- Page 1 Operating Instructions Transponder-Coded Safety Switch with Guard Locking CTM-LBI-BP/BR Unicode/Multicode with Control of Guard Locking via Control Input IMP...
-
Page 2: Table Of Contents
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR Contents About this document ..................... 4 1.1. Scope ............................4 1.2. Target group ..........................4 1.3. Key to symbols ..........................4 1.4. Supplementary documents ......................4 Correct use ......................5 Description of the safety function ................6 Exclusion of liability and warranty ................. 8 General safety precautions ................... - Page 3 Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR Connection of a single CTM-BP/BR (separate operation) ........19 Connection of several devices in a chain (series connection) ........ 21 11.1. Series connection with wiring in the control cabinet .................21 11.2. Series connection with Y-distributors ....................21 11.2.1.
-
Page 4: About This Document
These operating instructions are not valid for safety switches CTM-LBI-BP/BR-..-..D-… with control of guard locking via IO- Link. The MAN20001661 operating instructions are valid for these devices. Important! Make sure to use the operating instructions valid for your product version. Please contact the EUCHNER support team if you have any questions. 1.2. -
Page 5: Correct Use
EN 60204-1 Ì The safety switch is allowed to be operated only in conjunction with the intended EUCHNER actuators and the related con- nection components from EUCHNER. If different actuators or other connection components are used, EUCHNER provides no warranty for safe function. -
Page 6: Description Of The Safety Function
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 3. Description of the safety function Devices from this series feature the following safety functions: Monitoring of guard locking and the position of the guard (interlocking device with guard locking according to EN ISO 14119) Safety function (see chapter 6.5. Switching states on page 11): Ì... - Page 7 Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR Control of guard locking for variants with IMP/IMM connection If the device is used as guard locking for personnel protection, control of guard locking must be regarded as a safety function. The safety level of guard locking control is determined by the device PFH D and by the external control (e.g.
-
Page 8: Exclusion Of Liability And Warranty
Prior to use, read the operating instructions and keep these in a safe place. Ensure the operating instructions are always available during mounting, setup and servicing. You can download the operating instructions from www.euchner.com. (translation of the original operating instructions) 2525462-07-04/24... -
Page 9: Function
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 6. Function The device permits the locking of movable guards. Safety switch The system consists of the following components: coded actuator (transponder) and switch. Transponder-coded actuator Whether the device learns the complete actuator code (unicode) or not (multicode) depends on the respective version. -
Page 10: Guard Locking Signal Ol
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 6.3.3. Guard locking signal OL The guard locking signal is present if the guard locking is active. 6.3.4. Status signal OM The status signal is present if the device’s safety outputs are switched. 6.3.5. Locking element signal OLS The locking element signal is present if the locking element is stuck and guard locking cannot be released. -
Page 11: Switching States
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 6.5. Switching states The detailed switching states for your switch can be found in chapter 15. Status and error messages on page 29. All safety outputs, signals and display LEDs are described there. Guard closed and locked Guard closed and not locked Guard being opened Guard open... -
Page 12: Manual Release
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 7. Manual release Important! All release functions latch when the device is electrically isolated. Ì Guard locking remains released when the release function is reset. Ì Some situations require the guard locking to be released manually (e.g. malfunctions or an emergency). A function test must be performed after release. -
Page 13: Mounting
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 8. Mounting CAUTION Safety switches must not be bypassed (bridging of contacts), turned away, removed or otherwise rendered ineffective. Observe EN ISO 14119:2013, section 7, for information about reducing the possibilities for bypassing Ì an interlocking device. NOTICE Risk of damage to equipment and malfunctions as a result of incorrect installation. -
Page 14: Electrical Connection
Observe the EMC instructions in the manuals from the respective manufacturer. Important! If the device does not appear to function when the operating voltage is applied (e.g. the green STATE LED does not flash), the safety switch must be returned to EUCHNER. (translation of the original operating instructions) 2525462-07-04/24... -
Page 15: Notes About
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 9.1. Notes about Important! This device is intended to be used with a Class 2 power source in accordance with UL1310. Ì As an alternative an LV/C (Limited Voltage/Current) power source with the following properties can be used: This device shall be used with a suitable isolating source in conjunction with a fuse in accordance with UL248. -
Page 16: Requirements For Connecting Cables
Risk of damage to equipment or malfunctions as a result of incorrect connecting cables. Use connection components and connecting cables from EUCHNER. Ì If other connection components are used, the requirements in the following table apply. EUCHNER Ì provides no warranty for safe function in case of failure to comply with these requirements. -
Page 17: Connector Assignment/Terminal Assignment Of Safety Switches Ctm
Electronics and solenoid operating voltage, 0 V DC Solenoid control input, 24 V DC 1) Only for standard EUCHNER connecting cable 2) Monitoring output Ox can assume the function OD (door position) or OL (guard locking). More detailed information about your device is available at www.euchner.com. -
Page 18: Notes On Operation With Safe Control Systems
With series connection: always connect inputs FI1A and FI1B directly to a power supply unit or to outputs FO1A and FO1B Ì of another EUCHNER BR device. Pulsed signals must not be present at inputs FI1A and FI1B. A detailed example of connecting and setting the parameters of the control system is available for many devices at www.euchner.com, in the area Downloads/Applications/CTM. -
Page 19: Connection Of A Single Ctm-Bp/Br (Separate Operation)
The user is responsible for safe integration into the overall system. Detailed application examples can be found at www.euchner.com. Simply enter the order number of your switch in the search box. You will find all available connection examples for the device in Downloads. - Page 20 Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 24V DC 24V DC Actuator Monitoring Outputs Read Head Door Monitoring Diagnostic Safety Outputs OD/C FO1A FO1B Connected load BR evaluation via PLC Fig. 2: Connection example with control input IMM (principle of operation) (translation of the original operating instructions) 2525462-07-04/24...
-
Page 21: Connection Of Several Devices In A Chain (Series Connection)
The user is responsible for safe integration into the overall system. Detailed application examples can be found at www.euchner.com. Simply enter the order number of your switch in the search box. You will find all available connection exam- ples for the device in Downloads. -
Page 22: Maximum Cable Lengths With Br Switch Chains
FO1A/FO1B individual switches 0.34 mm² Contact EUCHNER in the following cases: If you connect more than 3 switches in series. Ì If you plan to use a different cable design (cross-section, material, etc.) Ì... -
Page 23: Connector Assignment Of Y-Distributor For Series Connection Without O-Link Communication
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 11.2.3. Connector assignment of Y-distributor for series connection without O-Link communication Important! The switch chain must always be terminated with strapping plug 097645. Ì All guard locking solenoids are always controlled simultaneously on the use of these Y-distributors in a Ì... - Page 24 Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR Fig. 3: Connection example for series connection with control of guard locking via control input IMP (principle of operation) (translation of the original operating instructions) 2525462-07-04/24...
-
Page 25: Using Communication Data
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 12. Using communication data A BR/IO-Link Gateway is required to use the device’s communication data and forward them to a higher-level bus system. The following devices are suitable: GWY-CB-1-BR-IO (BR/IO-Link Gateway) Ì ESM-CB (safety relay with integrated BR/IO-Link Gateway) Ì... -
Page 26: Acyclical Data (Device Data And Events)
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 12.3.2. Acyclical data (device data and events) After one of the commands listed below is sent, the requested data are provided via the IO-Link Gateway. The reply message always consists of 8 bytes in big endian format. Example: reply message in response to the command Send device ID number/serial number: 06 02 77 67 00 01 17 00 In this example, the device’s ID number is 161639 and its serial number is 279. -
Page 27: Setup
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 13. Setup 13.1. Teaching-in actuator (only for unicode evaluation) The actuator must be allocated to the safety switch using a teach-in function before the system forms a functional unit. During a teach-in operation, the safety outputs are switched off, i.e. the system is in the safe state. The teach-in operation starts automatically after the operating voltage is switched on. -
Page 28: Functional Check
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 13.2. Functional check WARNING Danger of fatal injury as a result of faults in installation and the functional check. Before carrying out the functional check, make sure that there are no persons in the danger area. Ì... -
Page 29: Status And Error Messages
LOCK yellow STATE LOCK Important! If you do not find the displayed device status in the following tables, this indicates an internal device fault. Contact EUCHNER. LED not illuminated LED illuminated 1 x LED illuminated, briefly goes off 1 x inverse... -
Page 30: Status Messages
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 15.2. Status messages LED indicator Safety Door outputs Guard position FO1A/ locking Status STATE LOCK signal FO1B signal OL green yellow Self-test after operating voltage is switched on. 5 Hz (5 s) No communication with the BR/IO-Link Gateway. quickly Door is closed and locked. -
Page 31: Error Messages
0x62 Observe the specified temperature range (see chapter 16. Technical data on page 33). Device temperature too low. 0x63 Internal fault Restart the device. On repeated occurrence, contact 0x01 Internal device fault EUCHNER. 2525462-07-04/24 (translation of the original operating instructions) -
Page 32: Acknowledging Error Messages
Via the acyclical data of IO-Link communication page 26 Reset for acknowledging error messages does not delete the configuration. Important! Contact EUCHNER if the fault display is not reset after briefly disconnecting the power supply. (translation of the original operating instructions) 2525462-07-04/24... -
Page 33: Technical Data
1 x 10 operating cycles Ambient temperature at U = 24 V °C Actuator approach speed m/min Actuating/extraction/retention force Device dependent, see www.euchner.com Locking force F 1,300 Locking force F /1.3 = 1,000 Weight Approx. 0.16 Connection (depending on version) 1 plug connector M12, 8-pin/1 plug connector M12, 12-pin/connecting cable with flying lead, 5 m, 8 x 0.25 mm²... -
Page 34: Typical System Times
This can usually be set up in the control systems by parameter assignment. If parameter assignment is not possible for your control system or if shorter test pulses are required, contact the EUCHNER support team. The test pulses are output only if the safety outputs are switched on. -
Page 35: Radio Frequency Approvals
Supplier‘s Declaration of Conformity 47 CFR § 2.1077 Compliance Information Unique Identifier: CTM-LBI-BR series CTM-IBI-BR series CTM-CBI-BR series CTM-L2-BR series CTM-I2-BR series CTM-C2-BR series CTM-LBI-BP series CTM-IBI-BP series CTM-CBI-BP series CTM-L2-BP series CTM-I2-BP series CTM-C2-BP series CTM-L2-AS1B series CTM-I2-AS1B series CTM-LBI-AS1B series CTM-IBI-AS1B series Responsible Party –... -
Page 36: Dimension Drawing For Safety Switch Ctm
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 16.3. Dimension drawing for safety switch CTM… Necessary minimum travel + perm. overtravel Necessary minimum travel (h ) + Actuator Length (L) Total travel (t) permissible overtravel (h A-B-A1-… 21 + 2 A-B-A5-… 21 + 2 With plug connector M12 ∅ 4.5 (2x) for M4 screw... -
Page 37: Technical Data For Actuator A-B-A1-A1
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 16.4. Technical data for actuator A-B-A1-A1-… Value Parameter Unit min. typ. max. Material - Housing Ultradur black - Ball holder Stainless steel - Elastomer Fluorinated rubber (FKM) Resistance Resistant to chemicals and oil Food safe DIN EN 1672-2, EN ISO 14159, PAH category 3 Weight 0.0194... -
Page 38: Technical Data For Actuator A-B-A5-A1
Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR 16.5. Technical data for actuator A-B-A5-A1-… Value Parameter Unit min. typ. max. Material - Housing Ultradur black - Ball holder Stainless steel - Elastomer Resistance Resistant to chemicals and oil Weight 0.0194 Ambient temperature °C Degree of protection IP65/IP67/IP69/IP69K... -
Page 39: Ordering Information And Accessories
20. Declaration of conformity The product complies with the requirements according to Machinery Directive 2006/42/EC. The EU declaration of conformity can be found at www.euchner.com. Enter the order number of your device in the search box. The document is available under Downloads. - Page 40 Edition: 2525462-07-04/24 Title: Operating Instructions Transponder-Coded Safety Switch CTM-LBI-BP/BR (translation of the original operating instructions) Copyright: © EUCHNER GmbH + Co. KG, 04/2024 Subject to technical modifications; no responsibility is accept- ed for the accuracy of this information.
