We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com
PRECAUTIONS
General safety instructions
Risk of personal injury
• WARNING: During use the
appliance and its accessible
parts become very hot. Keep
children well away from the
appliance.
• Protect your hands by wearing
oven gloves when moving food
inside the oven.
• Never try to put out a fire or
flames with water: Turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
91477B172/C
35
35
39
40
40
41
41
41
41
41
41
41
41
42
42
42
43
43
43
44
44
44
• This appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
• Children must not play with the
appliance.
• Keep children under the age of
45
45
45
46
48
49
50
50
50
51
51
52
53
54
55
55
58
59
60
63
64
PRECAUTIONS - 35
Advertisement
Related Manuals for Smeg TR90GPP
Summary of Contents for Smeg TR90GPP
-
Page 1: Table Of Contents
Instructions for the installer Preliminary operations We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com PRECAUTIONS General safety instructions • This appliance may only be... - Page 2 eight at a safe distance unless the flames, for example with a they are constantly supervised. lid or a blanket. • Keep children under the age of • The appliance becomes very 8 away from the appliance hot during use. Take care never when it is in use.
- Page 3 COMPARTMENT (IF • If the power cable becomes AVAILABLE) OR NEAR THE damaged, contact technical APPLIANCE. support immediately to arrange • DO NOT USE AEROSOLS IN for it to be replaced in order to THE VICINITY OF THIS avoid possible hazards. APPLIANCE WHILST IT IS IN •...
- Page 4 inserted as far as they will go model) by placing it on the into the side guides. The bottom as a support for mechanical safety locks that cooking. prevent them from being • If you wish to use greaseproof removed must face downwards paper, place it so that it will not and towards the back of the interfere with the hot air...
-
Page 5: Installation
dishwasher. hob. • Never use the oven door to • During the first pyrolytic cycle, lever the appliance into place unpleasant odours may occur when fitting. due to the normal evaporation • Avoid exerting too much of oily manufacturing pressure on the door when substances. -
Page 6: Appliance Purpose
particular attention to the compliance with electrical requirements regarding system safety standards. ventilation. • Use cables that can withstand • The settings for this appliance temperatures of at least 90°C. are shown on the gas setting • The tightening torque of the label. -
Page 7: Manufacturer's Liability
Technical data on the appliance's power Plastic packaging consumption in off/stand-by mode can be Danger of suffocation found at www.smeg.com under the page corresponding to the product in question. • Do not leave the packaging or any part of it Light sources unattended. -
Page 8: How To Read The User Manual
light sources. • This appliance contains light sources of efficiency class "G". How to read the user manual This user manual uses the following reading conventions: Warning/Caution • The light sources contained in the appliance are declared suitable for operation at ambient temperature ≥300°C and intended Information/Advice for use in high temperature applications such... -
Page 9: Hob
AUX = Auxiliary Burner UR2 int = Internal Ultra Rapid Burner SR = Semi-rapid Burner UR2 ext = External Ultra Rapid Burner R = Rapid Burner Control panel 1 Function knob programmed cooking operations and the minute minder timer. The oven’s various functions are suitable for different cooking methods. -
Page 10: Accessories
the rack above. been turned off. Tray rack Do not obstruct ventilation openings and heat dispersal slots. Interior lighting The appliance’s interior lighting comes on: • When the door is opened. • When any function is selected, apart from function. Useful for supporting containers with food When the door is open, it is not possible during cooking. -
Page 11: Using The Accessories
Using the accessories Wait a few moments and repeat the operation. Keep the knob pressed in longer. Racks and trays In case of an accidental switching off, a Racks and trays have to be inserted into the side safety device will be tripped, cutting off guides until they come to a complete stop. -
Page 12: Digital Programmer
2. Select the temperature using the CIRCULAIRE The heat is distributed quickly and temperature knob. uniformly. Suitable for all dishes, ideal Ensure that the programmer clock for cooking on multiple levels without shows the cooking duration symbol mixing smells or flavours. , otherwise it will not be possible to turn on the oven. - Page 13 6. Press the buttons at the same Ensure that the programmer clock time to reset the programmer clock. shows the cooking duration symbol , otherwise it will not be possible to It is not possible to set a cooking time of turn on the oven.
-
Page 14: Cooking Advice
Minute minder timer • Use a meat thermometer when roasting meat, or simply press on the roast with a The minute minder timer does not stop spoon. If it is hard, it is ready; if not, it needs the cooking operation but rather informs to be cooked for a few more minutes. -
Page 15: Cooking Information Table
Advice for defrosting and proving this way, the liquid from the defrosting food drains away from the food. • Place frozen foods without their packaging in a lidless container on the first shelf of the • The most delicate parts can be covered with oven. -
Page 16: Cleaning And Maintenance
Weight Temp. Time Food Function Shelf (Kg) (°C) (minutes) Tart CIRCULAIRE 35 - 40 Ricotta cake CIRCULAIRE 160 - 170 55 - 60 Jam tarts TURBO/CIRCULAIRE 20 - 25 Paradise CIRCULAIRE 55 - 60 cake Profiteroles TURBO/CIRCULAIRE 80 - 90 Sponge CIRCULAIRE 150 - 160... -
Page 17: Knobs
residues with a wooden toothpick or a needle. 2. Grasp the door on both sides with both hands, lift it so that it forms an angle of around 30° and remove it. 3. To reassemble the door, put the hinges in the relevant slots in the oven, making sure Knobs that grooved sections A are resting... -
Page 18: Cleaning The Oven Cavity
4. Remove the intermediate glass pane by down. lifting it upwards. Avoid letting food residue dry inside the oven cavity, as this could damage the enamel. Take out all removable parts before cleaning. For easier cleaning, it is recommended to remove: •... -
Page 19: Pyrolytic Function (On Some Models Only)
Removing self-cleaning panels and rack/tray the warnings on the product); leave for 60 support frames (on some models only) minutes, then rinse and dry the glass using kitchen roll or a microfibre cloth. Removing the side self-cleaning panels and the rack/tray support frames enables the sides to •... -
Page 20: Extraordinary Maintenance
lock lever might be inadvertently operated. shows the current time and the indicator light comes on. 2. Turn the temperature knob to set the time at which you wish to complete the pyrolytic cycle. 3. After a few seconds, the indicator lights remain on steadily and the appliance waits for the set start time to start the cleaning cycle. -
Page 21: Installation
Replacing the internal light bulb 4. Slide out and remove the light bulb. Power voltage Danger of electrocution • Unplug the appliance. • Wear protective gloves. 1. Completely remove all accessories from inside the oven. 2. Remove the rack/tray support frames. 3. - Page 22 with safety clamps B.S. 669. • No part of the hose is in contact with hot walls (max. 50 °C) • The hose is not under traction or tension and has no kinks or twists. • The hose is not in contact with sharp objects or sharp corners.
- Page 23 Connection to LPG issue a certificate of conformity. Use a pressure regulator and make the connection on the gas cylinder following the guidelines set out in the standards in force. The supply pressure must comply with the values indicated in the “Burner and nozzle characteristics table”.
-
Page 24: Gas Types And Countries
Replacing nozzles town gas Light the burner and turn it to the minimum position. Extract the gas cock knob and turn the adjustment screw next to the gas cock spindle (depending on the model) until the correct minimum flame is achieved. Refit the knob and verify that the burner flame is stable. -
Page 25: Burner And Nozzle Specifications Tables
Gas types 4 Natural Gas G2.350 13 mbar G2.350 • 5 LPG G30/31 28-30/37 mbar • • • • • • G30/31 30/30 mbar G30/31 • • • 6 LPG G30/31 37 mbar • G30/31 7 Town Gas G110 8 mbar G110 •... -
Page 26: Positioning
7 Town gas G110 – 8 mbar UR2 int. UR2 ext. Rated heating capacity (kW) 1.75 Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) (/8) (/2) (/3) Reduced power (W) 1000 The nozzles not provided are available at Authorised Service Centres. Positioning Appliance overall dimensions See General safety instructions. - Page 27 Appliance dimensions Assembling the upstand The upstand must always be positioned and secured correctly on the appliance. 1. Loosen the 6 screws (A) on the back of the hob using a screwdriver. 2. Place the upstand on the hob. 3. Align the slots of the upstand (B) with the screws (A).
- Page 28 3. Fasten the front skirting to the appliance Fastening to the wall using the previously removed screws. Installing the side plinth After installing the front skirting, the side skirting can be fastened correctly to the appliance. 1. Use a screwdriver to remove the front screws underneath the storage The symbols above indicate the danger if the compartment.
-
Page 29: Electrical Connection
5. Align the base of the fastening bracket with 9. Push the cooker towards the wall, and at the the ground and tighten the screws to fix the same time insert the bracket in the plate measurements. fastened to the rear of the appliance. 6. -
Page 30: Instructions For The Installer
3. Proceed with installation of the power The values indicated refer to the cross- supply cable. section of the internal conductor. The aforementioned power cables are sized taking into account the coincidence factor (in compliance with standard EN 60335-2-6). Fixed connection Fit the power line with an all-pole circuit breaker with a contact separation distance sufficient to provide complete disconnection in category III... - Page 31 contact your local Authorised Service Centre. • Once the appliance has been installed, please explain to the user how to use it correctly. 91477B172/C INSTALLATION - 65...
