We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com
PRECAUTIONS
General safety instructions
Risk of personal injury
• WARNING: During use the
appliance and its accessible
parts become very hot. Keep
children well away from the
appliance.
• Protect your hands by wearing
oven gloves when moving food
inside the oven.
• Never try to put out a fire or
flames with water: Turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
91477B304/A
31
31
35
36
36
36
36
36
37
37
37
37
37
38
38
38
38
39
39
40
40
• This appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
• Children must not play with the
appliance.
• Keep children under the age of
eight at a safe distance unless
40
40
41
42
42
43
44
44
44
45
45
46
47
48
49
49
49
52
53
56
57
PRECAUTIONS - 31
Advertisement
Table of Contents
Related Manuals for Smeg CO60GMA
Summary of Contents for Smeg CO60GMA
-
Page 1: Table Of Contents
Preliminary operations Instructions for the installer We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com PRECAUTIONS General safety instructions • This appliance may only be... - Page 2 they are constantly supervised. lid or a blanket. • Keep children under the age of • The appliance becomes very 8 away from the appliance hot during use. Take care never when it is in use. to touch the heating elements •...
- Page 3 AVAILABLE) OR NEAR THE damaged, contact technical APPLIANCE. support immediately to arrange • DO NOT USE AEROSOLS IN for it to be replaced in order to THE VICINITY OF THIS avoid possible hazards. APPLIANCE WHILST IT IS IN • WARNING: A gas cooking USE.
- Page 4 into the side guides. The bottom as a support for mechanical safety locks that cooking. prevent them from being • If you wish to use greaseproof removed must face downwards paper, place it so that it will not and towards the back of the interfere with the hot air oven.
-
Page 5: Installation
• Never use the oven door to ventilation. lever the appliance into place • The settings for this appliance when fitting. are shown on the gas setting • Avoid exerting too much label. pressure on the door when • Have the gas connection open. -
Page 6: Appliance Purpose
• Use cables that can withstand equipped with an updated version of the system, and as such, all that appears on the temperatures of at least 90°C. display may differ from those in the manual. • The tightening torque of the Manufacturer’s liability screws of the terminal supply The manufacturer declines all liability for... -
Page 7: Information For European Control Bodies
light sources. Plastic packaging Danger of suffocation • Do not let children play with the plastic bags. Information for European Control Bodies • The light sources contained in the appliance Fan forced mode are declared suitable for operation at the ECO function used to define the energy ambient temperature ≥300°C and intended efficiency class complies with the specifications for use in high temperature applications such... -
Page 8: Description
DESCRIPTION General description 1 Hob 5 Door 2 Control panel 6 Fan 3 Left light 7 Right light (on some models only) 4 Seal Frame shelf UR-3c AUX = Auxiliary Burner UR-3c = Ultra-Rapid Burner SR = Semi-rapid Burner Control panel fig. -
Page 9: Other Parts
1 Hob burner knobs • When the door is opened. • When any function is selected, apart from For lighting and adjusting the hob burners. Press function. and turn the knobs anti-clockwise to order to light the relative burners. Turn the knobs When the door is open, it is not possible to the zone between the maximum to turn off the interior lighting. -
Page 10: Use
Preliminary operations placed on the hob pan supports. Make sure they are placed properly. See General safety instructions. • Remove any protective film from the outside or inside of the appliance, including accessories. • Remove any labels (apart from the technical data plate) from the accessories and shelves. -
Page 11: Using The Storage Compartment (Where Present)
SMALL GRILL over. Using only the heat released from the Burner Pan diameter central element, this function allows you 12 - 14 cm to grill small portions of meat and fish for making kebabs, toasted sandwiches 16 - 24 cm and any types of grilled vegetable side UR-3c 18 - 28 cm... -
Page 12: Analogue Programmer
VAPOR CLEAN (on some models only) be overcooked on the outside and undercooked on the inside). This function facilitates cleaning using Advice for cooking meat the steam produced by a small amount • Cooking times vary according to the of water poured onto the depression on thickness and quality of the food and to the bottom. -
Page 13: Cooking Information Table
increased quantity in the oven, cooking on • Avoid overlapping the food. two levels may take slightly longer • To defrost meat, use the rack placed on the compared to cooking on a single shelf. second level and a tray on the first level. In •... -
Page 14: Cleaning And Maintenance
Weight Temp. Time Food Function Shelf (Kg) (°C) (minutes) Focaccia TURBO/CIRCULAIRE 180 - 190 20 - 25 Bundt cake CIRCULAIRE 55 - 60 Tart CIRCULAIRE 35 - 40 Ricotta cake CIRCULAIRE 160 - 170 55 - 60 Jam tarts TURBO/CIRCULAIRE 20 - 25 Paradise CIRCULAIRE... -
Page 15: Knobs
Check them frequently and clean them with a 2. Grasp the door on both sides with both damp cloth if necessary. Remove any dry hands, lift it forming an angle of around 30° residues with a wooden toothpick or a needle. and remove it. -
Page 16: Cleaning The Oven Cavity
4. Then remove the inner glass pane from the 8. Reinsert the intermediate glass unit and front profile. reposition the inner glass. 5. Lift the intermediate glass unit upwards. The intermediate glass pane must be repositioned on the open door so that the screen printing in the corner can be read from left to right (the rough part of the screen printing must face the... -
Page 17: Vapor Clean (On Some Models Only)
Drying • The damp stone must not be used for a least 8 hours after the end of the cleaning Cooking food generates moisture inside the procedures. appliance. This is a normal phenomenon and does not affect the appliance’s operation in any •... -
Page 18: Extraordinary Maintenance
3. Allow the cleaning cycle to run for 18 3. Use a tool (e.g. a spoon) to remove the bulb minutes. cover. Vapor Clean End 1. Turn the function knob to 0 to exit from the function. 2. Open the door and wipe away the less stubborn dirt with a microfibre cloth. -
Page 19: Installation
INSTALLATION If a hood is installed above the The appliance must be installed by a appliance, refer to the hood instructions qualified technician and according to manual to make sure the correct the regulations in force. clearance is left. Appliance factory set for: natural gas Connection with a rubber hose G20 at a pressure of 20 mbar. - Page 20 standard is stamped on the hose). B.S. 669. Carefully screw the hose connector 3 onto the appliance’s gas connector 1 (½” thread ISO Apply insulating material to the thread of the gas 228-1), placing the seal 2 between them. After hose connector 4 and screw the adapter 3 onto screwing on the hose connector, push the gas it.
- Page 21 Connection to LPG issue a certificate of conformity. Use a pressure regulator and make the connection on the gas cylinder following the guidelines set out in the standards in force. The supply pressure must comply with the values indicated in the “Burner and nozzle characteristics table”.
-
Page 22: Gas Types And Countries
Replacing nozzles Light the burner and turn it to the minimum position. Extract the gas cock knob and turn the adjustment screw next to the gas cock spindle (depending on the model) until the correct minimum flame is achieved. Refit the knob and verify that the burner flame is stable. -
Page 23: Burner And Nozzle Characteristics Tables
Gas types 5 LPG G30/31 28-30/37 mbar G30/31 • • • • • • 30/30 mbar G30/31 • • • 6 LPG G30/31 37 mbar G30/31 • 7 Town Gas G110 8 mbar • • G110 It is possible to identify the available gas types based on the country the appliance is to be installed in. - Page 24 6 LPG G30/31 - 37 mbar UR-3c Rated heating capacity (kW) Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) 1600 Reduced flow rate (W) Rated flow rate G30 (g/h) Rated flow rate G31 (g/h) 7 Town gas G110 – 8 mbar UR-3c 1.05 Rated heating capacity (kW)
- Page 25 the floor (2). importance of their correct installation. The anti-tip devices must be installed in order to prevent the appliance from tipping over. 1. Screw the wall fastening plate to the rear of the appliance. Assembling the upstand (on some models only) 2.
-
Page 26: Electrical Connection
5. Align the base of the fastening bracket with 9. Push the cooker towards the wall, and at the the ground and tighten the screws to fix the same time insert the bracket in the plate measurements. fastened to the rear of the appliance. 6. -
Page 27: Instructions For The Installer
regulations. For the Australian/New Zealand market: The circuit breaker incorporated in the fixed connection must comply with AS/NZS 3000. Instructions for the installer • If you use a plug to connect to the power supply, the plug must be accessible after installation.
