Summary of Contents for Makita M9508B
- Page 1 INSTRUCTION MANUAL Angle Grinder M9506 M9507 M9508 DOUBLE INSULATION Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: M9506 M9507 M9508 Wheel diameter 100 mm 115 mm 125 mm Max. wheel thickness 4 mm 6.4 mm Spindle thread M14 or 5/8″ Rated speed (n)/ No load speed (n 11,000 min Overall length 261 mm Net weight 1.6 kg 1.9 kg Safety class... -
Page 3: General Power Tool Safety Warnings
Do not abuse the cord. Never use the cord for NOTE: The declared vibration total value(s) has been carrying, pulling or unplugging the power tool. measured in accordance with a standard test method Keep cord away from heat, oil, sharp edges and may be used for comparing one tool with another. -
Page 4: Grinder Safety Warnings
Store idle power tools out of the reach of chil- Do not use a damaged accessory. Before each dren and do not allow persons unfamiliar with use inspect the accessory such as abrasive the power tool or these instructions to operate wheels for chips and cracks, backing pad for the power tool. - Page 5 For example, if an abrasive wheel is snagged or Additional Safety Warnings: pinched by the workpiece, the edge of the wheel that is When using depressed centre grinding wheels, entering into the pinch point can dig into the surface of be sure to use only fiberglass-reinforced the material causing the wheel to climb out or kick out.
-
Page 6: Functional Description
FUNCTIONAL ASSEMBLY DESCRIPTION CAUTION: Always be sure that the tool is switched off and unplugged before carrying out CAUTION: Always be sure that the tool is any work on the tool. switched off and unplugged before adjusting or Installing side grip (handle) checking function on the tool. -
Page 7: Grinding Operation
Installing or removing depressed OPERATION center wheel WARNING: It should never be necessary to Optional accessory force the tool. The weight of the tool applies ade- quate pressure. Forcing and excessive pressure WARNING: When using a depressed center could cause dangerous wheel breakage. wheel, the wheel guard must be fitted on the tool so that the closed side of the guard always points WARNING:... -
Page 8: Maintenance
To maintain product SAFETY and RELIABILITY, repairs, carbon brush inspection and replacement, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always 15° using Makita replacement parts. Makita Corporation 3-11-8, Sumiyoshi-cho,...
