1.1 Basic Requirements
All installation and operations shall conform to your local electrical safety regulations, fire
●
protection regulations, and other relevant regulations.
Make sure that the application scenario conforms to installation requirements. Contact your
●
local retailer or customer service center if there is any problem.
Use the Device according to the operating environment.
●
Keep the original packing material well because you might need it to pack the Device and send
●
it back for repair.
1.2 Installation Check
Make sure that the place where the Device is installed has enough space to hold the Device and
●
its mounting accessories.
For PTZ cameras, make sure that the place where the Device is installed can sustain at least 4
●
times the weight of the Device and its mounting accessories; for speed domes, make sure that
the ceiling and wall can sustain 8 times the weight of the Device and its mounting accessories.
Do not install the Device at risky or unstable places.
●
Make sure that the wall is thick enough to install expansion bolts (Users need to buy expansion
●
bolts separately).
For speed domes support intelligent tracking, illegal parking capture or laser, make sure that the
●
mounting height is over 6 m.
For laser PTZ, make sure that the mounting height is over 10 m.
●
Support wall mount and plane mount, fixed with M8 × 25 hex flange assembling bolts.
●
1.3 Cable Preparation
Select the video cable depending on transmission distance.
1.3.1 Video Cable Requirements
75 ohm.
●
Pure copper cored cables.
●
95% braided copper shielding.
●
Model
RG59/U
RG6/U
RG11/U
1 Installation Preparation
Table 1-1 Cables and maximum transmission distance (network)
Maximum Transmission Distance (ft/m)
750 ft/229 m
1,000 ft/305 m
1,500 ft/457 m
1
