Extension hold

This setting is active when the box next to "Extension Hold" is checked. The setting is useful for vehicle entry/
exit, especially in low-rise vehicles. When active, the user may kick the knee into extension by using rapid hip
flexion followed by hip extension. A lock then activates to prevent the knee from flexing against the force of
gravity. The user is not forced to hold the shin in extension while entering the vehicle. After 3 seconds, the shin
automatically unlocks and moves into flexion with gravity
Managing users and
The User Manager and the Clinicians Manager can be accessed from "Database" in the file menu,or when
editing the information in the Activity Report. You can add a new user or edit and delete existing users and
clinicians. Below is a detailed description of how to add, edit or delete users (Figure 10). The procedures are the
same for clinicians .
1. Add a new user by clicking the "New" button. Insert the name, address, and/or insurance/benefit ID and
click "OK."
2. Edit an existing user by selecting the user's name and click the "Edit" button. Change the name, address,
and/or insurance/benefit ID and click "OK."
3. Delete an existing user by selecting the user's name and click the "Delete" button.
1. List of Users
2. Add User
3. Edit User
1
Figure 10
hint: If the list of users is long, you can mark one of the users and then type the first letter of the name you are
looking for. This will automatically scroll to the names starting with this letter.
clinicians
4. Delete User
5. Name
6. Address
5
6
7
7. Insurance/Benefit ID
2
3
4
