We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com
These instructions apply only to the destination countries listed on the appliance's data plate.
This is a class 3 built-in hob.

PRECAUTIONS

General safety instructions

Risk of personal injury
• During use the appliance and
its accessible parts become
very hot. Keep children well
away from the appliance.
• Protect hands with heat resistant
gloves during use.
• Never try to put out a fire or
flames with water: Turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
• This appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
22 - PRECAUTIONS
22
22
25
26
27
27
27
27
27
27
28
28
28
29
29
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
• Children must not play with the
appliance.
• Keep children under the age of
eight at a safe distance unless
they are constantly supervised.
• Keep children under the age of
8 away from the appliance
when it is in use.
• Cleaning and maintenance
must not be carried out by
29
29
29
30
30
31
31
32
32
35
35
36
36
37
38
38
91477A886/B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PV164B3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smeg PV164B3

Summary of Contents for Smeg PV164B3

  • Page 1: Table Of Contents

    We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com These instructions apply only to the destination countries listed on the appliance's data plate.
  • Page 2 unsupervised children. tins or containers or plastic • Make sure that the flame- containers. spreader crowns are correctly • Do not insert pointed metal positioned in their housings with objects (cutlery or utensils) into their respective burner caps. the slots in the appliance. •...
  • Page 3 the glass cooking surface a support surface. breaks, turn off the appliance • Do not use the appliance as a immediately. Disconnect the support surface. power supply and call • Do not obstruct ventilation Technical Support. openings and heat dispersal •...

  • Page 4: Installation

    substances that could melt or • Before installation, make sure catch fire (paper, plastic or that the local distribution aluminium foil) on the conditions (type and pressure appliance while it is in use. of the gas) and the regulation • Do not place pans directly on of the appliance are the burners.

  • Page 5: Appliance Purpose

    current regulations. qualified technician. • After carrying out any • If the power cable becomes operation, check that the damaged, contact technical tightening torque of gas support immediately to arrange connections is between 10 Nm for it to be replaced in order to and 15 Nm.

  • Page 6: This User Manual

    considered inappropriate. It with current European directives. cannot be used: Power voltage Danger of electrocution • in employee kitchens, shops, offices and other working • Disconnect the mains power supply. environments. • Unplug the appliance. • in farms/farmhouses. To dispose of the appliance: •...

  • Page 7: How To Read The User Manual

    saucepan leads to a waste of energy. conventions: How to read the user manual Warning/Caution This user manual uses the following reading Information/Advice DESCRIPTION General description and turn the knobs anti-clockwise to AUX: Auxiliary burner order to light the relative burners. Turn the knobs SR: Semi-rapid burner to the zone between the maximum RR: Rapid burner reduced...

  • Page 8: Use

    Precautions burner, so that the flames do not reach up the sides of the pan. Once the contents come to the boil, turn down the flame far enough to ensure See General safety instructions. that the liquid does not boil over. Burner Pan diameter A gas leak can cause an explosion.

  • Page 9: Cleaning And Maintenance

    the knob and turn it anti-clockwise to the • Never use the griddle for more than 40 maximum flame symbol, until the burner ignites. If minutes. the burner does not light in the first 15 seconds, Correct positioning of the flame-spreader turn the knob to and wait 60 seconds crowns and burner caps...

  • Page 10: Cleaning The Hob

    Weekly cleaning them thoroughly and return them to the hob. Clean and maintain the hob once a week using The continuous contact between the an ordinary glass cleaning product. Always pan supports and the flame can cause follow the manufacturer’s instructions. The silicon modifications to the enamel over time in in these products creates a protective, water- those parts exposed to heat.

  • Page 11: Installation

    ventilated and that the air inlets are The fuses blow or the circuit breaker of the unobstructed. residential electrical system trips repeatedly. • Call Technical Support or an electrician. The hob smokes: • Let the hob cool down and clean it once There are cracks or fissures in the hob: cooking is complete.
  • Page 12 comply with the applicable standard. Extraction of the combustion products The combustion products may be extracted by means of hoods connected to a natural draught chimney whose efficiency is certain or via forced extraction. An efficient extraction system requires precision planning by a specialist qualified in this area and must comply with the positions and clearances indicated by the applicable standards.
  • Page 13 1. Remove the grids from the hob top. 6. Adjust the air flow by moving the air regulator B to obtain the distance D given in the corresponding table (see "Gas types and countries"). 7. After adjusting each burner, reassemble the appliance correctly.

  • Page 14: Gas Types And Countries

    replace the lubrication grease. Lubrication of the gas cocks should be performed by a specialised technician. Gas types and Countries Gas types 1 Natural Gas G20 20 mbar • • • • • • • • 20/25 mbar G20/25 • 2 Natural Gas G20 25 mbar •...

  • Page 15: Electrical Connection

    5 LPG G30/31 - 30/37 mbar Rated heating capacity (kW) 1.70 Nozzle diameter (1/100 mm) Reduced flow rate (W) 1050 1050 Primary air (mm) Rated flow rate G30 (g/h) Rated flow rate G31 (g/h) 6 LPG G30/31 - 37 mbar Rated heating capacity (kW) 2.55 Nozzle diameter (1/100 mm)

  • Page 16: Mounting

    competent technician. Hob seal • The minimum clearance between exhaust To prevent leakage of liquid between the frame hoods and the cooking surface must be at of the hob and the countertop, place the least the distance indicated in the exhaust adhesive seal provided along the entire outer hood installation instructions.

  • Page 17: Fixing To The Built-In Cabinet

    base using suitable equipment. Instructions for the installer • If you use a plug to connect to the power supply, the plug must be accessible after installation. • Do not bend or trap the power cable. • The appliance must be installed according to the installation diagrams.
