Midea MAP05S1AWT User Manual page 13

Confirm your window type (window type and opening size of different types)
l S d i n i g W n i d o w n I s a t l l t a o i n H u n g W n i d o w n I s a t l l t a o i n
For optimal performance in operation
INCORRECT
CORRECT
NOTE:
To ensure proper function, DO NOT overextend
or bend the hose. Make sure that there is no
obstacle around the air outlet of the exhaust
hose (in the range of 500mm) in order to ensure the
exhaust system works properly. All the illustrations
in this manual are for explanation purpose only.
The actual shape will remain the same.
