Summary of Contents for Absen AW Series

  • Page 1 Series User Manual Series User Manual...
  • Page 2: Table Of Contents

    Site installation environment preparation....................- 6 - Preparation of maintenance tools ....................... - 6 - Product description ................................- 7 - AW series overview ............................- 7 - Product main features ............................- 7 - Product specification ............................- 8 - Pictures of panels ............................
  • Page 3: Safety Information

    Please read this manual carefully before installing, powering, operating and maintaining this product. Follow safety instructions in this manual and on the product. If you have any questions, please seek help from Absen.
  • Page 4 Series User Manual Beware of Electric Shock! ⚫ To prevent electric shock the device must be properly grounded during installation. Do not ignore using the grounding plug, or else there is a risk of electric shock. ⚫ During a lightning and thundering, please disconnect the device’s power supply, or provide other suitable lightning protection.
  • Page 5 Series User Manual Beware of Injury! ⚫ Warning: Wear a helmet to avoid injury. ⚫ Ensure any structures used to support, fix and connect the display can withstand at least 10 times the weight of all the equipment. ⚫ When stacking products, please hold products firmly to prevent tipping or falling.
  • Page 6: Preparation Before Installation

    Series User Manual 2 Preparation before installation 2.1 Site installation environment preparation 1. Conventional panels cannot be installed on the seashore, and panels with special anti-salt-alkali materials can be installed on the seashore 2. The humidity at the installation site must not exceed 85RH; 3.
  • Page 7: Product Description

    AW series products are mainly used in fixed application fields such as digital sign, street furniture, light poles, light boxes, etc., as a carrier for video playback and information release applications.
  • Page 8: Product Specification

    Series User Manual 3.3 Product specification AW2.8-Product specifications Parameter Specifications LED type SMD 3in1 1515 Pixel pitch (mm) 2.84 Panel size (width × height × 500*500 500*750 thickness) / (mm) Physical Panel resolution 176*176 176*264 parameters panel weight(kg) Panel material Die-cast aluminum Module size (width ×...
  • Page 9 Series User Manual AW3.9-Product specifications Parameter Specifications LED type SMD 3in1 1921 Pixel pitch (mm) Panel size (width × height × 500*500 500*750 thickness) / (mm) Physical Panel resolution 128*128 128*192 parameters panel weight(kg) Panel material Die-cast aluminum Module size (width × height) / 250*250 (mm) Brightness (nit)
  • Page 10: Pictures Of Panels

    Series User Manual 3.4 Pictures of panels Panel size: 500mm*500mm Panel size: 500mm*750mm...
  • Page 11: Pictures Of Module

    Series User Manual 3.5 Pictures of module AW modules are divided into 4 types, A module and B module, used for normal standard panel; C module and D module, used for rotating installation panel; Adopt A module and B module, can be assembled into a normal standard panel. Adopt C module and D module, can be assembled into a rotating installation panel;...
  • Page 12: Product Parts Introduction

    Series User Manual 3.6 Product parts introduction Power supply Power box HUB & receiving card Die-cast aluminum Module panel frame 3.7 Pictures of power Power Specifications: Parameter Minimum value Typical value Maximum value unit Output voltage range Input voltage range...
  • Page 13: Pictures Of Receiving Card

    (air switch), arrester (optional), timer, function card, time delay unit, voltage indicator, current indicator, Thermal relay, e.tc Classified by power capacity: Absen mainly has 15KW, 30KW, 60KW, 90KW, 120KW, 150KW, 180KW distribution boxes. Classified by control mode: intelligent distribution box, ordinary distribution box.
  • Page 14: Packing

    Series User Manual Classified by application: indoor and outdoor. Distribution box and main cable selection Distribution box specification 15KW 30KW 45KW 60KW 4*4+1*2.5 4*10+1*6 4*16+1*10 4*25+1*16 International copper core cable model(mm²) Distribution box specification 90KW 120 KW 150 KW 180 KW 4*50+1*35 4*70+1*35 4*95+1*50...
  • Page 15: Installation Procedure

    Series User Manual 4 Installation procedure 4.1 Installation Notes: The panel is waterproof front and rear, and can be directly installed naked. It can be installed from front and rear. It cannot be installed directly against the wall. When the panel is installed naked, there is no need for any covering on the edges or any other decorations.
  • Page 16 Series User Manual Place the connecting piece behind the square pass, pass the bolt through the connecting piece and lock and fix the cabinet body. Use screws and nuts to lock the cabinet and the cabinet; Note: Make sure that the cabinet is level and there is no misalignment before tightening the screws...
  • Page 17: Rear- Installation

    Series User Manual Connect the network cable and power cable between the cabinet; Check whether the power cord and network cable of the screen are properly plugged in; Note: The power supply needs to be tested before powering on to ensure that the power cord wiring is correct before powering on;...
  • Page 18 Series User Manual 1、 Place the two cabinets side by side on the bottom beam of the steel structure, and pass the bolts through the connecting piece and the connecting hole of the cabinet lock fixing part; 2、 Use screws to pass through the left and right connecting holes of the cabinet , and lock with nuts;...
  • Page 19: Cable Connection

    Series User Manual 5 Cable connection 5.1 Cable connection Plug the power and network cables on the left side of the back of the cabinet into the power socket and network cable socket of the next cabinet. To avoid electric shock, please do not power on when plugged in.
  • Page 20: Product Maintenance

    Series User Manual 6 Product maintenance 6.1 Module replacement 6.1.1 Front-installation module remove AW2.8 modules use the front maintenance tool to remove the modules, and keep the magnetic suction tool energized during the suction process to prevent the module from falling remove AW3.9 modules Insert the T-type wrenches into the front maintenance hole of the...
  • Page 21 Series User Manual 2、Disassembly module: unscrew the 8 hexagonal screws in order; Note: Please hold the handle of the module when loosening the last screw, to prevent the module flip forward and fall down. 3、Push the front module forward and pass through the middle of the box. 4、When installing a new module, pass the module through the middle of the box, push it to the front of the screen, and then fix the module on the box.
  • Page 22: Common Installation Problems

    Series User Manual 6、Tighten the hexagon socket screws of the power box in turn; 6.2 Common installation problems 6.2.1 Front-maintenance power box 1. Remove the module of the box first, for details, please refer to the "Front-maintenance module". 2Remove the front maintenance screws of the power supply box as below: 3 Unplug the network and ground cables from the power box, and then remove the power box from the back of the screen;...
  • Page 23: Common Installation Issues

    Series User Manual box. For prevent electric shock and product damage: please turn off the power of the screen when removing the power supply box. 7 Common installation issues 7.1 Large gap between the panels 1. Check whether the bottom support beam of the panel is level; 2.
  • Page 24: Common Faults And Troubleshooting

    Series User Manual 8 Common faults and troubleshooting Common problems Solution 1. Check whether the power plug of the corresponding module is tightly inserted; 2. Check whether the power cable of the corresponding module is burnt out; 3. Check whether the switch power supply of the corresponding module has no output;...
  • Page 25 1. Check whether the setting of the playback window is normal; No full screen display 2. Check the output resolution of the video processor; 3. Check the output window of the video processor; Shenzhen Absen Optoelectronic Co., Ltd. 18-20F Building 3A, Cloud Park, Bantian, Longgang District, Shenzhen 518129, P.R.China...
