Sennheiser SR 300 IEM G3 Specifications

SR 300 IEM G3
FEATURES
Sturdy metal housing
42 MHz bandwidth: 1680 tunable UHF
frequencies for interference-free reception
Enhanced frequency bank system with up
to 16 compatible frequencies
Ethernet port for connecting to the Wire-
less Systems Manager (WSM) software for
control via computer – this delivers a good
overview of monitoring and professio-
nal data management for multi-channel
systems
Pilot tone squelch for eliminating RF inter-
ference when transmitter is turned off
Enhanced AF frequency range
Increased range for audio sensitivity
Wireless synchronization of receiver para-
meter from transmitter
User-friendly menu operation with more
control options
Illuminated graphic display
Auto-Lock function avoids accidental
changing of settings
HDX compander for crystal-clear sound
Mute function
Integrated 5-band graphic Equalizer
Wide range of accessories adapts the
system to any requirement
Optimized PLL synthesizer and micro-
processor technology
Stereo/mono selection
Easy setup of a multi-channel system
using the Easy Setup Sync function
You can only sound better if you hear yourself better. Wireless monitoring is taken
to the next level of perfection with the Sennheiser G3 monitoring system. Added
features of this stereo transmitter include the valuable integrated 5 band equali-
zer for extra control of the sound. New pass-through sockets for the audio signal
enable the audio feed from a console to be routed to other devices in the chain,
simplifying setup. The enhanced audio frequency response of 25 to 15,000 Hz
means the sound the performers hear is the most realistic and life-like a wireless
monitor system has
ever had to offer.

TECHNICAL DATA

Frequency ranges.................................................... 516 – 558, 566 – 608, 626 – 668,
Transmission frequencies ..................................... 1,680 frequencies, tuneable in steps
Switching bandwidth .............................................42 MHz
Frequency stability .................................................±10 ppm (–10 °C to +55 °C)
Antenna output.......................................................BNC socket, 50 O
RF output power at 50 O ...................................... typ. 10/30 mW (Low/Standard),
Modulation ................................................................wideband FM stereo (MPX pilot tone)
Compander system .................................................Sennheiser HDX
Nominal/peak deviation .......................................±24 kHz/±48 kHz
MPX pilot tone (frequency/deviation) ..............19 kHz/±5 kHz
AF frequency response ..........................................25 Hz to 15 kHz
AF input ..................................................................... 2 x XLR-3/¼" (6.3 mm) jack combo
Max. input level .......................................................+22 dBu
THD (at 1 kHz and nominal deviation) ..............< 0.9 %
Signal-to-noise ratio
at nominal load and peak deviation ...................> 90 dB
Wireless
stereo transmitter
734 –776, 780 – 822, 823 – 865 MHz
of 25 kHz
20 frequency banks, each with up to
16 factory-preset channels
6 frequency banks with up to 16
user programmable channels
switchable
socket, electronically balanced
Continued on page 2
