Test Operation - Assa Abloy ACCENTRA nexTouch Installation And Programming Instructions

5
Install Key Cylinder (if applicable) For Cylinder Option ONLY
80-9086-0030-010 04/2024
It may be necessary
to loosen the cylinder
set screw before
installing the cylinder.
Use #2 Philips
head screwdriver
HAND TIGHTEN.
Do not use powered
screwdriver.
2
Then, use #2
Philips head
screwdriver to
tighten cylinder
set screw.

Test Operation

Outside of Door
1
First, tighten
cylinder until snug
against door with
the logo horizontal.
1
7
Outside of Door
