DESCRIPTION

General description

1
2
3
4
5
6

1 Hob

2 Control panel
3 Oven light
4 Seal
Hob
Outer diameter
Zone
(mm)
1 210
2 180
3 270
4 180
91477B116/C
5
4
3
2
1
2
1
Pan minimum Ø
(mm)
120
110
145
110
5 Door
6 Storage compartment
7 Fans
Frame shelf
4
3
5
Pan Ø
Max. power draw
shelf
(W)*
(mm)
210 2300
180 1300
270 2300
180 1300
7
5
4
3
3
2
1
Power draw in
Booster function
(W)*
3000
1400
3000
1400
DESCRIPTION - 39
