The Wayback Machine - https://web.archive.org/web/20000615020558/http://www.toshiba.com:80/taecdpd/techdocs/67...
Technical Documentation |User's Guide
Back to Contents Page
Toshiba XM-6702B CD-ROM
Introduction
General Features | Drive Speed | BUS Interface | Disc Formats | Front Panel
General Features
Tray Loading Mechanism
3-way Disc Eject (eject button, software, emergency eject hole)
78ms Average Access Time
DAE (Digital Audio Extraction) Audio Capability
MPC3 and Photo-CD Multisession Compatibility
Headphone Output Volume Control
Supports CD-RW Play (speeds 6 - 14X)
top of page
Drive Speed
48X
BUS Interface
ATAPI
top of page
Types of Disc Formats Supported
Red-Book
Yellow-Book
CD-ROM-XA
CD-I Bridge (Photo-CD, Video CD)
CD-I
CD-I Ready
CD-G
Multi-session (Photo-CD, CD Extra, CD-RW, CD-R)
CD-TEXT
top of page
Front Panel
Figure 1.XM-6702B CD-ROM Front Panel

Advertisement

loading
Need help?

Need help?

Do you have a question about the XM-6702B and is the answer not in the manual?

Questions and answers

Related Manuals for Toshiba XM-6702B

Summary of Contents for Toshiba XM-6702B

  • Page 1 BUS Interface ATAPI top of page Types of Disc Formats Supported Red-Book Yellow-Book CD-ROM-XA CD-I Bridge (Photo-CD, Video CD) CD-I CD-I Ready CD-G Multi-session (Photo-CD, CD Extra, CD-RW, CD-R) CD-TEXT top of page Front Panel Figure 1.XM-6702B CD-ROM Front Panel...
  • Page 2 Eject The EJECT button is used to open the disc tray so you can install or remove a disc. Button Busy When you install a disc into the CD-ROM drive, the BUSY light flashes slowly as it attempts Indicator to locate the disc. One of the following will occur: BUSY light goes out.
  • Page 3 Remove computer cover and faceplate if required. Refer to your computer system’s manual for removal information. Your Toshiba CD-ROM can be placed in any free half-height drive slot at the front of your computer. (It can be mounted horizontally or vertically.) Carefully start sliding the CD-ROM into the opening with the disc tray facing the front of the computer.
  • Page 4 Figure 6.Mounting Illustration Software Driver - Toshiba’s CD-ROM Drive is "plug n’ play". In Windows, when you apply power to your computer and boot-up, the system will recognize new hardware, and begin installing Window’s ATAPI driver. If you prefer using DOS, download the ATAPI driver from our web site.
  • Page 5 top of page...

  • Page 6: Using The Cd-Rom Drive

    The Wayback Machine - https://web.archive.org/web/20000831170408/http://www.toshiba.com:80/taecdpd/techdocs/67… Technical Documentation |User's Guide Back to Contents Page Toshiba XM-6702B CD-ROM User's Guide Using the CD-ROM Drive Drive Operation | Usage Guidelines | Emergency Ejection | Cleaning CDs | Cleaning the Drive Drive Operation Inserting a CD - Horizontally To insert a CD in a CD-ROM drive that is mounted horizontally, perform the following steps: Figure 1.Inserting CD...
  • Page 7 If the disc becomes dirty wipe it with a damp soft cloth. Avoid cleaning in a circular motion, but rather from the inner side outward. Cleaning the Drive Toshiba does not recommend cleaning the drive. top of page...

  • Page 8: Troubleshooting

    The Wayback Machine - https://web.archive.org/web/20000831170418/http://www.toshiba.com:80/taecdpd/techdocs/67… Toshiba XM-6702B CD-ROM User's Guide Troubleshooting Problem Solution Disc tray cannot be opened Check that there is power to CD-ROM Use Emergency Eject instructions to open tray. Drive is not recognized by system Is the CD-ROM drive connected properly? Are all cables plugged in properly.

  • Page 9: Specifications

    The Wayback Machine - https://web.archive.org/web/20000711065536/http://www.toshiba.com:80/taecdpd/techdocs/67… Toshiba XM-6702B CD-ROM Specifications General | Performance | Reliability | Audio | Environmental | Power | Physical | Connectors | Regulatory General Interface ATAPI Compatible CD-ROM Standards Red-Book Photo CD CD-EXTRA Yellow-Book Video CD CD-RW (Read)
  • Page 10 0.46m max. length Analog Audio Line Output Connector 4 Pin ATAPI Standard 3m max. top of page Regulatory The XM-6702B CD-ROM has been certified by the following regulatory agencies: UL 1950 EN60950 CAN/CSA-22.2 No.950 FCC 15J-B DHHS (Laser) EN60825-1, FDA 21CFR...
  • Page 11 CAUTION: Severe damage to the CD-ROM circuits may occur if power cable is plugged in upside-down with power ON. Audio Supplies Analog sound to your system. Connectors ATAPI The XM-6702B CD-ROM is connected to your computer system through the ATAPI connector. Connector top of page Table 1.ATAPI Interface Pin Assignments INTERFACE PIN ASSIGNMENT SIGNAL...
  • Page 12 DD12 Host Data Bus BIT IOCS16- Host 16 BIT I/O Host Data Bus BIT Host Address Bus BIT 1 DD13 Host Data Bus BIT PDIAG- Passed Diagnostics Host Data Bus BIT Host Address Bus BIT 0 DD14 Host Data Bus BIT Host Address Bus BIT 2 Host Data Bus BIT CS1FX...
