It is highly recommended to view the assembly video prior to starting assembly!
Click here to View the assembly process or scan the QR code.
Manufactured by:
Outdoor Pure Cube
Assembly Instructions
Requirements:
2 People (recommended)
Rubber Mallet
Carpenters Level
Tape Measure
Phillips & Robertson Drill Bits or Screwdrivers
Drill Bit set (1/8" - 1" – 1 ½")
tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com
Trinity
Cordless Drill
2" hole Saw
Staple Gun
¼" Nut Driver
Step Ladder
4mm Hex Bit
05/2024
Advertisement
Related Manuals for leisurecraft Pure Cube Trinity
Summary of Contents for leisurecraft Pure Cube Trinity
- Page 1 Drill Bit set (1/8” - 1” – 1 ½”) 4mm Hex Bit It is highly recommended to view the assembly video prior to starting assembly! Click here to View the assembly process or scan the QR code. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 2 A solid base for your sauna is recommended and can be made from any of the following. Concrete Pad Wood Deck Crushed Stone Patio Stone/Paver Blocks It is recommended to build a base larger than required to provide a sitting area for cooling off during your sauna session Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 3 Use the holes on the panel as a guide and with a 1/8” drill bit, predrill holes into the post. Secure the panel to the post using the coarse thread lag screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 4 Secure the panel to the post using the same process as the previous panel. Place the assembled panels onto the back corner of the base. Ensure the panels overhang the base 1 ½” (51mm). Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 5 Secure the panel to the post using the coarse thread lag screws. Place the narrow panel next to the wide panel. Ensure the side labeled “top” is aligned with the top side of the wide panel. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 6 2 – 2 ½” (64mm) screws. Repeat the process with another narrow panel and post beside the other wide panel. Ensure the side labeled “top” is aligned with the top side of the wide panel. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 7 Screw between the slats of the enclosure to make the screws less visible. Place the bench assembly into the sauna ensuring it is tight to the back and side walls. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 8 Use the holes as a guide and with a 1/8” drill bit, pre- drill into the spacer block. Secure the block to the panel with a coarse connector lag screw in each block. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 9 Secure the blocks on each side to the door panel using a 3” (76mm) screw in each spacer block. *You may want to pre-drill these to prevent the spacer block from splitting. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 10 Slide the assembled roof panel on top of the walls. Ensure the roof is flush to the edges of the walls. You can use a rubber mallet to finesse into place if needed. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 11 Begin placing the trim over the seams between the wall panels. Ensure they are flush to the bottom of the wall panel and secure with 1 ¼” (32mm) staples or finishing nails. Continue for the remaining wall panels. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 12 1/8” bit. Be careful not to go through the nosing board with the drill bit. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 13 Secure the nosing to the roof panel using 2 of the connector lag screws in the pre-drilled holes. Repeat the process for the nosing above the other glass wall panel. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 14 Remove the protective film from the roof insert. Place the roof insert onto the roof. Decide what side you want the water to drain from. On the other side mark the position of the drain hole on the nosing. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 15 Transfer that measurement to the nosing piece and using a 1 ½” (38mm) bit drill a hole through the nosing. Screw the pipe into the drain hole on the roof insert. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 16 Place the upper bench enclosure on the front of the bench supports and secure with 2 – 2 ½” (64mm) screws into each support. Screw between the slats of the enclosure to make the screws less visible. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 17 Only go halfway through to prevent splintering and drill the remainder from the other side of wall. On the outside of the sauna, secure the vent guard over the holes with the provided screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 18 Use the hex key to snug up, do not tighten all the way. Ensure the outer handle lines up with the magnetic catch on the door frame and then tighten the lag screws completely. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 19 Use a 1 ½” (38mm) screw to hang the optional thermometer in the desired location. Use 2 - 1 ½” (38mm) screws to hang the optional cedar sauna shelf in the desired location. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 20 This natural weathering will not harm the wood or impair the sauna’s performance. If you wish to retain the natural color of your Dundalk Leisurecraft Sauna, there are many cedar stains on the market and almost as many opinions as to which is best.
-
Page 21: How To Take A Sauna
Children must be supervised by an adult. WARRANTY LeisureCraft warrants our saunas against defects in materials and workmanship under normal/residential use for a period of five (5) years, as applicable, from the date of receipt of the product by the original end- user consumer.
