HONDA CB750 HORNET '25-
M
O
RE F 22 4 23
1 Person
30 min
EASY
ID
PIEZA/PART
1
2
3
4
5
6
7
8
9
10
*
Algunos componentes se suministran montados.
Some components are supplied assembled.
U
N
T
I
N
G
DESCRIPCIÓN
Cúpula Sport
Soporte izquierdo
Soporte derecho ( )
Tornillo Allen M5x10 Ø11 ISO 7380
Arandela de nylon Ø6,4 x Ø16 x 1mm
Arandela de goma Ø4,5 x Ø11 x 2mm
Silentblock Ø12xØ6x9
Casquillo con valona Ø12xØ6,8x7,3
Tornillo Allen M5x16 Ø11 ISO 7380
Tapón tornillo M5 ISO 7380
www.puig.tv
www.puigusa.com
I
N
S
T
R
W INDS HIELD N G SPORT
DESCRIPTION
Sport screen
Left support
Right support ( )
M5x10 Ø11 ISO 7380 Allen screw
Ø6,4 x Ø16 x 1mm nylon washer
Ø4,5 x Ø11 x 2m rubber washer
Ø12xØ6x9 silentblock
Ø12xØ6,8x7,3 bush with flange
M5x16 Ø11 ISO 7380 Allen screw
M5 ISO 7380 screw cap
Pg. 1/4
info@puigusa.com
U
C
T
I
O
N
QTY
1
1
1
4
4
4
3
3
3
3
Illustrations and layout by: www.ciandisseny.com
info@puig.tv
S
ALLEN
Nº 3
Nº 5
REF
22423H/W/F/N/
J/A/R/CM3
SOPOR2P2-L22423
SOPOR2P2-R22423
TORNI-I7380-909
ARAND------701
AROPASACABLES-1
CASQUI-1A---750
TORNI-I7380-493
TAPON--------85
V0.03/25
