We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com

PRECAUTIONS

General safety instructions

Risk of personal injury
• WARNING: During use the
appliance and its accessible
parts become very hot. Keep
children well away from the
appliance.
• Protect your hands by wearing
oven gloves when moving food
inside the oven.
• Never try to put out a fire or
flames with water: Turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
30 - PRECAUTIONS
30
30
34
35
35
35
35
35
36
36
36
36
36
37
37
37
38
38
38
39
39
• This appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
• Children must not play with the
appliance.
• Keep children under the age of
eight at a safe distance unless
39
39
40
41
41
42
43
43
44
44
44
46
46
47
47
47
51
51
52
54
55
914779902/B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CO96GMA9 and is the answer not in the manual?

Questions and answers

Summary of Contents for Smeg CO96GMA9

  • Page 1: Table Of Contents

    Preliminary operations Instructions for the installer We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com PRECAUTIONS General safety instructions • This appliance may only be...
  • Page 2 they are constantly supervised. lid or a blanket. • Keep children under the age of • The appliance becomes very 8 away from the appliance hot during use. Take care never when it is in use. to touch the heating elements •...
  • Page 3 AVAILABLE) OR NEAR THE damaged, contact technical APPLIANCE. support immediately to arrange • DO NOT USE AEROSOLS IN for it to be replaced in order to THE VICINITY OF THIS avoid possible hazards. APPLIANCE WHILST IT IS IN • WARNING: A gas cooking USE.
  • Page 4 into the side guides. The bottom as a support for mechanical safety locks that cooking. prevent them from being • If you wish to use greaseproof removed must face downwards paper, place it so that it will not and towards the back of the interfere with the hot air oven.
  • Page 5: Installation

    • Never use the oven door to ventilation. lever the appliance into place • The settings for this appliance when fitting. are shown on the gas setting • Avoid exerting too much label. pressure on the door when • Have the gas connection open.
  • Page 6: Appliance Purpose

    • Use cables that can withstand equipped with an updated version of the system, and as such, all that appears on the temperatures of at least 90°C. display may differ from those in the manual. • The tightening torque of the Manufacturer’s liability screws of the terminal supply The manufacturer declines all liability for...
  • Page 7: Information For European Control Bodies

    light sources. Plastic packaging Danger of suffocation • Do not let children play with the plastic bags. Information for European Control Bodies • The light sources contained in the appliance Fan forced mode are declared suitable for operation at the ECO function used to define the energy ambient temperature ≥300°C and intended efficiency class complies with the specifications for use in high temperature applications such...
  • Page 8: Description

    DESCRIPTION General description 1 Upstand 6 Door 2 Hob 7 Fans 3 Control panel 8 Storage compartment 4 Inside lights Frame shelf 5 Seal AUX = Auxiliary Burner SR = Semi-rapid Burner R = Rapid Burner UR-3c = Triple crown ultra-rapid burner 914779902/B DESCRIPTION - 37...
  • Page 9: Control Panel

    Control panel 1 Hob burner knobs the appliance and which may continue for a brief period of time even after the appliance has For lighting and adjusting the hob burners. Press been turned off. and turn the knobs anti-clockwise to order to light the relative burners.
  • Page 10: Use

    Rack Deep tray To be placed over the top of the oven tray; for Useful for collecting fat from foods placed on cooking foods which may drip. the rack above. Preliminary operations the oven cavity. See General safety instructions. • Remove any protective film from the outside or inside of the appliance, including accessories.
  • Page 11: Using The Storage Compartment (Where Present)

    the burner does not light in the first 15 seconds, Using the storage compartment (where present) turn the knob to and wait 60 seconds before trying again. After lighting, keep the knob pressed in for a few seconds to allow the See General safety instructions.
  • Page 12: Analogue Programmer

    GRILL Analogue programmer Produces excellent grilling and gratinating results. When used at the end of cooking, gives a uniform browning to dishes. FAN WITH GRILL Allows optimal grilling, even for thick slices of meat. Perfect for larger cuts of meat. FAN ASSISTED A Setting knob Intense and uniform cooking.
  • Page 13: Cooking Information Table

    • Use a meat thermometer when roasting longer cooking time if necessary. meat, or simply press on the roast with a Advice for cooking on two shelves: spoon. If it is hard, it is ready; if not, it needs • We recommend using two racks (they can to be cooked for a few more minutes.
  • Page 14: Cleaning And Maintenance

    Weight Temp. Time Food Function Shelf (Kg) (°C) (minutes) Roast pork 2 - 3 TURBO/CIRCULAIRE 180 - 190 170 - 180 neck Roast TURBO/CIRCULAIRE 180 - 190 65 - 70 chicken surface 2 surface Pork chops FAN WITH GRILL Spare ribs FAN WITH GRILL Bacon GRILL...
  • Page 15: Cleaning The Hob

    Ordinary daily cleaning residues with a wooden toothpick or a needle. Always and only use specific products that do not contain abrasives or chlorine-based acids. Pour the product onto a damp cloth and wipe the surface, rinse thoroughly and dry with a soft cloth or a microfibre cloth.
  • Page 16 2. Grasp the door on both sides with both 3. Pull the rear part of the internal glass pane hands, lift it forming an angle of around 30° gently upwards, following the movement and remove it. indicated by the arrows (1). 3.
  • Page 17: Cleaning The Oven Cavity

    Cleaning the oven cavity solution inside the oven using a spray nozzle. Direct the spray towards the side In order to keep your oven in the best possible walls, upwards, downwards and towards condition, clean it regularly after letting it cool the deflector.
  • Page 18: Extraordinary Maintenance

    We recommend removing the door in Take care not to scratch the enamel of order to make the manual cleaning of the oven cavity wall. the parts that are difficult to reach easier. 4. Slide out and remove the light bulb. Extraordinary maintenance Seal maintenance tips The seal should be soft and elastic.
  • Page 19 Connection with a rubber hose standard is stamped on the hose). ü ü Verify that all following conditions are met: Carefully screw the hose connector 3 onto the appliance’s gas connector 1 (½” thread ISO • The hose is attached to the hose connector 228-1), placing the seal 2 between them.
  • Page 20 B.S. 669. Connection to LPG Use a pressure regulator and make the connection on the gas cylinder following the guidelines set out in the standards in force. The supply pressure must comply with the values indicated in the “Burner and nozzle characteristics table”.
  • Page 21 issue a certificate of conformity. Replacing nozzles 1. Remove the pan supports, burner caps and flame-spreader crowns to access the burner cups. 2. Replace the nozzles using a 7-mm wrench according to the type of gas to be used (see the “Burner and nozzle characteristics Extraction using a hood table”).
  • Page 22: Gas Types And Countries

    spindle clockwise all the way. Lubricating the gas cocks Over time the gas cocks may become difficult to Following adjustment to a gas other turn and get blocked. Clean them internally and than the one originally set in the factory, replace the lubrication grease.
  • Page 23: Positioning

    4 Natural Gas G2.350 - 13 mbar UR-3c Rated heating capacity (kW) Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) (F3) (H3) Reduced flow rate (W) 1600 5 LPG G30/31 - 30/37 mbar UR-3c Rated heating capacity (kW) 1.75 Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) Reduced flow rate (W) 1600...
  • Page 24 Assembling the upstand (on some models min. 300 mm only) 881 ÷ 936 mm 105 ÷ 160 mm 750 mm 450 mm 900 mm Minimum distance from side walls or other flammable material. Foot range Minimum cabinet width (=A) Appliance dimensions The upstand must always be positioned and secured correctly on the appliance.
  • Page 25: Electrical Connection

    1. Screw the wall fastening plate to the rear of 6. Consider a distance of 50 mm from the side the appliance. of the appliance to the bracket holes. 2. Adjust the height of the 4 legs. 3. Assemble the fastening bracket. 7.
  • Page 26: Instructions For The Installer

    data, serial number and brand name is visibly valve, burner and ignition are working positioned on the appliance. properly. Do not remove this plate for any reason. • Turn the burner knobs to the minimum position and check that the flame is stable The appliance must be connected to ground for each individual burner and all the using a wire that is at least 20 mm longer than...
