PUIG NG SPORT 20467 Mounting Instructions

M O
R EF 20 467
1 Person
15 min
EASY
ID PIEZA/PART
1
2
3
4
5
6
7
8
9
V1.02/22
STREETFIGHTER V4 '20-/ V2 '22-
U N T I N G
DESCRIPCIÓN
Cúpula Sport
Soporte Izquierdo
Soporte derecho
Casquillo Ø8,5 x Ø12 x 15mm
Tornillo M8x45 DIN912 12.9
Silentblock Ø9 x Ø6 x 8mm
Casquillo con valona Ø12 x Ø6,8 x 7,3
Tornillo Allen M5x16 Ø11 ISO 7380
Tapón tornillo M5 ISO 7380
www.puig.tv
www.puigusa.com
DUCATI
I N S T R
WINDSHIE L D NG SPORT
DESCRIPTION
Sport screen
Left support
Right support
Ø8,5 x Ø12 x 15mm Arrowhead
M8 x 45 DIN912 12.9 screw
Ø9 x Ø6 x 8mm Silentblock
Ø12 x Ø6,8 x 7,3 bush with flange
M5x16 Ø11 ISO 7380 Allen screw
M5 ISO 7380 screw cap
Pg. 1/2
info@puigusa.com
U C T I O N
QTY
1
1
1
2
2
4
4
4
4
Illustrations and layout by: www.ciandisseny.com
info@puig.tv
S
ALLEN
Nº 2,3
Nº 2,6
REF
20467W/H/F/NM3
SOPOR2P2-L20467
SOPOR2P2-R20467
CASQUI------864
TORNI-D912 --622
AROPASACABLES-3
CASQUI-1A---750
TORNI-I7380-493
TAPON--------85
