madbeanpedals Woodshed Manual

Woodshed Woodshed
F
FUZZ
X Type:
Build Level: Beginner
Based On: Arbiter® Fuzz Face™
The Woodshed is a "catch-all" style silicon Fuzz Face™. It delivers stock FF sounds plus a lot
more. The extra features include a bass control, "squish" knob for bumblebee fuzz and an external
bias control.
• VOL: Total effect output.
• FUZZ: Fuzz amount.
• SUBS: CCW is the stock Fuzz Face™. Turning SUBS CW will reduce the bass into the circuit
for smoother overdrive-like tone.
• SQUISH: CCW is the stock setting. Going CW increases the feedback resistance between Q2
and Q1 to squash the fuzz into nothingness, like my soul.
• BIAS: This allows you to change the biasing voltage of Q2. At medium settings you can get
some EJ style fuzz. High settings will also squish the fuzz sound.
• BOOST: This trimmer will increase the volume output as it is turned up.
• T1: This trimmer is used to set the range of the BIAS control. See notes.
Further study:
http://www.geofex.com/Article_Folders/fuzzface/fffram.htm
https://www.electrosmash.com/fuzz-face
Terms of Use: You are free to use purchased Woodshed circuit boards for both DIY and small commercial operations. You may not offer Woodshed PCBs for
resale or as part of a "kit" in a commercial fashion. Peer to peer re-sale is fine, though.
Technical assistance for is available via the
available to respond via email in a timely and continuous manner, and (2) posting technical problems and solutions in the forum creates a record from which other
members may benefit.
All copyrights and registered trademarks are property of their original owners. Any mention of trademarked or intellectual properties in this documents is purely for
comparative purposes.
Overview
Controls
madbeanpedals forum. Please go there rather than emailing me for personal assistance. This is because (1) I'm not always
Last Updated:
April 25, 2024 9:24 AM
© 2024 madbeanpedals
