Intex PRISM FRAME 26795EH Owner's Manual page 9

Non-USA & Canada:
14
15
16
17
(Pre-installed in #6)
18
(Pre-installed in #2, #4 & #5)
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
REF.
NO.
1 SINGLE BUTTON SPRING
2 HORIZONTAL BEAM (A) (SINGLE BUTTON SPRING INCLUDED)
3 HORIZONTAL BEAM (B) (SINGLE BUTTON SPRING INCLUDED)
4 HORIZONTAL BEAM (C)
5 HORIZONTAL BEAM (D) (SINGLE BUTTON SPRING INCLUDED)
6 CORNER JOINT
7 U-SUPPORT END CAP
8 DOUBLE BUTTON SPRING CLIP
U-SHAPED SIDE SUPPORT (U-SUPPORT END CAP &
9
DOUBLE BUTTON SPRING CLIP INCLUDED)
10 CONNECTING ROD
11 RESTRAINER STRAP
12 GROUND CLOTH
13 POOL LINER (DRAIN VALVE CAP INCLUDED)
14 DRAIN CONNECTOR
15 DRAIN VALVE CAP
16 POOL COVER
17 PLASTIC INSERT FOR CORNER JOINT
18 PLASTIC INSERT FOR HORIZONTAL CORNER PIPE
SAVE THESE INSTRUCTIONS
(85PO) PRISM FRAME™ OVAL PREMIUM POOL ENGLISH 7.5" X 10.3" PANTONE 295U 05/13/2020
1
2
13
12
DESCRIPTION
6
4
3
9
10 11
16.5'x9'x48"
(503cmx274cmx122) (610cmx305cmx122CM)
SPARE
QUANTITIES QUANTITIES
PART NO.
4 10381
2 12788
2 12789
2 12790
6 12757
8 12758
24 10379
24 10382
12 12482
12 10383
12 10938
1 10759
1 12736
1 10184
2 11044
1 12738
16 11156
16 11157
English
85PO
5
7
8
20'x10'x48"
SPARE
PART NO.
6 10381
2 12788
4 12789
2 12790
6 12759
8 12760
28 10379
28 10382
14 12482
14 10383
14 10938
1 12740
1 12737
1 10184
2 11044
1 12739
16 11156
16 11157
Page 8
