Opening detector
1. USE
Radio-controlled magnetic opening detector which sends its status via
a radio frequency command (Greenpower) when there is a change of
status: opening or closing
• Magnetic part for placing on the moving part (door or window)
• RF sensor with its support for placing on the fixed part of the building
(door/window frame)
• Zigbee PRO technology Green Power function used to send the open
or closed status, and also the battery voltage
2. DIMENSIONS (MM)
Technical data sheet: S000124126EN-00
128, av. du Maréchal-de-Lattre-de-Tassigny - 87045 LIMOGES Cedex - France
Tel: +33 (0)5 55 06 87 87 Fax: +33 (0)5 55 06 88 88
www.legrandgroup.com
Updated:
3. INSTALLATION
YES
NO
H < 2 m
H > 2 m
H > 1 m
H < 1 m
DOUBLE-SIDED INSTALLATION
3.1
1
3
2
6
7
20 mm
max.
Cat. No(s): 0 485 75
5
4
9
8
Created: 09/02/2024
1/3
Advertisement
Related Manuals for LEGRAND 0 485 75
Summary of Contents for LEGRAND 0 485 75
- Page 1 128, av. du Maréchal-de-Lattre-de-Tassigny - 87045 LIMOGES Cedex - France Tel: +33 (0)5 55 06 87 87 Fax: +33 (0)5 55 06 88 88 www.legrandgroup.com Opening detector Cat. No(s): 0 485 75 1. USE 3. INSTALLATION Radio-controlled magnetic opening detector which sends its status via...
- Page 2 Opening detector Cat. No(s): 0 485 75 INSTALLATION WITH SCREWS (NOT SUPPLIED, OPTIONAL) 5.4 Climate characteristics Usage temperature: +5°C to +45°C Storage temperature: +5°C to +45°C 6. PROGRAMMING PAIRING 6.1.1 PAIRING WITH A TOOL Requires a tool (software, app, etc) connected to the receiver Zigbee...
- Page 3 10.1 12, 13, 14, 16, 17, 18, 19, 21, 22, 23, 24, 11, 26, 15, etc. Then repeat the pairing operation explained above. LEGRAND declares that the radio-electric equipment type (0 485 75) complies with directive 2014/53/EU. FACTORY RESET The full text of the EU declaration of conformity is available on the following website: www.legrand.com/ecatalogue...
