Summary of Contents for Aqualisa QUARTZ CLASSIC QZD.A1.EV.23
- Page 1 QUA R T Z CLASSIC ™ USER GUIDE...
-
Page 2: Table Of Contents
For further information regarding the installation of your product, refer to the Smart Installation Guide. Declaration of Conformity Aqualisa Products Limited declares that the Aqualisa ® ® SmartValve and supplied controller, in conjunction with pairing... -
Page 3: Get Smart Connected
ON/OFF/DIVERT Get Smart Connected Unlock the potential of your shower; from water consumption analysis to enhanced user functions. Keep up to date with latest features for the Aqualisa ® App and voice activation by visiting the Aqualisa website and download the free ®... -
Page 4: Single Outlet Controller
SmartValve has a maximum run ® time of 20 minutes. The flow can be stopped and started at anytime by pressing the ‘Start/Stop’ button. This can be enhanced by activating and using the free Aqualisa App. ® See page 3. -
Page 5: Dual Outlet (Divert) Controller
SmartValve has a maximum ® run time of 20 minutes. The flow can be stopped and started at anytime by pressing the ‘Start/Stop’ button. This can be enhanced by activating and using the free Aqualisa App. ® See page 3. -
Page 6: Bath Outlet Controller
App. See page 3 for details. ® N.B. The app timer setting will allow you to select a duration of more than 12 minutes; however, this does not override the default maximum run time of the Aqualisa SmartValve , meaning the water flow will ®... -
Page 7: Setting Flow Rate
Setting Flow Rate For Dual Outlet (divert) Controllers only 1. Ensuring the Aqualisa SmartValve™ is powered, but ® without any outlets flowing, enable ‘Setup’ mode by first turning the temperature dial to full cold. Press and hold both buttons together for 5 seconds. -
Page 8: Wired Remote
Wired Remote Single Outlet 1. Press the ‘Start/Stop’ button on the remote to turn the shower on. 2. The blue LED display will flash until the selected temperature has been reached. When the LED display is constant, step into your shower and enjoy! 3. -
Page 9: Adjustable Head
Adjustable Head To avoid water dripping from the shower head after use, we advise to tilt the head back to allow residual water to drain out. The above recommendation applies to both adjustable and fixed shower heads. 1. Inner 2. Middle 3. -
Page 10: Fixed Head
1. Rotate the spray plate lever clockwise or anti- clockwise to select the desired spray pattern. When the lever is in position 4, the water saving ‘Eco’ mode is selected. This provides the same spray pattern as position 3, but, depending on which water system the product is fitted to, offers up to 25% water saving. -
Page 11: Bath Overflow Filler
Bath Overflow Filler 1. Push the waste cover to engage the plug fitting. 2. Push the waste cover again to disengage the plug. Do not leave the bath filler running unattended. Although the overflow will remove excess water once the bath is overfilled, this may not be sufficient to prevent the bath from overflowing (depending on system conditions). -
Page 12: Caring For Your Shower
Changing water system? If switching from a gravity-fed water system to a mains pressure system (e.g. Combination boiler) you will need to change your Aqualisa SmartValve . Contact a ®... -
Page 13: Troubleshooting
Symptom Possible cause Action Controller Power supply turned Check power supply is turned on - Green power unresponsive - off to Aqualisa light should be illuminated on the Aqualisa ® ® No Lights / Blank SmartValve SmartValve Loss of Check data cable connections are making good... - Page 14 Aqualisa SmartValve point. ® is set to ECO mode Unable to adjust or Reversed inlet water Ensure correct water supply to specified inlet control temperature supplies (i.e. Hot connection of the Aqualisa SmartValve ® supply feeding cold inlet and vice-versa)
- Page 15 Incorrect setting If hot water supply is from a combination boiler- temperature on Logic Module the Logic module mode MUST be set to COMBI. of Aqualisa Refer to Setting Water System Mode section in ® SmartValve the Smart Installation Guide.
- Page 16 Temperature too Seasonal conditions In the warmer months, the mains water temperature can rise to ambient level. The Aqualisa SmartValve always blends a mix of ® both hot and cold supplies therefore the output temperature at fully cold (controller setting) will always be higher than the incoming cold water supply.
-
Page 17: Have You Registered
You can easily increase your FREE guarantee to 5 years simply by registering your product. Please keep your receipt to validate your guarantee. Please see our website for full terms and conditions. *Subject to terms and conditions Register your guarantee instantly at aqualisa.co.uk/guarantee Register your guarantee 0800 408 4243... -
Page 18: Need Help
Need Help? You can find Frequently Asked Questions at aqualisa.co.uk Speak to our Customer Service team on 01959 560010 Use Live Chat at aqualisa.co.uk Or email us at enquiries@aqualisa.co.uk... - Page 19 Notes...
- Page 20 Sales enquiries: 01-864-3363, Service enquiries: 01-844-3212 Please note that calls may be recorded for training and quality purposes. The company reserves the right to alter, change or modify the product specifications without prior warning. ® Registered Trademark Aqualisa Products Limited. ®...
