- Page 1 answers Technisches Handbuch / Technical Manual Mainboard D1683 Deutsch / English / Français...
- Page 2 Sie haben ..technische Fragen oder Probleme? Wenden Sie sich bitte an: • Ihren zuständigen Vertriebspartner • Ihre Verkaufsstelle Aktuelle Informationen zu unseren Produkten, Tipps, Updates usw. finden Sie im Internet: http://www.fujitsu-siemens.com oder http://www.fujitsu-siemens.com/mainboards Are there ..any technical problems or other questions you need clarified? Please contact: •...
- Page 4 Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Herausgegeben von/Published by Fujitsu Siemens Computers GmbH A26361-D1683-Z120-1-6319 Bestell-Nr./Order No.: Printed in the Federal Republic of Germany AG 0703...
- Page 5 Deutsch English Mainboard D1683 Français Technisches Handbuch Technical Manual Ausgabe Juli 2003 July 2003 edition...
- Page 6 Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der jeweiligen Inhaber und werden als geschützt anerkannt. Copyright Fujitsu Siemens Computers GmbH 2003 Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
- Page 7 Übersicht/Overview Mainboard D1683 Diskettenlaufwerk / Floppy disk drive Interne Anschlüsse und Steckplätze / Internal Bedienfeld / Front panel connectors and slots Stromversorgungsüberwachung / 21 22 Power supply control IDE-Laufwerke 3/4 / IDE-drives 3/4 Stromversorgung / Power supply IDE-Laufwerke 1/2 / IDE-drives 1/2 Serial ATA2 Batterie / Battery Serial ATA1...
-
Page 9: Table Of Contents
Contents Übersicht/Overview Mainboard D1683 ...................1 Mainboard D1683..........................1 Notational conventions.......................1 Important notes ..........................2 Information about boards ......................2 List of features...........................3 Special features.........................4 Brief instructions on installing mainboard...................6 Prior to installation ........................6 Interfaces and connectors ......................8 External ports ............................8 LAN connector...........................8 Internal ports and connectors ......................9 Hard disk connection .........................9 Audio front panel........................9 Pin assignment of internal ports.......................10... -
Page 11: Übersicht/Overview Mainboard D1683
Mainboard D1683 Your mainboard is available in different configuration levels. Depending on the configuration chosen, some of the hardware components described may not be available on your mainboard. Additional information Information on the BIOS Setup and additional descriptions of the drivers are contained: •... -
Page 12: Important Notes
Important notes Important notes With the mainboard installed you must open the system to access the mainboard. How to dismantle and reassemble the system is described in the operating manual accompanying the system. Connecting cables for peripherals must be adequately insulated to avoid interference. Observe the safety notes in the operating manual of your system. -
Page 13: List Of Features
Recovery BIOS / DeskUpdate / Multi Boot ! / ! / ! HDD Password / USB Security ! / ! Fujitsu Siemens Computers Keyboard Power Button Support Internal ports DIMM Sockets (DDR 400, SDRAM, PC3200) AGP Slot (2x/4x/8x, 32 bit, 66 MHz, 1.5 V) PCI slot (32 bit, 33 MHz, 5 V and 3.3 V) -
Page 14: Special Features
Silent Fan A micro controller developed by Fujitsu Siemens Computers monitors and controls the fans in the PC and thus prevents any unnecessary noise annoyance. Should the processor become in spite of full turning ventilator too hot, then the processor clock rate will automatically be reduced so that the system continues to run stably. - Page 15 USB Security is a BIOS function that offers protection against unauthorised access regardless of the operating system used. If USB Security is activated, the system can only be started, if the MemoryBird of Fujitsu Siemens Computers is connected to one of the existing USB-ports.
-
Page 16: Brief Instructions On Installing Mainboard
Brief instructions on installing mainboard If you have purchased a separate mainboard, you can install it in your system in accordance with the following brief instructions. The activities described here assume a basic knowledge of PCs and cannot be carried out by a layperson. - Page 17 Brief instructions on installing mainboard Should no suitable connection field be Ê provided in the case, then you must install the connection field (1) provided. Ensure the plate is aligned properly so that the connections are suitable for the mainboard later. Set the mainboard on the edge on Ê...
-
Page 18: Interfaces And Connectors
Interfaces and connectors The positions of the interfaces and connectors are shown on page "Cover". The components and connectors marked are not necessarily present on the mainboard. External ports The positions of the external ports are shown on page "Cover". Audio input (Line in), light blue PS/2 keyboard port, purple PS/2 mouse port, green... -
Page 19: Internal Ports And Connectors
Internal ports and connectors Internal ports and connectors The positions of the internal ports and connectors are shown on the Cover. Additional information on some ports is also provided here. Hard disk connection An ultra ATA/66 or ultra ATA/100 hard disk must be connected with a cable especially designed for the ultra ATA/66 or ultra ATA/100 mode. -
Page 20: Pin Assignment Of Internal Ports
Pin assignment of internal ports Pin assignment of internal ports The pin assignment of some internal connections is shown in English in the following. Some of the following connectors may be optional! Power On/Off Front panel Sleep LED Message LED Power On LED 2) HD-LED... - Page 21 Pin assignment of internal ports Serial ATA (internal) Signal Signal Transmit data positive Transmit data negative Receive data negative Receive data positive ATA interface Signal Signal Reset drive (low asserted) Data 7 (high asserted) Data 8 (high asserted) Data 6 (high asserted) Data 9 (high asserted) Data 5 (high asserted) Data 10 (high asserted)
- Page 22 Pin assignment of internal ports CD audio input Signal Left CD audio input CD GND CD GND Right CD audio input AUX audio in Signal Left AUX audio input Analogue GND Analogue GND Right AUX audio input Stromversorgungsüberwachung / Power supply control Signal AC Outlet (high asserted) PS FAN Control (low asserted)
- Page 23 Pin assignment of internal ports Audio front panel Signal Signal Micro input Analogue GND Micro bias Analogue VCC Right line output Right line return not connected Left line output Left line return If the audio front panel is not used, you must plug jumpers on pin pairs 5/6 and 9/10. USB E/F - dual channel USB G/H - dual channel (internal or external via special wire)
- Page 24 Pin assignment of internal ports Fan 3 Signal Controlled FAN voltage (0V, +6V, ... +12V, max. 1A) or fix Fan voltage (+12 V, max. 1 A) Fan sense Floppy interface Signal Signal Step DIR (low asserted) FDHDIN (low asserted) Step Pulse (low asserted) not connected Write Data (low asserted) not connected...
- Page 25 Pin assignment of internal ports External temperature sensor Signal Signal P3V3P_DUAL SMB_PIC_DATA_H SMB_PIC_CLK_H LCD front panel Signal Signal SMB CLK LAN Link Icon Harddisk Action Icon SMB DATA BMC Alert Icon Message Icon Sleep Icon Power Icon Reserved for Future use LAN Active Icon P3V3P_DUAL Cover monitoring...
- Page 26 Pin assignment of internal ports Power supply ATX Signal Signal +3.3V(P3V3P) +3.3V(P3V3P) +3.3V(P3V3P) -12V (P12VN) +5V (VCC) PS on (low asserted) +5V (VCC) Powergood (high asserted) -5V (5PVN) +5V Auxiliary (VCC Aux) +5V (VCC) +12V (P12VP) +5V (VCC) Additional power supply ATX12 V Signal Signal +12 V...
-
Page 27: Settings With Switches And Jumpers
Pin assignment of internal ports Settings with switches and jumpers Your mainboard is equipped with switches or jumpers. The positions of the switches or jumpers are shown on page "Cover". Switch 1 = Skipping system and BIOS Setup password Switch 2 = System BIOS recovery 1 2 3 4 Switch 3 = must be set to off Switch 4 = must be set to off... -
Page 28: Add-On Modules / Upgrading
Add-on modules / Upgrading Exit energy-saving mode, switch off the system and remove the power plug from the mains outlet, before carrying out any of the procedures described in this chapter! Even when you have switched off the device, parts (e.g. memory modules, AGP and PCI extension boards) are still supplied with power. - Page 29 Replacing processor Mounting heat sink Be sure to use heat conducting material between the processor and the heat sink. If a heat conducting pad (rubber-like foil) is already applied to the heat sink, then use it. Otherwise you must apply a very thin layer of heat conducting paste. Heat conducting pads can only be used once.
-
Page 30: Upgrading Main Memory
Upgrading main memory Upgrading main memory Technical data Technology: DDR 333 or DDR 400 unbuffered DIMM modules 184-Pin; 2.5 V; 64 Bit, with and without ECC Size: 128 Mbyte to 4 Gbyte 333 DDR-SDRAM 128 Mbyte to 4 Gbyte 400 DDR-SDRAM Granularity: 128, 256, 512 or 1024 Mbyte for one socket At least one memory module must be installed. - Page 31 Upgrading main memory Installing a memory module Push the holders on each side of the memory slot outwards. Ê Insert the memory module into the location (1). Ê At the same time flip the lateral holders upwards until the memory module snaps in place (2). Ê...
-
Page 32: Upgrading Agp Screen Controllers
Upgrading AGP screen controllers Upgrading AGP screen controllers Technical data: The AGP slot supports the modes 4x/8x with 32 bits and 66 MHz. Only 1.5 V AGP graphics cards are supported. Some older 3.3 V AGP graphics cards are coded like 1.5 V AGP graphics cards. The installation of such 3.3 V AGP graphics cards can cause serious damage to the mainboard and the AGP graphics cards. - Page 33 Adding PCI cards Multifunctional expansion cards or expansion cards with integrated PCI-PCI bridge: These expansion cards require up to four PCI interrupts: INT A, INT B, INT C, INT D. How many and which of these interrupts are used is specified in the documentation provided with the card. The assignment of the PCI interrupts to the PCI IRQ Lines is shown in the following table: Controller or slot INT Mechanical slot...
-
Page 34: Replacing The Lithium Battery
Adding PCI cards Replacing the lithium battery In order to permanently save the system information, a lithium battery is installed to provide the CMOS-memory with a current. A corresponding error message notifies the user when the charge is too low or the battery is empty. The lithium battery must then be replaced. Incorrect replacement of the lithium battery may lead to a risk of explosion! The lithium battery may be replaced only with an identical battery or with a type recommended by the manufacturer. -
Page 35: Bios Update
BIOS update BIOS update When should a BIOS update be carried out? Fujitsu Siemens Computers makes new BIOS versions available to ensure compatibility to new operating systems, new software or new hardware. In addition, new BIOS functions can also be integrated. -
Page 36: Microcode Update
Intel refers to the use of the processor without microcode updates as operation outside the specifications. Safety for processor on Fujitsu Siemens Computers mainboards If the processor uses an old or incorrect microcode, error-free operation cannot be ensured. Fujitsu Siemens Computers has therefore implemented a function on its mainboards that interrupts the booting process if no suitable microcode is available for the installed processor. -
Page 37: Drivers
Drivers Microcode update under DOS with bootable microcode update floppy disk - brief description Download the update file from out website to your PC. Ê Insert an empty floppy disk (1.44 Mbyte). Ê Run the update file under DOS (e.g. 1683101.EXE ). Ê... -
Page 38: Annex
Mainboard current requirement You require a Pentium4 power supply nit as per the ATX12V specification for this mainboard. If you do not have a PC from Fujitsu Siemens Computers, make sure that the power supply unit provides the required amperages. -
Page 39: Apm And Acpi System Status, Energy-Saving Modes
APM and ACPI system status, energy-saving modes APM and ACPI system status, energy-saving modes System ACPI Power Power Sleep Power Wake-up status Status Status LED I LED II consum time ption Normal On/Off Normal operation Simple Standby Off/On flashin Almost Almost energy- like... -
Page 40: Mainboard Revision And Bios Version
Mainboard Revision and BIOS Version Mainboard Revision and BIOS Version The compatibility, e.g. with new processors, can be independent of the BIOS version or the revision status of the mainboard used. Mainboard Revision The revision status of the mainboard exactly identifies which mainboard you have. It is indicated on a sticker on the edge of the mainboard: D1683-A31 GS 1 05618476... -
Page 41: Error Messages
Error messages This chapter contains error messages generated by the mainboard. Available CPUs do not support the same bus frequency - System halted! Memory type mixing detected Non Fujitsu Siemens Memory Module detected - Warranty void There are more than 32 32 RDRAM devices in the system Check whether the system configuration has changed. - Page 42 Error messages DMA test failed EISA CMOS not writable Extended RAM Failed at offset: nnnn Extended RAM Failed at address line: nnnn Failing Bits: nnnn Fail-Safe Timer NMI failed Multiple-bit ECC error occurred Memory decreased in size Memory size found by POST differed from EISA CMOS Single-bit ECC error occurred Software NMI failed System memory exceeds the CPU’s caching limit...
- Page 43 Error messages Missing or invalid NVRAM token Switch the device off and on again. If the message is still displayed, please contact your sales outlet or customer service centre. Monitor type does not match CMOS - RUN SETUP Correct the entry for the monitor type in the Main menu of the BIOS Setup . On Board PCI VGA not configured for Bus Master In the BIOS Setup , in the Advanced menu, submenu PCI Configuration , set the Shared PCI Master Assignment entry to VGA .
- Page 44 Error messages System battery is dead - Replace and run SETUP Replace the lithium battery on the mainboard and redo the settings in the BIOS Setup . System Cache Error - Cache disabled Switch the device off and on again. If the message is still displayed, please contact your sales outlet or customer service centre.
-
Page 45: Glossary
Glossary The technical terms and abbreviations given below represent only a selection of the full list of common technical terms and abbreviations. Not all technical terms and abbreviations listed here are valid for the described mainboard. ACPI Advanced Configuration and Industrial Standard Architecture Power Management Interface AC'97...
