Owner's Manual
Original Instructions
Air Conditioners
N Series Cassette Type Unit
Models:
Indoor Unit
CH-C050NK
CH-C071NK
CH-C085NK
CH-C100NK
CH-C125NK
CH-C140NK
CH-C160NK
Outdoor Unit
CH-U050NK
CH-U071NK
CH-U085NK
CH-U100NM
CH-U125NM
CH-U140NM
CH-U160NM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N Series and is the answer not in the manual?

Questions and answers

Related Manuals for Cooper & Hunter N Series

Summary of Contents for Cooper & Hunter N Series

  • Page 1 Owner's Manual Original Instructions Air Conditioners N Series Cassette Type Unit Models: Indoor Unit Outdoor Unit CH-U050NK CH-C050NK CH-U071NK CH-C071NK CH-U085NK CH-C085NK CH-U100NM CH-C100NK CH-U125NM CH-C125NK CH-U140NM CH-C140NK CH-U160NM CH-C160NK...
  • Page 2 To Users Thank you for selecting C&H’s product. Please read this instruction manual carefully before installing and using the product, so as to master and correctly use the product. In order to guide you to correctly install and use our product and achieve expected operating effect, we hereby instruct as below: (1) This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of...
  • Page 3 necessary revision to the product from time to time due to the reason of sales or production, and reserve the right to revise the contents without further notice. (7) Indoor unit must not be installed in a laundry. (8) If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

  • Page 4: Table Of Contents

    Contents 1 Safety Notices (Please be sure to abide) ......1 2 Product Introduction ............6 2.1 Overall Layout ................6 2.2 Product Operating Range ............7 2.3 Standard Accessories .............7 3 Installation ................8 3.1 Installation Preparation ............8 3.2 Unit Installation ..............16 3.3 Electrical Installation ............

  • Page 5: Safety Notices (Please Be Sure To Abide)

    N Series Cassette Type Unit 1 Safety Notices (Please be sure to abide) SPECIAL WARNING: (1) Do not pierce or burn. (2) Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer.
  • Page 6 N Series Cassette Type Unit PROHIBITED! (1) The air conditioner should be grounded to avoid electric shock. Do not connect the ground wire to gas pipe, water pipe, lightning arrester or telephone wire. (2) The appliance shall be stored in a well-ventilated area where the room size corresponds to the room area as specified for operation.
  • Page 7 N Series Cassette Type Unit WARNING! Please install the air conditioner in a secure place that can withstand the weight of air conditioner. Insecure installation may cause the air conditioner falling down and lead to injury. (10) Be sure to adopt independent power circuit. If the power cord is damaged, it must be repaired by the manufacturer, service agent or other professional agents.
  • Page 8 N Series Cassette Type Unit NOTE! Do not put a finger or other objects into the air inlet or air return grill. Please adopt safety protection measures before touching the refrigerant pipe; otherwise your hands may be hurt. Please arrange the drain pipe according to the instruction manual.
  • Page 9 N Series Cassette Type Unit OBSERVED! If wired control is to be used, it should be connected first before powering up the unit, otherwise the wired control may not be able to use. When installing the indoor unit, keep it away from television, wireless waves, and fluorescent.

  • Page 10: Product Introduction

    N Series Cassette Type Unit 2 Product Introduction 2.1 Overall Layout NOTE: The connection pipe, drain pipe, power cord, for this unit should be prepared by the user.

  • Page 11: Product Operating Range

    N Series Cassette Type Unit 2.2 Product Operating Range — Cooling Heating Outdoor temperature DB(°C) -15~48 -15~24 Indoor temperature DB/WB(°C) 32/23 27/- (Maximum) 2.3 Standard Accessories Indoor Unit Accessories Name Appearance Q'ty Usage To connect with the Drain Hose hard PVC drain pipe...

  • Page 12: Installation

    N Series Cassette Type Unit Outdoor Unit Accessories Name Appearance Q'ty Usage To plug the unused drain Drain Plug 1or3 hole. Drainage To connect with the hard Connecter PVC drain pipe 3 Installation 3.1 Installation Preparation 3.1.1 Selection of Installation Location WARNING! ①...
  • Page 13 N Series Cassette Type Unit (6) If hoisting screw bolts are to be used, check whether the installation location is safe enough. If not safe, reinforce the location before installation. (7) Indoor unit, power cord, connecting wires and communication cords should be at least 1m from television and radio.
  • Page 14 N Series Cassette Type Unit 3.1.2 Unit Dimension WARNING! ① . Install the indoor unit in a location which can withstand a load of at least five times the weight of the main unit and which will not amplify sound or vibration.
  • Page 15 N Series Cassette Type Unit Dimensions Model CH-C071NK CH-C085NK CH-C100NK CH-C125NK CH-C140NK CH-C160NK NOTES! ① . Drilling of ceiling opening and installation of air conditioner must be performed by professionals! ② . Please refer to the installation cardboard for the dimension of drilling hole of...
  • Page 16 N Series Cassette Type Unit (2) Outdoor units CH-U050NK, CH-U071NK, CH-U085NK, CH-U100NM CH-U125NM, CH-U140NM, CH-U160NM Unit: mm Dimensions Model...
  • Page 17 N Series Cassette Type Unit Dimensions Model 1010 1010 1010 3.1.3 Diagram of Unit Installation Space and Location (1) Diagram of installation space and location for outdoor unit (Notice: for best performance of the outdoor unit, make sure its installation space conforms to the following installation dimensions).
  • Page 18 N Series Cassette Type Unit 2) When two or more outdoor units are to be installed side by side. Unit: mm (mm) ≥300 ≥300 ≥1000 A,B,C — — — ≥300 ≥300 ≥1000 ≥1000 A,B,C,E — — ≥2000 — — —...
  • Page 19 N Series Cassette Type Unit 3) When outdoor units are installed in rows. Unit: mm (mm) ≤1/2H b≥250 ≤H b≥300 1/2H<H >H Prohibited 4) When outdoor units are installed one above another Unit: mm (2) Diagram of installation location and space for indoor unit (Notice: for the best performance of indoor unit, make sure its installation space conforms to the following installation dimensions).

  • Page 20: Unit Installation

    N Series Cassette Type Unit Model H(mm) 3.2 Unit Installation 3.2.1 Indoor Unit Installation In order to make the front panel cover 20mm of the ceiling, the distance between the ceiling and the unit should be 35mm or less. If the distance between the ceiling and the unit is above 35mm, add some ceiling material to shorten the distance.
  • Page 21 N Series Cassette Type Unit 3.2.1.1 Hoisting the Main Body Unit NOTE! Please tightly screw up the nuts and bolts to prevent the air conditioner from falling. (1) Installing the Suspension Bolts. 1) Using the installation template, drill holes for bolts (four holes).
  • Page 22 N Series Cassette Type Unit 1) Install the hoisting stand on the hoisting screw by using nuts and gaskets at both the upper and lower sides of the hoisting stand. To prevent the gasket from breaking off, a gasket anchor board can be helpful.
  • Page 23 N Series Cassette Type Unit to the drainage hole on the chassis of the outdoor unit. Then connect a drain hose to the drainage connector (If drainage connector is used, the outdoor unit should be at least 10cm from the installation ground). See the figures below.
  • Page 24 N Series Cassette Type Unit return bend should be added every 6 meters. The requirement on the adding of oil return bend is as below: (1) Outdoor unit is beneath the indoor unit. There’s no need to add non-return bend at the lowest or highest position of the vertical pipe, as shown below: (2) Outdoor unit is above the indoor unit.
  • Page 25 N Series Cassette Type Unit Dimensions for the making of oil return bend are as follows: A(inch) B(mm) C(mm) Ф1/2 ≥26 ≤150 Ф5/8 ≥33 ≤150 3.2.3.2 Pipe Flaring (1) Cut the connection pipe with a pipe cutter. (2) The mouth of connection pipe should face downward. Remove burrs with the cut surface so that the chips do not enter the pipe.
  • Page 26 N Series Cassette Type Unit (3) If the pipe is repeatedly bent or extended, it will become hard and difficult to be bent or extended. So do not bend or extend the pipe for more than 3 times. (4) When bending the pipe, do not bend it excessively, otherwise it will get broken.
  • Page 27 N Series Cassette Type Unit Pipe Diameter(inch) Tightening Torque(N·m) Ф1/4 15-30 Ф3/8 35-40 Ф1/2 45-50 Ф5/8 60-65 Ф3/4 70-75 Ф7/8 80-85 Screw on the flare nut of the flaring connecting pipe on the outdoor unit valve. The method of screwing the flare nut is the same with that for indoor unit.
  • Page 28 N Series Cassette Type Unit 3.2.3.5 Thermal Insulation of Pipe Joint (Only for Indoor Unit) Stick coupler heat insulation (large and small) to the place where connecting pipes. 3.2.4 Connection Pipe Vacuum Pumping NOTE! Make sure the outlet of vacuum pump is away from fire source and is well- ventilated.
  • Page 29 N Series Cassette Type Unit Model Time(min) And verify if the pressure gauge at the low pressure side of the manifold valve assembly reads -0.1MPa (-750mmHg), if not, it indicates there is leak somewhere. Then, close the switch fully and then stop the vacuum pump.
  • Page 30 N Series Cassette Type Unit 3.2.5 Refrigerant Adding See the following table for the amount of additional refrigerant. Standard Unnecessary Charge Additional Refrigerant Item Pipe Length Pipe Length Amount for Extra Pipe ≤7.0m 5.0m 22 g/m ≤7.0m 5.0m 30 g/m ≤7.0m...
  • Page 31 N Series Cassette Type Unit (5) In order to make sure the drain hose is straight, the hangers should keep a distance of 1~1.5m from one another. (6) Use the drain hose that is delivered together with the unit. (7) Insert the drain hose into the drain faucet.
  • Page 32 N Series Cassette Type Unit 3.2.6.2 Outdoor Side Drainage Pipe (1) If the outdoor unit is underneath the indoor unit, arrange the pipeline according to the following diagram. 1) Drain hose should be placed on the ground and its end should not be immersed into water.
  • Page 33 N Series Cassette Type Unit 3.2.6.3 Notice on Drain Lift Pipe (1) The drain lift pipe should be 1000mm or less away from ground, as shown below. (2) If multiple drain pipes are to be converged, please install according to the following process.
  • Page 34 N Series Cassette Type Unit NOTE: Specifications of the converging drain pipes should be applicable to the operating capacity of the units. (3) Drain branch should be connected to the vertical or horizontal part of the main drain pipe. (4) Horizontal pipe should not be connected to the vertical pipe that is on the same level.
  • Page 35 N Series Cassette Type Unit (2) See the following diagram for the method of water filling. 3.2.7 Installing the Front Panel As shown below, take off the 4 corner covers from the front panel and loose the hexagon screw bolts on the 4 fasteners to the maximum. The position marked with “PIPING SIDE”...
  • Page 36 N Series Cassette Type Unit NOTES： (1) Improper screw looseness will lead to the following problem. (2) After the screws are tightened, if there is still a gap between the ceiling and the decorative front panel, adjust the height of the unit again (as shown below).

  • Page 37: Electrical Installation

    N Series Cassette Type Unit WARNING! After installing the panel, the insulated protective cover with the thickness of 1mm shall be used to wrap the wiring terminal, Tighten the insulated glue cover on both sides with bonding tie to fix it.
  • Page 38 N Series Cassette Type Unit the communication cords must be effectively fixed. ⑤ . The external power cord, connection wire of indoor and outdoor units and the communication cords can’t directly contact any hot objects. For example: they must not contact chimney pipes, warm gas pipes or other hot objects.
  • Page 39 N Series Cassette Type Unit 3.3.2 Electrical Parameters Fuse Circuit breaker Min. sectional area Power supply Model capacity capacity of power cord V/Ph/Hz Indoor unit 220-240V ~50Hz 3.15 Circuit breaker Min. sectional area of Power supply capacity power cord Model...
  • Page 40 N Series Cassette Type Unit between indoor and outdoor units. The maximum length is 100m. Please select a proper length according to local conditions. Communication cords must not be twisted together. To be in compliance IOS5151, it is necessary to use 8 meters long wire.
  • Page 41 N Series Cassette Type Unit 2) Use a screwdriver to unscrew the terminal screw on the terminal board. 3) Use nippers to bend the solid wire into a ring that fits the terminal screw. 4) Form a proper ring and then put it on the terminal board. Use a screwdriver to tighten up the terminal screw.
  • Page 42 N Series Cassette Type Unit WARNING! ① . Before working, please check whether the indoor and outdoor units are powered ② . Match the terminal numbers and wire colors with the colors indicated in the indoor unit. ③ . Wrong wire connection may burn the electrical components.
  • Page 43 N Series Cassette Type Unit CH-C050NK + CH-U050NK ① . Power cord 3×1.5mm ② . Power cord 3×1.0mm ③ . Communication cords 2×0.75mm ④ . Communication cords 2×0.75mm CH-C071NK + CH-U071NK CH-C085NK + CH-U085NK ① . Power cord 3×2.5mm ② .
  • Page 44 N Series Cassette Type Unit WARNING! ③ . High and low voltage wires should be secured separately. Secure the former ones with big clamps and the latter ones with small clamps. ④ . Use screws to tighten up the connection wires and power cords of indoor and outdoor units on the terminal board.
  • Page 45 N Series Cassette Type Unit 2) Outdoor side Remove the big handle/front panel of the outdoor unit and insert one end of the communication cord and the power cord to the terminal board. CH-U050NK,CH-U071NK,CH-U085NK CH-U100NM, CH-U125NM, CH-U140NM, CH-U160NM...

  • Page 46: Check After Installation

    N Series Cassette Type Unit CH-U125NM, CH-U140NM, CH-U160NM 3.4 Check after Installation Check Items after Installation Possible events due to improper Check items installation. The unit may fall down, vibrate or Is the main body installed securely? produce noise. Cooling...

  • Page 47: Installation Of Controller

    N Series Cassette Type Unit (2) Control circuit is correct and all the wires are firmly connected. (3) Cut-off valves of the gas pipe and liquid pipe are open. (4) The inside of the unit should be clean. Take irrelevant objects out if there is any.
  • Page 48 N Series Cassette Type Unit first check the following points before repair: Failure Possible Reasons 1)The power supply is not connected. 2)Electrical leakage of air-conditioning unit causes The unit cannot be tripping of the leakage switch. started. 4)The operating keys are locked.

  • Page 49: Error Code

    N Series Cassette Type Unit 5.2 Error Code WARNING! ① . If abnormal things (for example, awful smell) occur, please stop the unit immediately and disconnect power. Then contact C&H’s authorized service center. If the unit continues to run in abnormal situations, it may get damaged and cause electric shock or fire hazard.
  • Page 50 N Series Cassette Type Unit NOTE: When the unit is connected with the wired controller, the error code will be simultaneously shown on it. Instructions to the Error Indicating Lamps on the Panel of the Cassette Type Unit. Power and ON/OFF Indicating Lamp: It goes red when the unit is powered on while it goes white when the unit is started.

  • Page 51: Unit Maintenance

    N Series Cassette Type Unit 5.3 Unit Maintenance 5.3.1 Clean Air Filter If the air conditioner is used at a dusty place, clean the air filter regularly. (Once every half a year) How to clean the air filter 1) Open the air intake grill.
  • Page 52 N Series Cassette Type Unit How to clean the air filter 4) Cleaning the filer screen Use vacuum cleaner to remove dust or rinse the filter. If the filter is very dirty (greasy), use warm water (below 45°C) with neutral detergent to clean it.

  • Page 53: After-Sales Services

    N Series Cassette Type Unit How to clean the air intake grill 6) Install the air filter. Same with step 4 in “Clean Air Filter”. 7) Close the air intake grill. Refer to step 1. 5.3.3 Drainage Pipe Periodically check if the drainage pipe is blocked to smooth the condensate water.
