre-built auto functions for “ ” the control. Press Enter use the Up / Down buttons to select the pre program Prog 18 Prog 18 Dimmer fixture look.
-
Page 8: Dmx Profile
DMX Profile Tetra Driver 16 1 Ch Mode DMX Ch Function Description Value Init Dimmer LED Intensity 0-255 Tetra Driver 16 2 Ch Mode Init DMX Ch Function Description Value LED Color Warm White LED Intensity 0-255 LED Color Cool White LED Intensity... - Page 9 Tetra Driver 16 64 Channel (4Ch X 16) DMX Chanel Function Description Value Init LED Color Red LED Intensity (Port 1) 0-255 LED Color Green LED Intensity (Port 1) 0-255 LED Color Blue LED Intensity (Port 1) 0-255 LED Color...
-
Page 10: Size And Weight
Size and Weight 3.5” 10.5” 19” Fixture Size: 19” X 10.5” X 3.5” Fixture Weight: 12lb Packaged Size: 21.3” X 13” X 5.5” Packaged Weight: 16.5lb Parts & Accessories 5072-PCB-MAI-DIS DISPLAY AND MAIN PCB 5072-PCB-DRI LED DRIVER PCB 5060-PCB-DMX-3 RJ45 & 3PIN XLR CONNECTION PCB 5060-PCB-DMX-5 RJ45 &... -
Page 11: Cleaning
Wall Attachment Use included Eye Bolt for a secondary safety attachment when Tetra Driver 16 is rigged Cleaning and Maintenance Installation Maintenance- The operator has to make sure that the unit is operating safely and has the installa- tions and electronics checked by an expert every year. -
Page 13: Customer Service
Customer Support MEGA Lite has a customer support line to provide set-up help and to answer any questions should you encounter a problem. Please visit our website for any other related technical documents. For service related issues, please contact our service dept. Monday - Friday 9am to 6pm CST (210) 684-2600 service@mega.lighting...
