SW 8588 - F/Q/K
1.
B
D
E
D
B
2.
D
B
3.
Attach the footboard post (P5)
to the footboard panel (P4)
using hardware:
B = 4pcs
D = 2pcs
E = 1pc
E
C
F
Attach the headboard post (P3)
to the headboard panel (P1)
and headboard bottom rail(P2)
using hardware:
B = 6pcs
D = 8pcs
E = 1pc
Attach the side rail (P6) to the
headboard post (P3) and
footboard post (P5) using
hardware:
C = 8pcs
F = 1pc
WARNING!!
· Remove hardware from box and sort by size.
· Please check to see that hardware and parts are
present prior start of assembly.
· Please follow attached instruction in the same
sequence numbered to ensure fast and
easy assembly.
· Do not use this bed if any part is broken,torn
or missing.
· The assembly of this product requires two
people.
· Do not use any power tools as this may damage
the frame and will invalidate any claim.
PART LIST
Headboard Panel
P1
P2 Headboard Bottom Rail
Headboard Post
P3
Footboard Panel
P4
Footboard Post
P5
P6
Side Rail
Center Rail
P7
P8
Bed Slats
P9
Support Leg
HARDWARE LIST
A
M6 X 50MM JCBC
B
M6 X 30MM JCBC
C
M8 X 20MM JCBB
D WOOW DOWEL M8X30MM
ALLEN KEY M4
E
ALLEN KEY M5
F
G
M4 X 25MM SCREW =
H ADJUSTER
= 1pc
= 1pc
= L-1pc
= R-1pc
= 1pc
= L-1pc
= R-1pc
= 2pcs
= 1pc
= 14pcs
= 2pcs
= 2pcs
= 10pcs
= 8pcs
= 10pcs
= 1pc
= 1pc
14pcs
= 2pcs
