- Page 1 Owner's Manual Original Instructions Air Conditioners N Series Duct Type Unit Models: Indoor Unit Outdoor Unit CH-U050NK CH-D050PNK CH-U071NK CH-D071PNK CH-U085NK CH-D085PNK CH-U100NM CH-DH100PNK CH-U125NM CH-DH125PNK CH-U140NM CH-DH140PNK CH-U160NM CH-DH160PNK...
- Page 2 To Users Thank you for selecting C&H’s product. Please read this instruction manual carefully before installing and using the product, so as to master and correctly use the product. In order to guide you to correctly install and use our product and achieve expected operating effect, we hereby instruct as below: (1) This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of...
- Page 3 necessary revision to the product from time to time due to the reason of sales or production, and reserve the right to revise the contents without further notice. (7) Indoor unit must not be installed in a laundry. (8) If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
-
Page 4: Table Of Contents
Contents 1 Safety Notices (Please Be Sure To Abide) ....... 1 2 Product Introduction ............5 2.1 Overall Layout ................. 5 2.2 Product Operating Range ............6 2.3 Standard Accessories ............. 6 3 Installation ................7 3.1 Installation Preparation ............7 3.2 Unit Installation .............. -
Page 5: Safety Notices (Please Be Sure To Abide)
N Series Duct Type Unit 1 Safety Notices (Please Be Sure To Abide) SPECIAL WARNING: Do not pierce or burn. Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. Be aware that refrigerants may not contain an odor. The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater). - Page 6 N Series Duct Type Unit PROHIBITED (1) The air conditioner should be grounded to avoid electric shock. Do not connect the ground wire to gas pipe, water pipe, lightning arrester or telephone wire. (2) The appliance shall be stored in a well-ventilated area where the room size corresponds to the room area as specified for operation.
- Page 7 N Series Duct Type Unit WARNING (11) The air conditioner can be cleaned only after it is turned off and power-disconnected, otherwise electric shock may occur. (12) The air conditioner is not intended to be cleaned or maintained by children without supervision.
- Page 8 N Series Duct Type Unit OBSERVED (1) If wired control is to be used, it should be connected first before powering up the unit, otherwise the wired control may not be able to use. (2) When installing the indoor unit, keep it away from television, wireless waves, and fluorescent.
-
Page 9: Product Introduction
N Series Duct Type Unit 2 Product Introduction 2.1 Overall Layout NOTICE: (1) The connection pipe, drain pipe, power cord, and duct for this unit should be prepared by the user. (2) The unit is standard equipped with rectangular duct. (3) Remote controller and wired controller are for reference only. -
Page 10: Product Operating Range
N Series Duct Type Unit 2.2 Product Operating Range Cooling Heating Outdoor temperature DB(°C) -15~48 -15~24 Indoor temperature DB/WB(°C) 32/23 27/- (Maximum) 2.3 Standard Accessories Indoor Unit Accessories Name Appearance Q'ty Usage Wired Controller To control the indoor unit To fix the hook on the cabinet Nut with Washer of the unit To be used together with the... -
Page 11: Installation
N Series Duct Type Unit Outdoor Unit Accessories Name Appearance Q'ty Usage Drain Plug 1or3 To plug the unused drain hole Drainage To connect with the hard PVC Connecter drain pipe 3 Installation 3.1 Installation Preparation 3.1.1 Selection of Installation Location WARNING ①. - Page 12 N Series Duct Type Unit (6) If hoisting screw bolts are to be used, check whether the installation location is safe enough. If not safe, reinforce the location before installation. (7) Indoor unit, power cord, connecting wires and communication cords should be at least 1m from television and radio.
- Page 13 N Series Duct Type Unit Indoor Unit Gas pipe Liquid pipe Electric Box Drain pipe NOTICE Drilling of ceiling opening and installation of air conditioner must be performed by professionals! Unit: mm Item Model 1060 1000 1068 1360 1300 1368 1360 1300 1368...
- Page 14 N Series Duct Type Unit Outdoor Unit CH-U050NK, CH-U071NK, CH-U085NK, CH-U100NM CH-U125NM, CH-U140NM, CH-U160NM...
- Page 15 N Series Duct Type Unit Unit: mm Dimensions Model 1010 1010 1010 3.1.3 Diagram of Unit Installation Space and Location (1) Diagram of installation space and location for outdoor unit (Notice: for best performance of the outdoor unit, make sure its installation space conforms to the following installation dimensions).
- Page 16 N Series Duct Type Unit (mm) — ≥100 A,B,C, — ≥300 ≥100 ≥100 — ≥100 ≥1000 A,B,C,E — ≥300 ≥150 ≥150 ≥1000 — ≥1000 — ≥1000 ≥1000 ≥100 ≥1000 ＜H ＞H ≥100 ≥1000 ＞H ＜H ≤1/2H ≥250 ≥2000 ≥1000 1/2H＜H ≤H ≥250 ≥2000...
- Page 17 N Series Duct Type Unit (mm) ≥300 ≥2000 ＜H ＞H ≤1/2H ≥250 ≥2000 ＞H 1/2H＜H ≤H ≥300 ≥2500 ≤1/2H ≥300 ≥2000 ≥1000 ＜H 1/2H＜H ≤H ≥300 ≥2500 ≥1000 Prohibited ＞H B,D,E ≤1/2H ≥250 ≥2500 ≥1000 1/2H＜H ≤H ≥300 ≥2500 ≥1000 ＞H Prohibited ＞1/2H...
- Page 18 N Series Duct Type Unit 4) When outdoor units are installed one above another. Unit: mm 2000...
-
Page 19: Unit Installation
N Series Duct Type Unit (2) Diagram of installation location and space for indoor unit (Notice: for the best performance of indoor unit, make sure its installation space conforms to the following installation dimensions). 3.2 Unit Installation 3.2.1 Indoor Unit Installation 3.2.1.1 Preparation for Installing the Indoor Unit NOTICE ①... - Page 20 N Series Duct Type Unit (1) Install the bolts to the ceiling at a place strong enough to hang the unit. Mark the bolt positions from the installation template. With a concrete drill for 12.7mm diameter holes. See the following figure. Ф...
- Page 21 N Series Duct Type Unit 3.2.1.2 Leveling The water level test must be done after installing the indoor unit to make the unit is horizontal, as shown below. 3.2.2 Outdoor Unit Installation (1) If the outdoor unit is installed on a solid ground such as concrete, use M10 screw bolts and nuts to secure the unit and make sure the unit stands erect and level.
- Page 22 N Series Duct Type Unit the outside of connection pipe should be added with a layer of insulating cotton to protect it from mechanical damage during installation, maintenance and transportation. Size of Fitting Pipe Item Maximum Biggest drop between (Inch) pipe indoor and outdoor Model...
- Page 23 N Series Duct Type Unit (1) Outdoor unit is beneath the indoor unit. There’s no need to add non-return bend at the lowest or highest position of the vertical pipe, as shown below: Indoor unit System gas pipe Oil return bend Install an oil return bend every 6m Outdoor unit...
- Page 24 N Series Duct Type Unit Dimensions for the making of oil return bend are as follows: B(mm) C(mm) Ф12 ≥26 ≤150 Ф16 ≥33 ≤150 3.2.3.2 Pipe Flaring (1) Cut the connection pipe with a pipe cutter. (2) The mouth of connection pipe should face downward. Remove burrs with the cut surface so that the chips do not enter the pipe.
- Page 25 N Series Duct Type Unit As shown beside, use a sharp cutter to cut the heat insulating pipe and bend it after the pipe is exposed. After bending, place the heat insulating pipe back on the pipeline and fix it with adhesive tape. 3.2.3.4 Connecting the Pipe at the Indoor Unit Side NOTICE ①.
- Page 26 N Series Duct Type Unit Pipe Diameter(In) Tightening Torque(N·m) 1/4" 15-30 3/8" 35-40 1/2" 45-50 5/8" 60-65 3/4" 70-75 7/8" 80-85 Screw on the flare nut of the flaring connecting pipe on the outdoor unit valve. The method of screwing the flare nut is the same with that for indoor unit. Gas pipe Liquid pipe Pipe...
- Page 27 N Series Duct Type Unit 3.2.4 Connection Pipe Vacuum Pumping NOTICE Make sure the outlet of vacuum pump is away from fire source and is well- ventilated. (1) Remove the caps of the liquid valve, gas valve and also the service port. (2) Connect the hose at the low pressure side of the manifold valve assembly to the service port of the unit’s gas valve, and meanwhile the gas and liquid valves should be kept closed in case of refrigerant leak.
- Page 28 N Series Duct Type Unit Pressure gauge (Low-pressure) gauge manifold Pressure gauge (Hi-pressure) Switch (Low-pressure) Switch (Hi-pressure) Connection pipe Connection pipe (to indoor unit) Liquid valve Gas valve Service pipe Hose Service port Hose with the valve pin Vacuum pump NOTICE: For large-size units, there are maintenance ports for liquid valve and gas valve.
- Page 29 N Series Duct Type Unit 3.2.6.1 Indoor Side Drainage Pipe NOTICE Install the drain hose in accordance with the instructions in this installation manual and keep the area warm enough to prevent condensation. Problems with the piping may lead to water leaks. (1) Install the drain hose with downward gradient (1/50 to 1/100) and no risers or traps are used for the hose.
- Page 30 N Series Duct Type Unit one on the left side (electric box side). (8) When using the drain port on the right side of the unit, reinstall the drain cap to the left side drain port. See the following figure. (9) Be sure to insulate where the drain port and the drain hose is connected.
- Page 31 N Series Duct Type Unit (2) If the outdoor unit is above the indoor unit, arrange the pipeline according to the following diagram. 1) Wind the insulating tape from bottom to top. 2) The whole pipeline should be wound together to avoid water returning to the room.
- Page 32 N Series Duct Type Unit 3.2.6.3 Notice on Drain Lift Pipe (1) For the unit with the condensate pump, only one drain port at the side close to the electric box is prepared and only through it the drain hose can be connected.
- Page 33 N Series Duct Type Unit The vertical height of the drain hose should be 75mm or less so that it is unnecessary for the drain port to withstand additional force. When multiple drain hoses are used, their installation should be performed as shown in the figure below.
- Page 34 N Series Duct Type Unit 3-way connection of Connection of drain elbow Drainage pipe joint Connection of horizontal pipe 3.2.6.4 Check Drainage After piping work is finished, check if drainage flows smoothly. As shown in the figure, add approximately 1liter of water slowly into the drain pan and check drainage flow during COOL running.
- Page 35 N Series Duct Type Unit Unit: mm Supply Air Outlet Return Air Inlet Item Model 1000 1185 1300 1185 1300 1150 1360 1150 1360 3.2.7.2 Return Air Method (1) The default ex-factory return air method is from the back. The return air cover shall be installed at the bottom of the unit, as is shown in the following figure.
- Page 36 N Series Duct Type Unit (4) The noise of downward return air is obvious bigger than that of rear return air. For downward return air, silencer and static pressure carton shall be added to conduct noise reduction treatment. 3.2.7.3 Installation of Air Supply Duct and Air Return Supply Installation method shall be selected by entirely considering the conditions of buildings, maintenance, etc.
-
Page 37: Electrical Installation
N Series Duct Type Unit NOTICE: ①. The supply air duct, return air duct and fresh air duct shall have thermal insulation layer to prevent heat leakage and condensation. Stick the plastic nail to the air duct, then attach the heat preservation cotton with tinfoil and fix it with plastic nail cover, finally, seal the connection joint with tinfoil tape tightly;... - Page 38 N Series Duct Type Unit Do not draw power from another power circuit. ③. The air conditioner circuit should be at least 1.5m away from any inflammable surface. ④. The external power cord, connection wire of indoor and outdoor units and the communication cords must be effectively fixed.
- Page 39 N Series Duct Type Unit 3.3.2 Electrical Parameters 3.3.2.1 Wire Specifications and Fuse Capacity Min. Circuit Fuse Sectional Power Supply Breaker Capacity Area of Model Capacity Power Cord V/Ph/Hz Indoor Unit 3.15 220-240V ~50Hz Min. Sectional Circuit Breaker Power Supply Area of Power Capacity Model...
- Page 40 N Series Duct Type Unit ⑤. Specifications of circuit breaker are based on a working condition where the working temperature is 40°C. If working condition changes, please adjust the specifications according to national standards. ⑥. Adopt 2pc of 0.75mm² power cords to be the communication cords between indoor and outdoor units.
- Page 41 N Series Duct Type Unit c) Before connecting the product to public power network, please consult your local power supply authority to ensure that the power network has met the above requirements. No requirement for the unlisted product’s impedance value of power-supply system. 3.3.3 Connection of Power Cord and Communication Cord For solid wires (as shown below): 1) Use wire cutters to cut off the wire end and then peel away about 25mm of...
- Page 42 N Series Duct Type Unit How to connect the connection wire and power cord. Lead the connection wire and power cord through the insulation tube. Then fix the wires with wire clamps (as shown in the next figure). WARNING ①. Before working, please check whether the indoor and outdoor units are powered on.
- Page 43 N Series Duct Type Unit Electric wiring between the indoor and outdoor units. Outdoor Unit Indoor Unit Wired Controller Breaker Breaker Power:220V-240V ~ 50Hz Power:220V-240V ~ 50Hz ①. Power cord 3×1.5mm ②. Power cord 3×1.0mm ③. Communication Cords 2×0.75mm ④. Communication Cords 2×0.75mm ①.
- Page 44 N Series Duct Type Unit Outdoor Unit Indoor Unit L1 L3 N Wired breaker breaker Controller Power:220V-240V~ 50Hz Power:380V-415V 3N ~ 50Hz ①. Power cord 5×1.5mm ②. Power cord 3×1.0mm ③. Communication Cords 2×0.75mm ④. Communication Cords 2×0.75mm Electrical wiring of indoor unit. WARNING ①.
- Page 45 N Series Duct Type Unit WARNING ⑧. When connecting the power cord, make sure the phase sequence of the power supply matches with the corresponding terminals, otherwise the compressor will get reversed and operate abnormally. 1) Indoor side Take off the electric box cover from the sub-assembly of electric box. Then connect the wires.
-
Page 46: Check After Installation
N Series Duct Type Unit CH-U100NM CH-U125NM CH-U140NM CH-U160NM CH-U125NM CH-U140NM CH-U160NM Power cord should be secured along with the right side plate and fixed to the hook with a wire clamp so as to avoid contacting the pipeline. The communication line between indoor and outdoor units should also be laid along with the right side plate but away from the power cord. -
Page 47: Test Running
N Series Duct Type Unit Check items Possible events due to improper installation Is the voltage consistent with that The unit may fail or its components may get stated on the nameplate? burned. Are the wires and pipes installed The unit may fail or its components may get correctly? burned. -
Page 48: Installation Of Controller
N Series Duct Type Unit NOTICE： ①. If you use remote control to turn off the unit and then immediately turn the unit on again, compressor will need 3min to restart. Even if you press “ON/OFF” button on the remote control, it won’t be started up right away. ②. -
Page 49: Error Code
N Series Duct Type Unit 5.2 Error Code WARNING ①. If abnormal things (for example, awful smell) occur, please stop the unit immediately and disconnect power. Then contact C&H’s authorized service center. If the unit continues to run in abnormal situations, it may get damaged and cause electric shock or fire hazard. -
Page 50: Unit Maintenance
N Series Duct Type Unit NOTICE: When the unit is connected with the wired controller, the error code will be simultaneously shown on it. 5.3 Unit Maintenance 5.3.1 Filter Cleaning Increase the frequency of cleaning if the unit is installed in a room where the air is extremely contaminated (As a yardstick for yourself, consider cleaning the filter once a half year). -
Page 51: After-Sales Services
N Series Duct Type Unit 5.3.4 Notices at the Beginning of the Using Season (1) Check if there is blockage at the inlet or outlet vent of air conditioner. (2) Check if the earth wire has been attached reliably by the skilled serviceman. (3) Check if the exhausted batteries of the wireless controller have been replaced.
