- Page 1 SKP 2000 Instruction manual...
-
Page 2: Table Of Contents
Using the plug-on transmitter ..............10 Switching the plug-on transmitter on/off ..........10 Deactivating the lock mode temporarily ..........11 Muting the audio signal or deactivating the RF signal ......12 Selecting a standard display ..............14 Using the operating menu ................15 The buttons .................... -
Page 3: Important Safety Instructions
• Heed all warnings and follow all instructions in this instruction manual. • Use only a cloth for cleaning the product. • Do not place the product near any heat sources such as radiators, stoves, or other devices (including amplifiers) that produce heat. -
Page 4: The Skp 2000 Plug-On Transmitter
The SKP 2000 plug-on transmitter The SKP 2000 plug-on transmitter This plug-on transmitter is part of the 2000 series. With this series, Sennheiser offers high-quality state-of-the-art RF transmission systems with a high level of operational reliability and ease of use. Transmitters and receivers permit wireless transmission with studio-quality sound. -
Page 5: The Frequency Bank System
Frequency bank U1 ... U6 Channel 64 – freely selectable frequency Each of the channels in the frequency banks “1” to “20” has been factory- preset to a fixed frequency (frequency preset). The factory-preset frequencies within one frequency bank are intermodulation-free. These frequencies cannot be changed. -
Page 6: Delivery Includes
Delivery includes Delivery includes The packaging contains the following items: 1 SKP 2000 plug-on transmitter 2 AA size batteries, 1.5 V 1 instruction manual 1 POP 1 pouch (with belt clip) 1 frequency information sheet 1 RF power information sheet... -
Page 7: Product Overview
Product overview Product overview Overview of the SKP 2000 plug-on transmitter » Microphone input, XLR-3 socket Operation and battery status (female, unbalanced) indicator, red LED lit = Mechanical locking ring of flashing = LOW BATTERY XLR-3 socket ON/OFF button Infra-red interface... -
Page 8: Overview Of The Displays
Product overview Overview of the displays After switch-on, the plug-on transmitter displays the “Frequency/Name” standard display. For further illustrations and examples of the different standard displays, refer to page 14. The display backlighting is automatically reduced after approx. 20 seconds. -
Page 9: Putting The Plug-On Transmitter Into Operation
Putting the plug-on transmitter into operation Inserting the batteries/accupack For powering the plug-on transmitter, you can either use two 1.5 V AA size batteries or the rechargeable Sennheiser BA 2015 accupack (see “Accessories” on page 30). Slide the battery compartment cover... -
Page 10: Charging The Accupack
Putting the plug-on transmitter into operation Charging the accupack Remove the BA 2015 accupack. Insert the BA 2015 accupack into the L 2015 charger (see “Accessories” on page 30). The L 2015 charger can only charge the BA 2015 accupack. -
Page 11: Using The Plug-On Transmitter
The transmission link is established and the diversity receiver’s RF level display “RF” reacts. It is vital to observe the notes on frequency selection on page 26. If you cannot establish a transmission link between plug-on transmitter and receiver, read the chapter “Synchronizing the plug-on transmitter with a receiver”... -
Page 12: Deactivating The Lock Mode Temporarily
You can activate or deactivate the automatic lock mode via the “Auto Lock” menu item (see page 21). If the lock mode is activated, you have to temporarily deactivate it In order to be able to operate the plug-on transmitter:... -
Page 13: Muting The Audio Signal Or Deactivating The Rf Signal
– When you are in the operating menu, the lock mode remains deactivated until you exit the operating menu. – When one of the standard displays is shown, the lock mode is automatically activated after 10 seconds. The lock mode icon flashes prior to the lock mode being activated again. - Page 14 MUTE. The plug-on transmitter reacts as indicated in the table. The current state of the muting function or the RF signal is displayed on the display panel of the plug-on transmitter: 543.850 **2000**...
-
Page 15: Selecting A Standard Display
Using the plug-on transmitter Selecting a standard display Press the UP/DOWN button to select a standard display: Contents of the display Selectable standard display “Frequency/Name” 543.850 **2000** MUTE “Channel/Frequency” B.Ch: 19.31 543.850 MUTE “Name/Channel” **2000** B.Ch: 19.31 MUTE... -
Page 16: Using The Operating Menu
A special feature of the Sennheiser 2000 series is the consistent, intuitive menu structure of transmitters and receivers. As a result, adjustments to the settings can be made quickly – even in stressful situations, for example on stage or during a live show or presentation. - Page 17 Display Function of the menu item Page Main menu “Menu” Sensitivity Adjusts the sensitivity “AF” Frequency Preset Sets the frequency bank and the channel Name Enters a freely selectable name Auto Lock Activates/deactivates the automatic lock mode Advanced Calls up the extended menu “Advanced...
-
Page 18: Working With The Operating Menu
Using the operating menu Working with the operating menu If the lock mode is activated, you have to deactivate it In order to be able to work with the operating menu (see page 11). By way of example of the “Sensitivity” menu, this section describes how to use the operating menu. - Page 19 Change to the “Exit” menu item. Menu Exit Confirm your selection. You return to the next higher menu level or you exit the operating menu and return to the current standard display. To directly return to the current standard display: Press the ON/OFF button.
-
Page 20: Adjusting Settings Via The Operating Menu
Adjusting settings via the operating menu Make use of the possibility to adjust settings via the operating menu of your receiver and to transfer these settings to the plug- on transmitter. For more information, refer to the instruction manual of the receiver. - Page 21 When setting up multi-channel systems, please observe the following: Only the factory-preset frequencies within one frequency bank (“1” to “20”) are intermodulation-free. It is vital to observe the notes on frequency selection on page 26.
- Page 22 The name can be displayed on the “Frequency/Name” and “Name/Channel” standard displays (see page 14). The name can consist of up to 8 characters such as: • letters (without pronounciation marks), • numbers from 0 to 9, •...
-
Page 23: The Extended Menu "Advanced Menu
Via the “Tune” menu item, you can: 1. set a transmission frequency to be stored in the current channel of the frequency bank (“U1” to “U6”) select a frequency bank (“U1” to “U6”) and a channel and assign this channel a transmission frequency. - Page 24 Adjusting settings via the operating menu Selecting a frequency bank and a channel and assigning this channel a transmission frequency Press the UP/DOWN button until the “Tune” menu item appears. Keep the button pressed until the frequency bank selection appears.
- Page 25 Via the “RF Power” menu item, you can adjust the transmission power in three steps (“Low”, “Standard” and “High”). It is vital to observe the notes on the enclosed frequency information sheet! Activating/deactivating the phantom powering – “PhantomPower 48V” Advanced Menu...
- Page 26 “Stored” The plug-on transmitter adds an inaudible pilot tone to the audio signal. The receiver detects and evaluates the pilot tone, and is thus able to identify the signal of the matching transmitter and mute all others. The pilot tone supports the receiver’s squelch function.
-
Page 27: Synchronizing The Plug-On Transmitter With A Receiver
Make sure that you set the plug-on transmitter to the same frequency bank and the same channel as the receiver (see page 20). If you still cannot establish a transmission link, refer to the chapter “If a problem occurs ...” on page 29. -
Page 28: Cleaning The Plug-On Transmitter
Liquids entering the housing of the device can cause a short-circuit and damage the electronics. Keep all liquids away from the plug-on transmitter. Do not use any solvents or cleansing agents. Use a cloth to clean the plug-on transmitter from time to time. -
Page 29: Recommendations And Tips
... for optimum reception • Transmission range depends to a large extent on location and can vary from about 10 m to about 150 m. There should be a “free line of sight” between plug-on transmitter and receiving antennas. • To avoid overloading the receiver, observe a minimum distance of 5 m between plug-on transmitter and receiving antennas. -
Page 30: If A Problem Occurs
If a problem occurs ... If a problem occurs ... Problem Possible cause Possible solution Plug-on transmitter Lock mode is Deactivate the lock mode cannot be operated, activated (see page 11). “Locked” appears on the display panel No operation Batteries are flat or... -
Page 31: Accessories
Accessories If a problem occurs that is not listed in the above table or if the problem cannot be solved with the proposed solutions, please contact your local Sennheiser partner for assistance. To find a Sennheiser partner in your country, search at www.sennheiser.com under “Service & Support”. -
Page 32: Specifications
(Aw to Dw, Gw, see page 4) Transmission frequencies up to 3,000 frequencies, tuneable in steps of 25 kHz 20 frequency banks, each with up to 64 factory-preset channels 6 frequency banks, each with up to 64 user programmable channels... - Page 33 ≤ 25 µA • with switched-off plug-on transmitter Operating time typ. 7 hrs (30 mW RF, w/o P48) Dimensions approx. 105 mm x 43 mm x 43 mm Weight (incl. batteries) approx. 195 g In compliance with Europe: EN 301489-1/-9...
-
Page 34: Manufacturer Declarations
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 35 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.
-
Page 36: Index
Index connecting (microphones) accupack charging deactivating temporarily (lock inserting mode) activating/deactivating displays lock mode (Auto Lock) adjusting the contrast of the phantom powering display panel (LCD (PhantomPower 48V) Contrast) pilot tone transmission (Pilot charge status Tone) overview standard displays adjusting... - Page 37 (during multi-channel operation operation) Mute (muting the audio deactivating (offline signal) operation) Mute Mode (setting the mode for the MUTE switch) Sensitivity (adjusting the input MUTE switch sensitivity) function setting up (transmission link) setting the mode (Mute Software Revision (displaying the...
- Page 38 Sennheiser electronic GmbH & Co. KG Printed in Germany Am Labor 1, 30900 Wedemark, Germany Publ. 06/09 www.sennheiser.com 529676/A01...
