  • Page 1 Z5777/Z5790 Rigging manual 1.1 en...
  • Page 2 General information Z5777/Z5790 Rigging manual Version: 1.1 en, 06/2023, D2758.EN .01 Copyright © 2023 by d&b audiotechnik GmbH & Co. KG; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference. We recommend you to regularly check the d&b website for the latest version of this document.

  • Page 3: Table Of Contents

    Contents Contents Z5777/Z5790 XSL(i) Stacking frame......4 1.1 Safety precautions and intended use........4 1.2 Scope of supply................4 Assembly/Disassembly............. 6 2.1 Operational safety..............6 2.2 Tension mode rigging..............6 2.3 Locking pins/Fixing bolts............6 2.4 First cabinet to frame - Instruction label........7 2.5 Adding further cabinets..............

  • Page 4: Z5777/Z5790 Xsl(I) Stacking Frame

    Z5777/Z5790 XSL(i) Stacking frame Z5777/Z5790 XSL(i) Stacking frame 1.1 Safety precautions and intended use In connection with XSL/XSLi-TOP groundstacks, the d&b Z5777/Z5790 XSL/XSLi Stacking frames are used to provide an adequate and stable ground support for groundstack setups on top of applicable d&b subwoofers or other suitable surfaces.
  • Page 5 Z5777/Z5790 XSL(i) Stacking frame Z5790 XSLi Stacking frame The Z5790 XSLi Stacking frame is equipped and supplied with the following components. Please verify the shipment for completeness and proper condition of the items. Pos. Qty. Description Z5790 XSLi Stacking frame Including: Rubber feet Threaded fixing bolt (M12) 9 x 39 mm...

  • Page 6: Assembly/Disassembly

    Assembly/Disassembly Assembly/Disassembly 2.1 Operational safety The assembly should always be carried out by two persons. During assembly pay attention to the possible risk of crushing. Wear suitable protective clothing. Observe all instructions given on the respective instruction labels of the rigging components and loudspeaker cabinets. 2.2 Tension mode rigging NOTICE! For safety and stability reasons, XSL-TOP cabinets must always be...

  • Page 7: First Cabinet To Frame - Instruction Label

    Assembly/Disassembly 2.4 First cabinet to frame - Instruction label The rear center Splay link slot of the frame allows the first cabinet to be set to downtilt angles from 0° to –10° in 2° increments. To attach the first cabinet to the frame, proceed as follows: 1.

  • Page 8: Adding Further Cabinets

    Assembly/Disassembly 2.5 Adding further cabinets To add further cabinets, proceed as follows: 1. Extend the Front links of the first cabinet on both sides. ↳ The Front links are spring loaded and therefore extend automatically as soon as the Locking pins are released and pulled out.

  • Page 9: Safety And System Checks

    Assembly/Disassembly Front links of the last (uppermost) cabinet NOTICE! Potential risk of damage to the rigging components. To avoid any damage to the Front links of the uppermost cabinet of the ground stack, ensure these Front links are kept in their park positions on both sides.

  • Page 10: Care And Maintenance

    Care and maintenance Care and maintenance 3.1 Transport / Storing During transport ensure the stacking frame is not stressed or damaged by mechanical forces. Use suitable transport cases. Due to their surface treatment the rigging components are temporarily protected against moisture. However, ensure the components are in a dry state while stored or during transport.

  • Page 11: Manufacturer's Declarations

    Manufacturer's declarations Manufacturer's declarations 4.1 Conformity of rigging components This declaration applies to: d&b Z5777 XSL Stacking frame (Including all additional items) d&b XSL TOP loudspeaker cabinets (With integrated rigging components) ▪ Z0770 XSL8 ▪ Z0772 XSL12 d&b Z5790 XSLi Stacking frame (Including all additional items) d&b XSLi TOP loudspeaker cabinets (With integrated rigging components)
  • Page 12 www.dbaudio.com...
