PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
REF.
NO.
1 SINGLE BUTTON SPRING
2 HORIZONTAL BEAM (A) (SINGLE BUTTON SPRING INCLUDED)
3 HORIZONTAL BEAM (B) (SINGLE BUTTON SPRING INCLUDED)
4 HORIZONTAL BEAM (C)
5 HORIZONTAL BEAM (D) (SINGLE BUTTON SPRING INCLUDED)
6 CORNER JOINT
7 U-SUPPORT END CAP
8 DOUBLE BUTTON SPRING CLIP
U-SHAPED SIDE SUPPORT (U-SUPPORT END CAP &
9
DOUBLE BUTTON SPRING CLIP INCLUDED)
10 CONNECTING ROD
11 RESTRAINER STRAP
12 GROUND CLOTH
13 POOL LINER (DRAIN VALVE CAP INCLUDED)
14 DRAIN CONNECTOR
15 DRAIN VALVE CAP
16 POOL COVER
17 STRAINER HOLE PLUG
18 STRAINER CONNECTOR
19 STRAINER GRID
20 HOSE
21 HOSE CLAMP
22 SPLIT HOSE PLUNGER VALVE
23 HOSE O-RING
24 PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED)
25 STEP WASHER
26 STRAINER NUT
27 FLAT STRAINER RUBBER WASHER
28 INLET THREADED AIR CONNECTOR +
29 ADJUSTABLE POOL INLET JET NOZZLE
30 AIR JET VALVE
31 AIR JET VALVE CAP (NOT SHOWN)
32 PLASTIC INSERT FOR CORNER JOINT
33 PLASTIC INSERT FOR HORIZONTAL CORNER PIPE
+ If applicable, depending on the size of the filter pump fitted with your pool, you must quote the model
number shown on the filter pump housing to order the correct size of "Pool Inlet Air Adaptor" or "Inlet
Threaded Air Connector" replacement part.
SAVE THESE INSTRUCTIONS
(85PO) PRISM FRAME™ OVAL PREMIUM POOL ENGLISH 7.5" X 10.3" PANTONE 295U 05/13/2020
and become familiar with all the parts.
DESCRIPTION
16.5'x9'x48"
(503cmx274cmx122) (610cmx305cmx122CM)
SPARE
QUANTITIES QUANTITIES
PART NO.
4 10381
2 12788
2 12789
2 12790
6 12757
8 12758
24 10379
24 10382
12 12482
12 10383
12 10938
1 10759
1 12736E
1 10184
2 11044
1 12738
2 10127
2 11070
2 11072
2 11873
4 10122
1 11872
1 10262
1 10747
1 10745
1 10256
1 10255
12371
1
12372
1 12369
1 12363
1 12373
16 11156
16 11157
English
85PO
20'x10'x48"
SPARE
PART NO.
6 10381
2 12788
4 12789
2 12790
6 12759
8 12760
28 10379
28 10382
14 12482
14 10383
14 10938
1 12740
1 12737E
1 10184
2 11044
1 12739
2 10127
2 11070
2 11072
2 11873
4 10122
1 11872
1 10262
1 10747
1 10745
1 10256
1 10255
12371
1
12372
1 12369
1 12363
1 12373
16 11156
16 11157
