INSTRUCTION MANUAL
Easy Preparation Finger Chuck for Automotive Wheels
・ This instruction manual is for production engineers and maintenance
personnel in charge of operation of this product. When a beginner uses
this product, receive instructions from experienced personnel, the
distributor or our company.
・ Before installing, operating or maintaining this equipment, carefully
read this manual and the safety labels attached to the equipment.
Failure to follow these instructions and safety precautions could result
in serious injury, death, or property damage.
・ Store this manual near equipment for future reference.
・ If any questions related to safety arise about this manual, please
confirm them with the distributor or our company.
77-1,Motomachi,Fuchu -shi,Hiroshima,726-8610 Japan
FG-Q
DANGER
Kitagawa Corporation
TEL +81-(0)847 -40-0561
FAX +81-(0)847-45-8911
Version 1.08 (2024.05.02)
type
Advertisement
Table of Contents
Related Manuals for Kitagawa FG-Q Series
Summary of Contents for Kitagawa FG-Q Series
- Page 1 ・ Store this manual near equipment for future reference. ・ If any questions related to safety arise about this manual, please confirm them with the distributor or our company. Kitagawa Corporation 77-1,Motomachi,Fuchu -shi,Hiroshima,726-8610 Japan TEL +81-(0)847 -40-0561 FAX +81-(0)847-45-8911...
- Page 2 Preface This manual provides detailed information about how to safely and correctly use the finger chuck for machining automotive wheels (FG-Q type) using lathe. Before starting to use this finger chuck for automotive wheels, read this manual carefully and always follow the instructions and warnings in "Important Safety Precautions" and "Precautions for Use"...
- Page 3 The chuck and cylinder from Kitagawa Corporation should be used together. If you must use a part not made by Kitagawa, check with us or our distributor to be sure it is safe to do so. We will not be responsible for injury, death, damage or loss caused by use of a chuck or cylinder made by another company unless this use has been approved by Kitagawa or its distributor.
-
Page 4: Table Of Contents
Table of Contents 1. Structural Drawing and Parts List -----------------------------------------------------------------------4 1-1. Type display 1-2. Structural drawing 1-3. Scope of product 1-4. Parts list Important Safety Precautions ------------------------------------------------------------9 3. Specifications ----------------------------------------------------------------------------------------------14 3-1. Specifications table 4. Top tooling --------------------------------------------------------------------------------------------------15 4-1. Changing the lever position setup 4-2. -
Page 5: Structural Drawing And Parts List
1. Structural Drawing and Parts List 1-1. Type display Type display as shown below Fig.1... -
Page 6: Structural Drawing
1-2. Structural drawing Fig.2... -
Page 7: Scope Of Product
1-3. Scope of product This instruction manual is for the chuck part. Fig.3 ・ To prevent the work from flying, safe design, maintenance and erroneous action prevention of the hydraulic system to maintain the gripping force of the chuck is extremely important. Thoroughly read the “Important Safety Precautions”... -
Page 8: Parts List
1-4. Parts list Fig.4... - Page 9 Table 1 Parts list Part name Quantity No. Part name Quantity A Body 09 Set screw B Rear body 10 Set screw C Diaphragm plate 11 Set screw D Plunger 12 Set screw E Plunger nut 13 Set screw F Bushing 14 Retaining ring G Pin 15 O-ring P 6...
-
Page 10: Important Safety Precautions
Important Safety Precautions Important safety precautions are summarized below. Please read this section before first starting to use this product. Failure to follow the safety precautions below will result in DANGER serious injury or death. Turn off main power supply before attaching, inspecting or replacing chuck, and before adding oil. - Page 11 Important Safety Precautions Failure to follow the safety precautions below will result in DANGER serious injury or death. Do not allow the rotation speed of the chuck to exceed the maximum allowable speed limit. (Refer to the Spec. information for For All Users supply and Page 14) ・...
- Page 12 Important Safety Precautions Failure to follow the safety precautions below will result in DANGER serious injury or death. Always tighten the bolts at the specified torque. If the torque is insufficient or excessive, the bolt will break, which is dangerous as the chuck or work will fly out.
- Page 13 Important Safety Precautions Failure to follow the safety precautions below will result in DANGER serious injury or death. Provide sufficient strength for the draw pipe. Provide sufficient screw depth for the draw pipe. Firmly tighten the draw pipe. For Machine Tool Manufactures ・...
- Page 14 ・ Not only the chuck is damaged but also the chuck and workpiece may fly out. ・ Do not install parts other than genuine parts made by Kitagawa by adding the tapping. ・ Do not remove chuck parts from the chuck.
-
Page 15: Specifications Table
3. Specifications 3-1. Specifications table Table 2 Type FG56Q FG62Q Jaw stroke Gripping force per a jaw Allowable maximum input force Allowable maximum 2500 2200 rotation speed Mass 117.5 Moment of inertia kg・m 4.13 Matching cylinder YG-204 YG-204 Maximum hydraulic pressure (with matching cylinder) Fluctuation of diaphragm plate... -
Page 16: Top Tooling
4. Top tooling 4-1. Changing the lever position setup 1. Pull the stopper rack and disengage the center gear from the rack as shown in Fig.5. 2. Insert the provided handle for changing the lever position into the pin, rotate the center gear, and move the lever case to the desired wheel size position. -
Page 17: Changing The Lever And Fixed Jig Setup
Fig. 6 4-2. Changing the lever and fixed jig setup 1. Pull the stopper rack and disengage the center gear from the rack as shown in Fig.5. 2. Loosen the limit screw as shown in Fig.7. If the limit screw is not loosened, the lever case will stop halfway even if the primary gear is turned, and it will not move to the lever replacement position. - Page 18 Fig.7 ・ Make sure that the stopper rack is fully pushed in before gripping the workpiece. If it is not pushed in completely, there is a risk of the workpiece flying off due to poor gripping, which is dangerous. ・ Make sure that the alignment mark on the fixed jig is within the wheel size scale range and that the limit screw is tightened before rotating the chuck.
- Page 19 Table 3-1 FG56Q Wheel Size Correspondence Lever A1 Lever B1 Lever C1 FG56QL1A1 Fixed Jig A FG56QL1B1 Fixed Jig B FG56QL1C1 Fixed Jig C FG56QL2A1 FG56QL2B1 FG56QL2C1 20” 19” 20”-17” 18” 18” 17” 17” 18”-15” 16” 16” 15” 15” 16”-13” 14”...
-
Page 20: Centering Jigs
4-3. Centering jig Function of centering jig A centering jig is provided to center the workpiece. There is the slide ring for process-1 and the center rod for process-2 as shown in Fig.8. Please refer to the respective delivery specifications information for shape and specifications. Fig. -
Page 21: Balance Pins For Seating Confirmation
4-4. Balance pins for seating confirmation Balance pin function Balance pins for seating confirmation can be installed at three places on the chuck surface. As shown in Fig.9, when there is no-load, the balance pin is in a raised position due to the built-in spring, and the air supplied to the balance pin is discharged out of the chuck via the silencer. -
Page 22: Usage
5. Usage This product is a device to fix an automotive aluminum wheel when it is processed by the lathe machine or the rotary table. The rotary cylinder closes the levers and fixes an automotive aluminum wheel so that it does not move during processing. -
Page 23: Precautions Related To Processing
5-2. Precautions related to processing <1> Unbalance ・ In the case of processing largely unbalanced work, lower the rotation speed. The work will fly out and this is dangerous. ・ Vibrations are generated if there is unbalance owing to the work or the jig, etc. Vibration not only will impart a negative influence on the process precision but also the endurance of the chuck being remarkably shortened, and the chuck may break. -
Page 24: Maintenance And Inspection
6. Maintenance and Inspection 6-1. Periodic Inspection Daily check ・ Clean the guide groove of the lever to prevent chips from accumulating. ・ Check that the balance pins stroke normally. If it does not move smoothly or does not move, disassemble and clean the chuck. ・... -
Page 25: Grease Lubrication
Table 4 Genuine Kitagawa genuine product CHUCK GREASE PRO product (Kitagawa distributor of each country) Kitagawa chuck grease Conventional product Molykote EP Grease TORAY Dow Corning (only inside Japan) Conventional Chuck EEZ grease Kitagawa-Northtech Inc. -
Page 26: Disassembling
4. Safety information about grease and anti-rust oil Scope of application ・ Designated grease ・ Anti-rust agent applied to the product at the time of delivery. First aid measures In case of inhalation: If inhaled in large quantities, immediately move the inhaler to a place with fresh... - Page 27 Chuck body disassembly procedure Turn off the main power and make sure that the piston is at its forward end position before the disassembly process. Remove the lever, balance pin, and centering jig beforehand. Remove the center gear [N] Attach the gear fixed jig [B1] with the socket head cap screw [04] to prevent the screw pinion [M] from turning accidentally during work.
- Page 28 ・ Use the bolts attached to the chuck, and do not use other bolts. However, if you must use other bolts not provided by Kitagawa, use bolts that have at least a strength classification of 12.9 (10.9 for M22 or more) and be sure they...
- Page 29 Table 5 Bolt size Tightening torque N・m N・m N・m N・m N・m N・m N・m N・m Fig.10...
-
Page 30: Malfunction And Countermeasures
7. Malfunction and Countermeasures 7-1. In the case of malfunction Check the points specified in the table below and take the appropriate countermeasure. Table 6 Defective Cause Countermeasure The chuck inside will break. Disassemble and replace the broken part. The chuck Disassemble, correct the seized part with oilstone, etc., or The sliding surface is seized. - Page 31 ・ If the chuck failed due to a seizure or breakage, remove the chuck from the machine, following the disassembly steps in page 26. When the chuck cannot be removed due to a blockage of workpiece, do not disassemble forcibly but please contact us or our agent.
-
Page 32: Attachment
For Machine Tool Manufactures Following pages are described for machine tool manufacturers (personnel who attach a chuck to a machine). Please read following instruction carefully when you attach or detach a chuck to machine, and please sufficiently understand and follow the instructions for safe operation. - Page 33 ・ Attach the manual switching valve at a position where it is easy to operate for the attaching equipment. ・ Install the hydraulic unit at a position where the drain hose is not kinked and the needle of the pressure gauge is easily read. ・...
-
Page 34: Design Of Chuck Open/Close Hydraulic Circuit
8-2. Design of chuck open/close hydraulic circuit ・ Fig.12 shows an example of chuck open/close hydraulic circuit. ・ Use the solenoid valve having 4 ports, 2 positions, and the circuit must hold the gripping port position when current is not applied. ・... -
Page 35: Design Of Seating Confirmation Air Circuit
8-3. Design of seating confirmation air circuit Fig.13 shows an example of seating confirmation air circuit. ・ The solenoid valve for seating confirmation must be in detected state when current is applied. ・ Use the air pipes having the inside diameter overφ 4 mm. Fig.13... -
Page 36: Design Of The Draw Pipe
8-4. Design of the draw pipe ・ If you design the draw pipe, refer to the Spec. information for supply for the shape and specification. ・ Provide sufficient strength for the draw pipe. If the draw pipe is broken due to insufficiency of the strength, the gripping force will be lost instantly, which is dangerous as the work will fly out. - Page 37 2.Attaching the air feed tube to the cylinder ・ Install the air feed tube (rotary joint) from the cylinder rear side, and then install the relay draw-pipe at the leading end of the draw-pipe on the small piston side. 3. Attach the cylinder to the spindle (or the cylinder adapter) ・...
- Page 38 ・ Use the bolts attached to the chuck, and do not use other bolts. However, if you must use other bolts not provided by Kitagawa, use bolts that have at least a strength classification of 12.9 (10.9 for M22 or more) and be sure they have sufficient length.
-
Page 39: Other Information
7. Adjust the plunger position ・ Adjust the position of the plunger [D] using the connection handle [Z] as shown in Fig.14. Note that the plunger is equipped with a ball plunger (to stop plunger from rotating), so be sure to complete the adjustment at the position where you feel this response. ・... - Page 40 The products herein are controlled under Japanese Foreign Exchange and Foreign Trade Control Act. In the event of importing and/or exporting the products, you are obliged to consult KITAGAWA as well as your government for t he related regulation prior to any transaction.
