Baxton Studio Louetta SW 8591-F Assembly Instruction Manual

SW 8591 - F/Q/K
1.
E
C
2.
C
3.
4.
F
E
Attach the footboard post (P4)
to the rail (P5).
You will need to use hardware:
C = 2pcs
E = 4pcs
G = 1pc
Attach the headboard lower post
(P3) to the rail (P5).
You will need to use hardware:
C = 2pcs
E = 4pcs
G = 1pc
E
D
H
A
G
J
BACK VIEW
After that, attach the side rail
(P6) to the rail (P5) using
hardware:
D = 8pcs
H = 1pc
Attach the headboard panel
(P1) to the headboard upper
post (P2) using hardware:
A = 6pcs
E = 4pcs
F = 6pcs
G = 1pc
J = 6pcs
WARNING!!
· Remove hardware from box and sort by size.
· Please check to see that hardware and parts are
present prior start of assembly.
· Please follow attached instruction in the same
sequence numbered to ensure fast and
easy assembly.
· Do not use this bed if any part is broken,torn
or missing.
· The assembly of this product requires two
people.
· Do not use any power tools as this may damage
the frame and will invalidate any claim.
PART LIST
P1 Headboard Panel
P2 Headboard Upper Post
P3 Headboard Lower Post
P4 Footboard Post
P5 Rail
P6
Side Rail
P7 Center Rail
Support Leg
P8
P9 Bed Slats
HARDWARE LIST
A
M6 X 80MM JCBC
B
M6 X 50MM JCBC
C
M6 X 60MM JCBC
D
M8 X 16MM JCBB
E
M8 X 30MM WOOD DOWEL
F
M6 X 13MM BARREL NUT
G
ALLEN KEY M4
H
ALLEN KEY M5
I
M4 X 25MM SCREW
J
WOODEN BUTTON PLUG
K
ADJUSTER
REV_26/10/2023
= 1pc
= L-1pc
= R-1pc
= L-1pc
= R-1pc
= 2pcs
= 2pcs
= L-1pc
= R-1pc
= 1pc
= 2pcs
= 14pcs
= 6pcs
= 6pcs
= 8pcs
= 8pcs
= 12pcs
= 6pcs
= 1pc
= 1pc
= 14pcs
= 14pcs
= 2pcs
SW 8120 Q / K
