- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support ELECTRIC HOIST SUPPORT ARM Model: HST-750...
- Page 2 We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
- Page 4 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
- Page 5 WARNING! Please carefully review this information before using the product to ensure your safety. The arm comprises a stable buckle and foundation bracket, featuring a strong bearing capacity of 300 kg. The Rocker arm can rotate 180 degrees, allowing the boom to operate more flexibly with a wide operating range and high working efficiency.
-
Page 6: Product Description
Link Rod Locking Casting Rocker Arm Extension Arm Wall Mount 3. Product Parameter 1. Name:Electric Hoist Support Arm 2. Model:HST-750 3. Max. Load:300kg(700mm arm);150kg(1100mm arm) 4. Material: Steel 5. Rotation: 180° - 3 -... -
Page 7: Parts List
4. Parts List Picture Name Wall Mount Rocker Arm Extension Arm Link Rod Locking Casting 1 Locking Casting 2 Locking Casting 3 Big Washer Bolts(M12x70mm) Bolts(M12x30mm) Split Pin User Manual - 4 -... -
Page 8: Installation Steps
5. Installation Steps Step 1- Install the wall mount onto the wall and secure it with the appropriate expansion screws. Use the right tools to ensure the support arm is firmly tightened. Please note that expansion screws are not included in the package and need to be purchased by the customer separately. - Page 9 the bolts and nuts are tightened. Link Rod Rocker Arm xtension Prevent the hoist from slipping out. A: The nut is installed in the square tube. B: You can select one of the holes to install according to your needs. Step 4- Put the big washer into the shaft and insert the rocker arm into the bottom locking casting pin, then install the big washer and split pin.
- Page 10 Open the end of split pin to lock the link rod. Step 5- Insert the link into the pin on the top locking casting, and then install the split pin. After installing the split pin, make sure to open the end of the pin to confirm that the split pin cannot fall out of the locking pin hole.
-
Page 11: Maintenance
A:700mm(Max) 300kg(Max) 150kg(Max) B:1100mm(Max) Location A: Load capacity: Max300kg , Arm: Max 700mm; Suitable for 2200lbs Electric Hoist Location B: Load capacity: Max150kg , Arm: Max 1100m; Suitable for 440lbs-1800lbs Electric Hoist 6. Usage Guide 1. Unpack and check for any transit damage. 2. - Page 13 Technical Support and E-Warranty Certificate www.vevor.com/support...
