mPower Electronics UNI LITE MP112 Series Quick Start Manual

UNI
MP112 & MP112RT
Quick Start Guide
mPower Electronics Inc.
2910 Scott Blvd. Santa Clara, CA 95054
www.mpowerinc.com
info@mpowerinc.com
PN:M027-4007-000
Read Before Operating
The User's Guide must be carefully read by all
individuals who have or will have the responsibility of
using, maintaining, or servicing this product. The
product will perform as designed only if it is used,
maintained, and serviced in accordance with the
manufacturer's instructions.
User Interface
The UNI's user interface consists of the LCD
display, LEDs, an alarm buzzer, one push-button key,
an alligator clip, and a chemical sensor.
LED Alarm
Window
LCD
Display
Buzzer
Sensor and
Gas Inlet
LITE
Series
Alligator clip
Concentration
or Time Left
Low Battery
Indication
Programming
& On/Off key
Sensor ID
Product Label
with Sensor ID
Warning
•
Never operate the monitor when the cover is removed.
•
Remove the monitor cover and battery only in area known
as non-hazardous.
•
Use only mPower's lithium battery part number M500-
0038-000 (EVE 14335) (3.6 V, 1650 mAh, 2/3 AA size).
•
This instrument has not been tested in an explosive gas/air
atmosphere having oxygen concentration greater than 21%.
•
Substitution of components will impair suitability for
intrinsic safety and void warranty.
•
It is recommended to bump test with a known
concentration gas to confirm the instrument is functioning
properly before use.
•
Before use, ensure that the colorless ESD layer on the
display is not damaged or peeling. (The blue protective film
may be removed.)
Avertissement
•
N'utilisez jamais le moniteur lorsque le couvercle est enlevé.
•
Retirer le couvercle du moniteur et la batterie uniquement
dans une zone connue comme non dangereuse.
•
Utilisez uniquement le numéro de pièce de la batterie au
lithium mPower M500-0038-000 (EVE 14335) (3.6 V, 1650
mAh, 2/3 AA grandeur).
•
Cet instrument n'a pas été testé dans une atmosphère
explosive gaz / air ayant une concentration en oxygène
supérieure à 21%.
•
La substitution de composants compromettra l'aptitude à la
sécurité intrinsèque et annulera la garantie.
•
Il est recommandé de tester avec un gaz de concentration c
onnu pour confirmer que l'instrument fonctionne correctem
ent avant de l'utiliser.
•
Avant l'utilisation, assurez-vous que la couche ESD incolore
de l'écran n'est pas endommagée ou épluchée. (Le
film protecteur bleu peut être enlevé.)
v1.0
Press and hold the Operation Key (
seconds, until the LCD displays "On" enters a self-
test sequence, and then enters Normal Mode . Once
the unit is turned on, it cannot be turned off and runs
continuously until the remaining lifetime ends.
MP112 vs MP112RT Display
The MP112 shows lifetime remaining starting at
24 months, while the MP112RT displays real-time
concentrations for the first 21 months and then
switches to time remaining for the last 90 days. Both
units alarm and display the alarm type if any pre-set
limit is exceeded.
Normal Mode Menus
From Normal Mode:
1) Short press to show the Peak reading and long
press twice to clear the Peak. Or Short press
again to enter EVT LOG, long-press until the
beep to show the latest alarm event A1 and then
short-press repeatedly to cycle through the last
10 alarm events. Up to 50 events can be viewed
using mPower Suite.
2) Press 2 secs to initiate a Daily Alarm Test and
cycle through the High & Low Alarm settings,
Bump Due days remaining and User ID. MP112
also shows Cal Due days and remaining life.
3
3) Press 4 secs to go to Configuration Mode.
Turning the Unit On
2
) for 3
