Exsys EX-1183HMVS-2W Manual

4-port usb 3.2 gen 1 metal hub with 1.5a power for each usb-port and 15kv esd surge protection
Hide thumbs Also See for EX-1183HMVS-2W:

Advertisement

Available languages

Available languages

Quick Links

Download this manual
4-Port USB 3.2 Gen 1 Metal HUB with
1.5A power for each USB-Port and
Manual
Manual
EX-1183HMVS-2W
HUB USB 3.2 Gen 1 a 4 porte con
alimentazione da 1,5 A per ciascuna
porta USB e protezione da
sovratensione ESD da 15 KV
15KV ESD Surge Protection
Manuale
Germania:
EXSYS Vertriebs GmbH
Industriestraße 8
61449 Steinbach
www.exsys.de
Svizzera:
EXSYS Vertriebs GmbH
Dübendorfstrasse 17
8602 Wangen
www.exsys.ch
Italia:
EXSYS Italia S.r.l
Via Belvedere, 45/B
22100 Como (CO)
www.exsys.it
Vers. 1.2 / 08.02.24

Advertisement

loading
Need help?

Need help?

Do you have a question about the EX-1183HMVS-2W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Exsys EX-1183HMVS-2W

Summary of Contents for Exsys EX-1183HMVS-2W

  • Page 1 1,5 A per ciascuna porta USB e protezione da sovratensione ESD da 15 KV Germania: 4-Port USB 3.2 Gen 1 Metal HUB with EXSYS Vertriebs GmbH Industriestraße 8 1.5A power for each USB-Port and 61449 Steinbach www.exsys.de 15KV ESD Surge Protection...
  • Page 2 Disegno tecnico Index Description Extent of Delivery Layout, Connections & Jumper Settings 10-12 3.1 Layout 3.2 Connections 10-11 3.3 Jumper Settings Hardware Installation Driver Installation Cleaning Technical Information Technical Drawing © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved...

  • Page 3: Contenuto Confezione

    1. Descrizione L'EX-1183HMVS-2W è un HUB USB 3.2 Gen 1 in struttura in metallo per un massimo di 4 dispositivi. L‘Hub è dotato di 4 porte per dispositivi periferici e 1 porta per il collegamento al PC. Supporta tutte le porte USB da 1.1 a 3.2.
  • Page 4 Upstream Type-B 3.2 Attacchi +7 ~48V T-Block +7V a +48V : ATTENZIONE!!! Non collegare mai l'alimentazione (+) a terra GND, questo potrebbe distruggere il tuo hardware!!! GND (Ground) +7V / 48V © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved...
  • Page 5 Non inserire mai la spina al contrario né forzarla. USB 3.2 Gen 1 Type-B: GND_DRAIN StdB_SSTX + StdB_SSTX+ Attenzione! StdB_SSTX - StdB_SSTX - Non inserire mai la spina al contrario né forzarla. VBus © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved...
  • Page 6 Le possibili impostazioni ed i loro effetti sono mostrati nella tabella seguente. Standard: Impostazione Stato Funzione JP1 = ENA Jumper JP1 Jumper JP2 Alimentatore Host PC Hub Downstream JP2 = ON Bus Power Host control Dati Power HOST HOST DIS/ENA HOST/ON © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved...

  • Page 7: Installazione Hardware

    Nella zona dei collegamenti, assicurarsi che non rimangano fibre del panno nella presa. Non utilizzare in nessun caso un panno umido o bagnato per la pulizia! © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved...

  • Page 8: Dati Tecnici

    Temp. Di conservazione : -20° a 85° Celsius Umidità Rel. 5% a 95% Alimentazione: +7 a +48 Volt Dimensione: 178.50 x 69.30 x 23.00 mm Peso: 815 g 8. Disegno Tecnico © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved...

  • Page 9: Extent Of Delivery

    English 1. Description The EX-1183HMVS-2W is a plug & play high-speed USB 3.2 Gen 1 metal hub for 4 USB devices. The EX-1183HMVS-2W provides 4 ports for USB devices and 1 uplink port for PC. It supports all USB connections from 1.1 to 3.2. All ports can fix with screw lock. Through the power supply via the Terminal Block or the DC-Connector, 1,5A can be provided at each USB port.
  • Page 10 Upstream B-Port Power Supply Power Supply 3.2 Connections +7 ~48V +7V to +48V T-Block: ATTENTION!!! Never connect power (+) to GND, it will destroy your Hardware!!! GND (Ground) +7V - 48V © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved...
  • Page 11 Never plug in with force or in wrong direction. USB 3.2 Gen 1 B-Port: GND_DRAIN StdB_SSTX+ StdB_SSTX + StdB_SSTX - StdB_SSTX - Attention! Never plug in with force VBus or in wrong direction. © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved...

  • Page 12: Jumper Settings

    The possible settings and their effects are shown in the following table. Default: Settings Status Function JP1 = ENA Jumper JP1 Jumper JP2 Netzteil Host PC Hub Downstream JP2 = ON Bus Power Host control Data Power HOST HOST DIS/ENA HOST/ON © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved...

  • Page 13: Hardware Installation

    For cleaning please use only a dry fluff less cloth and remove the dirt with gently pressure. In the area of the connectors please make sure that no fibres from the cloth remain in the connectors. Attention! Never use a moist or wet cloth for cleaning! © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved...

  • Page 14: Technical Information

    32°F to 131°Fahrenheit Storage Temperature: -40°F to 185°Fahrenheit Rel. Humidity: 5% to 95% Power: +7 to +48 Volt Size: 178.50 x 69.30 x 23.00 mm Weight: 815g 8. Technical Drawing © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved...
