SW-505-24P-F Managed PoE+ Switch
Quick Installation Guide
Placement
1. Attach either the rack mounting ears or the adhesive feet.
2. If applicable, mount the device in the rack.
Connections for service
1. Connect one of the LAN ports on your router to one of the ports on the switch.
2. Connect your PoE/PoE+ powered devices to the Gigabit PoE+ ports.
3. Use either the unpowered Ethernet portion or the SFP portion (with the appropriate
module) of the Ethernet/SFP combo ports for devices that have their own power. SFP
modules are not included with this product.
4. Connect the power cord to the switch and to a properly grounded power outlet. The
switch takes a minute or more to boot.
Document 411-3005-01 Rev A June 2023

Advertisement

loading
Need help?

Need help?

Do you have a question about the LUXUL SW-505-24P-F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LEGRAND LUXUL SW-505-24P-F

Summary of Contents for LEGRAND LUXUL SW-505-24P-F

  • Page 1 SW-505-24P-F Managed PoE+ Switch Quick Installation Guide Placement 1. Attach either the rack mounting ears or the adhesive feet. 2. If applicable, mount the device in the rack. Connections for service 1. Connect one of the LAN ports on your router to one of the ports on the switch. 2.
  • Page 2 SW-505-24P-F Quick Installation Guide Advanced configuration The default network settings work for most at-home offices and other small networks, so you might not need to change anything. Skip this section unless you know that you need to make configuration changes on the switch. 1.
  • Page 3 SW-505-24P-F Quick Installation Guide What's on the front panel System LED Blinking = normal operation On = error; press the Mode/Reset button to reboot LINK/ACT/SPEED Information shown on port LEDs – Link activity and speed and PoE LEDs (default), or PoE status Mode/Reset button Tap to change between LINK/ACT and PoE modes Press and hold until the System LED blinks and all port lights turn...
  • Page 4 Learn more about Luxul products at Legrand AV University! Luxul and the Luxul logo are registered trademarks of Legrand AV Inc. All other brand names or marks are used for identification purposes and are trademarks of their respective owners. All patents are protected under existing designations.
