- Page 1 INSTALLATION GUIDE FOR THE OPTIFLAME ELECTRIC FIREPLACE MODEL NUMBERS: BF33ST/DX BF39ST/DX HBI39ST/DX BF45ST/DX HBI45ST/DX 7206350200REV01...
-
Page 2: Table Of Contents
CONTENTS PAGE 1 Listings and Code Approvals PAGE 1 Model Specifications PAGE 1 Step-by-Step Installation Section A PAGE 2 Framing Section B PAGE 2 Recommended Power Supply Wire Specifications PAGE 2 Recommended Wire and Fusing Requirements PAGE 3 Voltage Selector Switch Location PAGE 3 Mounting Flanges Section C... -
Page 3: Listings And Code Approvals
LISTINGS AND CODE APPROVALS The BF series fireplaces have been tested in accordance with the UL 2021and CSA C22.2 No. 46 standards for fixed and location-dedicated electric room heaters. MODEL SPECIFICATIONS Rated Power Model Voltage Remote Wall Refractory AMPS AMPS AMPS Description Watts... -
Page 4: Section A
SECTION A: FRAMING Optiflame Dimensions MODEL BF33ST/DX 15.0” 33.5” 29.5” 23.0” 14.3” 29.6” 32.8” 18.8” 28.5” 48.0” 34.0” 34.0” BF39ST/DX 16.0” 39.5” 33.5” 26.6” 15.3” 36.0” 38.7” 22.8” 32.7” 54.0” 38.0” 38.0” BF45ST/DX 16.0” 45.5” 33.5” 26.6” 15.3” 42.0” 44.7” 22.8”... -
Page 5: Voltage Selector Switch Location
VOLTAGE SELECTOR SWITCH LOCATION IMPORTANT: Ensure that the incoming power supply voltage matches the setting of the voltage selector switch. NOTE: The voltage selector switch is located inside the exhaust panel on the top right hand corner. CAUTION: When changing the voltage selector switch from 240 volts to 120 volts ensure that the power supply is turned FIGURE 1... -
Page 6: Section C
SECTION C: FACTORY SETTING WIRING (WITHOUT MAIN POWER WALL SWITCH) IMPORTANT: The unit is factory configured for 208/240 volt operation NOTE: Use 3 conductor wire with ground (4 wires total) from the power supply (breaker panel) to the junction box on the unit. NOTE: All wiring must be completed prior to installing the unit. -
Page 7: (Without Main Power Wall Switch)
SECTION C: FACTORY SETTING WIRING (WITHOUT MAIN POWER WALL SWITCH) IMPORTANT: The unit is factory configured for 208/240 volt operation NOTE: Use 2 conductor wire with ground (3 wires total) from the power supply (breaker panel) to the junction box on the unit. NOTE: All wiring must be completed prior to installing the unit. -
Page 8: Section D
SECTION D: MAIN POWER WALL SWITCH WIRING OPTIONS MAIN POWER WALL SWITCH WIRING FOR 240 VOLT NOTE: This option should not be used with the remote control kit. NOTE: Before installing the unit you must have the following wires installed: 1. - Page 9 240 VOLT MAIN WALL SWITCH WIRING DIAGRAM WHITE - N WHITE – N 240 V RED – L2 RED – L2 POWER SUPPLY WALL SWITCH BLACK – L1 BLACK – L1 (BREAKER PANEL) GROUND - G GROUND - G...
-
Page 10: Main Power Wall Switch Wiring For 120 Volt
MAIN POWER WALL SWITCH WIRING FOR 120 VOLT NOTE: This option should not be used with the remote control kit. NOTE: Before installing the unit have the following wires installed: 1. A 2 conductor wire with ground (3 wires total) from the power supply panel to the main switch wall box. - Page 11 120 VOLT MAIN WALL SWITCH WIRING DIAGRAM WHITE - N WHITE – N RED – L2 120 V POWER BLACK – L1 SUPPLY (BREAKER WALL PANEL) BLACK – L1 SWITCH GROUND - G GROUND - G...
-
Page 12: Section E
SECTION E: HEATER WALL SWITCH AND WALL THERMOSTAT WIRING OPTIONS HEATER WALL SWITCH WIRING FOR 120/240 VOLT NOTE: Before installing the unit complete the following: 1. Install main power connection with appropriate voltage as per Section C or Section D. 2. - Page 13 HEATER WALL SWITCH WIRING DIAGRAM FOR 120/240 VOLT (SEE SECTION C OR SECTION D FOR MAIN POWER CONNECTION) RED – 2 WALL RED – 1 SWITCH GROUND - G...
-
Page 14: Wall Mounted Thermostat Wiring For 120/240 Volt
WALL MOUNTED THERMOSTAT WIRING FOR 120/240 VOLT NOTE: Before installing the unit complete the following: 1. Install main power connection with appropriate voltage as per Section C or Section D. 2. Install a 2 conductor wire with ground (3 wires total) from the heater switch wall box to the junction box on the unit. - Page 15 WALL MOUNTED THERMOSTAT WIRING DIAGRAM FOR 120/240 VOLT (SEE SECTION C OR SECTION D FOR MAIN POWER CONNECTION) RED – 2 WALL RED – 1 THERMOSTAT GROUND - G...
-
Page 16: Flame Override Switch Wiring For 120/240 Volt
FLAME OVERRIDE SWITCH WIRING FOR 120/240 VOLT NOTE: The fireplace can be wired to have a wall switch operate the heater independent of the flame NOTE: Before installing the unit complete the following: 1. Install main power connection with appropriate voltage as per Section C or Section D. - Page 17 FLAME OVERRIDE WALL SWITCH WIRING DIAGRAM FOR 120/240 VOLT (SEE SECTION C OR SECTION D FOR MAIN POWER C0NNECTION) BLUE – 4 WALL BLUE – 3 SWITCH GROUND - G...
-
Page 18: Wiring Diagrams
WIRING DIAGRAM LOWER SECTION BROWN WHITE BLACK BLUE (3) BLUE (4) MARR BLACK RED (2) RED (1) WHITE BLACK RED (L2) WHITE (N) - Page 19 WIRING DIAGRAM UPPER SECTION...
- Page 20 WIRING SCHEMATIC...
- Page 21 1-888-DIMPLEX 1-888-346-7539 1367 Industrial Road Cambridge, Ontario Canada, N1R 7G8 Approved for use in the United States and Canada...
