POOL SETUP ( continued )
You may have purchased this pool with the Intex Krystal Clear™ filter pump. The pump has its
own separate set of installation instructions. First assemble your pool unit and then set up the
filter pump.
Estimated assembly time 60~90 minutes. (Note the assembly time is only approximate and
individual assembly experience may vary.)
1. • F ind a flat, level location that is free and clear of stones, branches or other sharp objects that may
puncture the pool liner or cause injury.
• O pen the carton containing the liner, joints, legs, etc., very carefully as this carton can be used to store
the pool during the winter months or when not in use.
• R emove the ground cloth (12) from carton. Spread
it out completely with its edges being at least 5 - 6'
(1.5 - 2.0 m) from any obstacle such as walls, fences,
trees, etc. Remove the liner (13) from carton and
spread it out over the ground cloth with the drain
valve towards the draining area. Place the drain
valve away from the house. Open it up to warm it
in the sun. This warming will make installation easier.
Make sure the liner is centered atop the ground cloth.
Be sure to face the end with the 2 hose connectors towards the electrical power source.
IMPORTANT: Do not drag the liner across the ground as this can cause liner damage and pool
leakage (see drawing 1).
• During the set-up of this pool liner, point the hose connections or openings in the direction of the
electric power source. The outer edge of the assembled pool is to be within reach of the electrical
connection for the optional filter pump.
2. Remove all the parts from the carton(s) and place
them on the ground in the location where they are to
be assembled. Check the parts listing and be sure
all the pieces to be assembled are accounted for
(see drawings 2.1-2.2).
IMPORTANT: Do not start assembly if any pieces
are missing. For replacement pieces call the
Consumer Service telephone number in your area.
After all pieces are accounted for move the pieces
away from the liner for of installation.
NOTE: Sprinkle some talcum powder over the
horizontal beams before sliding them into the pool
liner sleeve. This will make removal of the beams
from the liner easier during the disassembly of the
pool.
SAVE THESE INSTRUCTIONS
(85PO) PRISM FRAME™ OVAL PREMIUM POOL ENGLISH 7.5" X 10.3" PANTONE 295U 05/13/2020
5 - 6' (1.5 - 2.0 m)
LINER
5 - 6'
(1.5 - 2.0 m)
ELECTRICAL SOURCE
CORNER JOINT
(A) (B) (C)
(D)
LINER
(D)
(D)
(D)
(C) (B) (A)
CORNER JOINT
CORNER JOINT
16.5' x 9' x 48"
CORNER JOINT
(A) (B) (B) (C)
(D)
LINER
(D)
(D)
(D)
(C) (B) (B) (A)
CORNER JOINT
CORNER JOINT
20' x 10' x 48"
English
85PO
1
5 - 6'
(1.5 - 2.0 m)
2.1
CORNER JOINT
(D)
(D)
2.2
CORNER JOINT
(D)
(D)
