3 Rheologic

indicators

In the upper left corner, there is a battery indicator (Figure 4-1). The battery indicator depicts the status of the
RHEO KNEE's battery. When the battery is critically low, the user will receive a warning vibration and/or audio
sound. In case of any disturbance to the connection, due to timeouts in software, battery status, or excessive
distance to the RHEO KNEE, the Bluetooth connection icon (Figure 4-2) will change color according to the
connection state.
1. Battery level
2. Bluetooth Connection
3. Connect buttons
Figure 4
A message board (Figure 4-5) is located below the battery and Bluetooth indicators. The message board will
show messages related to the status of the RHEO KNEE. Pay attention if the message reads "Service required,
please contact Össur representative".
If this message appears, RHEO KNEE has detected a problem, and the RHEO KNEE should be sent for a service
check.

change name

To make it easier for you to recognize the RHEO KNEE among the list of accessible Bluetooth devices, you
can customize the name of the RHEO KNEE to each specific user. Össur recommends that you keep the serial
number as a part of the name for unique identification (Figure 4-4).

Warning system

The RHEO KNEE provides audio and vibration warning systems, which alert the user that power is low or a
system malfunction has occurred (Figure 4-6). Select the type of warning: audio, vibration, or both. Sliding the
frequency bar will change the pitch of the audio warning (Figure 5).
important: Make sure that the user recognizes the warning signals (some users
are hearing impaired or have poor tactile sensitivity).
6
Workbench functions
TM
4. Unit Name and Edit
- Firmware Version
- Step Count
5. Message Board
6. Warning System
Figure 5
