- Page 1 MGate 5192 Series Quick Installation Guide Version 1.0, April 2024 Technical Support Contact Information www.moxa.com/support 2024 Moxa Inc. All rights reserved. P/N: 1802051920010 *1802051920010*...
-
Page 2: Package Checklist
Overview The MGate 5192 is an industrial Ethernet gateway for the power industry to integrate a IEC 61850 MMS network or devices to Modbus, DNP3, IEC 60870-5-101, or IEC 60870-5-104 networks. Package Checklist Before installing the MGate 5192, verify that the package contains the following items: •... -
Page 3: Panel Layouts
Color Description DNP3 (DNP3) No communication with the DNP3 client. [as DNP3 TCP or Green Steady (1 sec.): Normal DNP3 communication serial outstation] in progress. Blinking (1 sec.): 1. Received exception from the client (format error, checksum error, invalid data). 2. - Page 4 Front View Dimensions DIN Rail - 4 -...
- Page 5 Side DIN Rail Wall Mount - 5 -...
-
Page 6: Reset Button
Reset Button Restore the MGate to factory default settings by using a pointed object (such as a straightened paper clip) to hold the reset button down until the Ready LED stops blinking (approximately five seconds). Hardware Installation Procedure 1. Connect the power adapter. Connect the 12-48 VDC power line or DIN-rail power supply to the MGate 5192’s terminal block. -
Page 7: Wall Or Cabinet Mounting
Wall or Cabinet Mounting We provide two metal plates to mount the unit on a wall or inside a cabinet. Attach the plates to the unit’s rear panel with screws. With the plates attached, use screws to mount the unit on the wall. -
Page 8: Specifications
Specifications Power Parameters Power Input 12 to 48 VDC Power Consumption 455 mA max. Relays Contact Current Rating Resistive load: 2 A @ 30 VDC Environmental Limits Operating Temperature Standard models: -10 to 60°C (14 to 140°F) Wide temp. models: -40 to 75°C (-40 to 167°F) Storage Temperature -40 to 85°C (-40 to 185°F) - Page 9 NOTE The power input specification complies with the requirements of SELV (Safety Extra Low Voltage), and the power supply should comply with UL 61010-1 and UL 61010-2-201. WARNING 사용자안내문 (User Guide) 이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서가정용 환경에서 사용하는 경우 전파간섭의 우려가 있습니다. This equipment has KC approval to be used for industrial environments and therefore it has the possibility of interferences with household equipment.
