- Page 1 IS194 Rev.08 17/04/2024 BIONIK8 Automatic barrier Brushless INSTRUCTIONS AND RECOMMENDATIONS FOR THE INSTALLER...
-
Page 2: Intended Use
This product may only be used for its expressly intended purpose. Any other usage is prohibited. ROGER TECHNOLOGY cannot be held directly or indirectly responsible for any damage resulting from incorrect, inappropriate or unreasonable usage of this product. Limits of use BIONIK8 barriers are suitable for VERY HEAVY DUTY operation and may be used with booms up to 8 metres in length. -
Page 3: Package Content
Dimensions MAX = 8000 Note: all measurements are expressed in mm unless otherwise indicated. Package content BARRIERA BIONIK8 COMPLETE BIONIK8 BARRIER CABINET WITH INTEGRATED CONTROL UNIT HEAD COMPLETE WITH DIFFUSER AND FLASHING LAMP UNIT ACCESSORIES - ASSEMBLED BOOM BOLTS AND SCREWS... -
Page 4: Technical Characteristics
Technical characteristics BI/008 BI/008/115 Power Supply 230 V~ - 50 Hz ±10% 115 V~ - 60 Hz ±10% Motor power supply Starting power 300 W 300 W Power consumption 0 ÷ 18 A 0 ÷ 18 A Torque 10 ÷ 400 Nm 10 ÷... -
Page 5: Typical Installation
Typical installation 10 8 Automatic Barrier BIONIK serie Integrated control unit Flashing light External Photocell Boom with shockproof rubber Strip led Reflective sticker Internal Photocell Fixed end rest for boom complete with a shock-resistant rubber mechanical stop Release system Key or keypad release switch... - Page 6 References and accessories 15 16 17 18 Codice / Code Descrizione / Description Barrier unit cabinet, in carbon steel with anti-corrosion treatment and painted Aluminium boom support base, die-cast, with anti-corrosion treatment, painted JNT/BA/128 BIONIK 8. Internal connection joint made of anodized aluminium. BA/128/4 Boom L 4,1 m made of aluminium, with slot cover profiles and shockproof rubber Zinc coated steel boom fastening bracket...
- Page 7 Codice / Code Descrizione / Description Brushless ed encoder assoluto / Gear motor complete with Brushless motor and absolute encoder SP/85/AS/02 2 Ø85 springs for booms up to 8 m Corrosion-proof, painted steel inspection hatch Galvanised base plate for barrier fastening KT244 BAFS/01 Fixed end rest, non-adjustable, with rubber buffer...
-
Page 8: Installation
Installation 10.1 Preliminary checks • Check that the material received is in good condition and suitable for the application. • Check that the operating limits of the product are not exceeded. • Check that the site chosen for installation meets the overall space requirements of the product and that there are no obstacles hindering open or close manoeuvres. •... - Page 9 90° BIONIK8...
- Page 10 10.4 Selecting direction of aperture BIONIK barriers are configured by default for installation on the right hand side (seen from the inspection hatch side). OPENING ON THE LEFT Whenever corrective actions are carried out, pay the utmost attention when releasing, locking or moving the internal mechanical parts.
-
Page 11: Boom Installation
Boom installation IMPORTANT: The BIONIK8 barrier is supplied with two 4.1 m booms (D1 and D2). WARNING! • Unlock the barrier (see chapter 20). • Turn the linkage lever into the position necessary for installing the boom horizontally. • Lock the barrier. - Page 12 Installing and adjusting the spring The booms are understood as complete with shock-resistant rubber and LED strips BI/008 (con asta fino a 8 m) (boom up to 3 m) The adjustable fixed end rest with integrated magnet BAFS/05 must be used The adjustable fixed end rest with integrated magnet BAFS/05 must be used The adjustable fixed end rest with integrated magnet...
- Page 13 12.2 Slider selection • The correct position of the slider is determined by the boom weight: the heavier the boom is (weight determined by the totality of the accessories installed), the more to the outside the slider should be installed. •...
- Page 14 12.3 Spring unit installation 1. Unlock the barrier (see chapter 20) and move the boom into the completely open vertical position. 2. Fasten the spring unit SP/85/AS/02 to the linkage lever using the screws included (fig. 16), according to the opening direction and in the position that allows the correct movement of the barrier.
- Page 15 12.4 Spring adjusting 1. Adjust the spring tensioning by loosening the nuts [A] as indicated in fig. 18. 1. By moving upward the fastening cross bar [B], the spring tensioning increases; vice versa, by moving it downward, the tensioning decreases. 2.
-
Page 16: Adjusting The Mechanical Stop
Adjusting the mechanical stop The figure 20 shows the mechanical stop on a barrier installed on the LEFT hand side. For barriers installed on the RIGHT, perform the mirror images of the procedures illustrated. • Unlock the barrier (see chapter 20). Set the completely open [AP] and completely closed [CH] positions by adjusting the relative mechanical stops. - Page 17 GREEN Connecting photocells G90/F4ES photocells may be installed on both sides of the barrier at two different heights: (50 cm or 100 cm). • Disconnect from mains electricity and from battery power (if applicable). • Open the inspection hatch, turning the key clockwise by 90°. •...
-
Page 18: Electrical Connections
Electrical connections All electrical connections must be made with the unit disconnected from mains power and, if applicable, battery power. See controller manual for instructions on making connections and programming CTRL. Before connecting to electrical power, ensure that the mains power specifications on the identification plate match the mains power supply used. - Page 19 Installing the battery kit (optional) Disconnect the mains power. Unscrew the screws [Z] and remove the head [A] (if applicable). Lift the cable grommet [B] and disconnect the connector [C]. Open the transparent control unit cover [D]. Switch the control unit switch to the OFF position [E]. Lift the control unit and insert the batteries in their housing [F].
-
Page 20: Maintenance
LED LIGHT Maintenance N.B.: Only use original spare parts when repairing or replacing products. The installer must provide the user with complete instruction for using the motorised door or gate in automatic, manual and emergency modes, and must hand the operating instructions to the user of the installation upon completion. -
Page 21: Declaration Of Conformity
To lock the barrier again, turn the key clockwise by 360° making 2 complete turns, as indicated in fig. 2. Declaration of conformity I the undersigned, as acting legal representative of the manufacturer: Roger Technology - Via Botticelli 8, 31021 Bonisiolo di Mogliano V.to (TV) hereby DECLARE that the appliance described hereafter:... - Page 22 USER GUIDE Release and lock procedure 2x360° 2x360° FIG. 1 FIG. 2 Whenever corrective actions are carried out, pay the utmost attention when releasing, locking or moving the internal mechanical parts. These operations could be hazardous for the installer. In some situations, such as in the event of a power outage or scheduled or extraordinary maintenance, it is necessary to release the automation. The operation of the release of the automation must be carried out when the boom is is stopped in the closed position (horizontal).
