Light UP Détecteur de couloir DALI
•
Light UP Corridor detector DALI
0 485 54
•
Documentation technique disponible dans
votre langue => Scanner le QR code
•
Technical documentation available in your
language => Scan the QR code
•
Documentación técnica disponible en su
idioma => Escanear el cόdigo QR
•
Documentazione tecnica disponibile nella
vostra lingua => Scansionare il codice QR
•
Technische documentatie beschikbaar in
jouw taal. => Scan de QR-code
F (Fréquence) : 2,4 à 2,483 GHz
•
•
P (Puissance) : <100 mW
•
F (Frequency) : 2.4 to 2.483 GHz
•
P (Power) : <100 mW
•
Retour configuration usine
•
Reset button
•
Capteur infra-rouge
•
PIR sensor
•
LED de mouvement
•
Motion LED
•
LED Bluetooth
•
Bluetooth LED
Close Up Legrand
Le soussigné, LEGRAND, déclare que l'équipement radioélectrique du type réf. 0 485 54
•
est conforme à la directive 2014/53/UE. Le texte complet de la déclaration UE de
conformité est disponible à l'adresse suivante : www.legrandoc.com
•
LEGRAND declares that radio equipment of the type Cat. no. 0 485 54 complies with
Directive 2014/53/EU. The full text of the EU declaration of conformity can be found at:
www.legrandoc.com
Hauteur/Height
1.7 m min
Radio
•
Consommation en veille :
•
Standby consumption:
110 - 230 V~
50 / 60 Hz
2 x 1.5 mm² ou/or 1 x 2.5 mm²
-10°C / +30°C
PIR
100 lux
10 mn
•
Mode Passage
•
Walktrough mode
3 m x 24 m (2.5 m)
5.0 compatible 4.2
•
Portée : 10 m
•
Reach: 10 m
2.4 - 2.483 GHz
Garantie/
Maximum
Guaranteed
15 V
100 mA
Charge/Load OFF
Charge/Load ON
1.72 W
•
Bouton Radio bind
•
Radio bind button
•
Bouton Radio réseau
•
Radio network button
•
LED Radio
•
Radio LED
•
Capteur de luminosité
•
Daylight sensor
15 V
130 mA
1.72 W
