Omron F3SP-U4P-TGR Datasheet

Muting Controller for Safety Light Curtain
F3SP-U4P
● High functionality
(two independent muting
functions, override function,
automatic and manual reset).
● Category 2 or 4 depending on
safety light curtain.
● Only 45 mm width
● Double output safety relay.
● 6 LED for status and diagnostics.
● Detachable terminals for easy
installation.
● Controlls 1 or 2 safety light curtains
● TÜV approved
List of Models
Controller
Description
Muting Controller for Safety Light Curtain F3S-B, F3SN and F3SH
Accessories
Description
Muting lamp
Rating / performance
Power supply voltage
Power consumption
Output contacts
Indicators
Enclosure rating
Terminal
Response time
Ambient temperature
Housing material
Weight
F3SP-U4P
Muting controller for one or two Safety
Light Curtain.
F3SP-U4P-TGR
24 VDC ±10%
420 mA max. (excl. SLC power consumption)
2 NO 2,5 A (protected by fuse)
6 LEDs for status and diagnostics.
IP20
32 screw terminals (1,5 mm²), detachable blocks with 4 screws each
≤ 30 ms
Operating: -10 °C +55 °C
Plastic, DIN rail mounting
0,6 kg
Functional
Safety
Model
F3SP-U4P-TGR
Model
F39-A11
G-73
