IR Dome Camera User Manual
The product image may differ from the actual product.
Please use this camera with a DVR which supports HD video recording.
Please read the instructions thoroughly before using the product.
C
C
A
A
U
U
T
T
I
I
O
O
N
N
:
:
To reduce the risk of electric shock, do not expose this apparatus to rain or moisture.
Only operate this apparatus from the type of power source indicated on the label.
The company shall not be liable for any damages arising out of any improper use, even if we have been advised of the possibility of
such damages.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence
of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
This exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
ROHS Announcement
All lead-free products offered by the company comply with the requirements of the European law on the Restriction
of Hazardous Substances (RoHS) directive, which means our manufacture processes and products are strictly
"lead-free" and without the hazardous substances cited in the directive.
The crossed-out wheeled bin mark symbolizes that within the European Union the product must be collected
separately at the product end-of-life. This applies to your product and any peripherals marked with this symbol. Do
not dispose of these products as unsorted municipal waste.
CE Mark
This apparatus is manufactured to comply with the radio interference.
The company does not warrant that this manual will be uninterrupted or error-free. We reserve the right to revise or
remove any content in this manual at any time.
C
C
A
A
U
U
T
T
I
I
O
O
N
N
R
I
S
K
O
F
E
L
E
C
T
R
I
C
S
H
O
R
I
S
K
O
F
E
L
E
C
T
R
I
C
S
H
O
C
K
C
K
696Z
d206x_V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DG206 and is the answer not in the manual?

Questions and answers

Related Manuals for Avtech DG206

Summary of Contents for Avtech DG206

  • Page 1 696Z IR Dome Camera User Manual The product image may differ from the actual product. Please use this camera with a DVR which supports HD video recording. Please read the instructions thoroughly before using the product. To reduce the risk of electric shock, do not expose this apparatus to rain or moisture. Only operate this apparatus from the type of power source indicated on the label.

  • Page 2: Package Content

    FEATURES 1. 1/2.9” CMOS Sensor 2. 1080P video output 3. f2.8 ~ 12mm vari-focal lens 4. Low light sensitivity of 0.1 Lux / F1.4(Wide)~F2.8(Tele), 0Lux (IR LED ON) 5. IP66 for weather-proof application PACKAGE CONTENT  IR camera  User manual ...

  • Page 3: Installation

    INSTALLATION Step1: Find the screw on the camera, and remove it with the supplied wrench. Then, remove the camera base as shown in Figure 1, and disassemble the camera to four parts as shown in Figure 2. Figure 1 Figure 2 Step2: Locate where you want to install this camera (wall or ceiling), and drill holes on the wall or ceiling for securing the bracket and routing the cables (if necessary).
  • Page 4 Step5: Slightly adjust the camera lens to where it’s supposed to face, and replace Part 1 and Part 2 back, as shown in Figure 5 and Figure 6. Step6: Hold the camera lens and Part 1, rotate only Part 2 clockwise to the end, and replace the screw removed in Step1 back, as shown in Figure 6.

  • Page 5: Camera Parameters

    CONNECTION 1. DC12V Input Terminal Connect the power terminal of the camera to a DC 12V regulated power supply. NOTE: Please use the correct power adaptor, DC12V (regulated), to operate this unit. The power tolerance of this unit is DC12V ± 10%. Over maximum DC 12V power input will damage this unit.
  • Page 6 MENU DESCRIPTION EXPOSURE LENS TYPE No function. SHUTTER AUTO / 1/25 / 1/30 / 1/50 Set the shutter speed for exposure. / 1/60 / 1/100 / 1/ 120 / 1/250 / 1/500 / 1/1000 / 1/3000 / 1/10000 OFF / LOW / MIDDLE / Set the level of Auto Gain Control to automatically HIGH adjust the image when the light level changes.
