7. 2. 4

Original is misfed

Cause Checking
order
Foreign substance
7. 2. 5

Motor continues to operate at the start-up

Cause Checking
order
Foreign substance
7. 2. 6

Scanner is not recognized

Cause Checking
order
USB Driver
USB Cable
DC Power Supply
Main PCB
Checking
1 Is there any foreign substance under
Upper Unit?
Checking
1 Is there any foreign substance under
Upper Unit, which blocks the light of
sensor?
Checking
1 Does the PC recognize USB?
2 Is there any problem with the USB
cable, such as breakage, short-circuit
and damage of connector pin?
3 Is the DC Power Supply on the printer
part normal?
4 Prepare another PC which can
recognize USB Scanner. correctly
Does this PC recognize the KIP 600?
Result
Yes
Result
Yes
Result
1
Yes
No
No
7-5
Treatment
Remove it.
Treatment
Remove it.
Treatment
Check the USB Driver in
Device Manager.
Replace the USB Cable.
Replace DC Power Supply.
Replace Main PCB.
