T-Lock Wrap Around Insert Instructions
Items Needed for Installing T-Lock Wrap Around Insert:
T-LOCK Wrap Around Insert - #TLOCKWRAPI
T-Lock Wrap Around Platen Insert
Instructions for Installing the T-Lock Wrap Around Insert:
Below are instructions for installing the T-Lock Wrap Around Insert on your T-Lock Platen Base.
1
Step 1:
Insert the T-Lock Base into the platen stem of the Brother DTG printer.
3
Step 3:
Insert the T-Lock Wrap Around Insert into the T-Lock Base.
BrotherDTG.com/Support • Visit www.BrotherDTG.com/Guides for additional platen instructions
T-Lock Base - #TLOCKBASE
T-Lock Base needed for using Inserts
2
Step 2:
Adjust the height of the platen and tighten the locking lever.
4
Step 4:
Secure the T-Lock Wrap Around Insert by rotating the center piece in the
T-Lock brackets.
