- Page 1 SKM 2000 Instruction manual...
-
Page 2: Table Of Contents
The frequency bank system ................4 Delivery includes ....................5 Product overview ....................6 Overview of the SKM 2000 radio microphone ........... 6 Overview of the displays ................7 Putting the radio microphone into operation ..........8 Inserting the batteries/accupack ..............8 Charging the accupack .................. - Page 3 • Heed all warnings and follow all instructions in this instruction manual. • Use only a cloth for cleaning the product. • Do not place the product near any heat sources such as radiators, stoves, or other devices (including amplifiers) that produce heat.
-
Page 4: The Skm 2000 Radio Microphone
• Increased immunity to intermodulation and interferences in multi- channel operation Areas of application The radio microphone can be combined with the EM 2000 and EM 2050 rack-mount receivers. The receivers are available in the same UHF frequency ranges and are equipped with the same frequency bank system with factory-preset frequencies. -
Page 5: The Frequency Bank System
Frequency bank U1 ... U6 Channel 64 – freely selectable frequency Each of the channels in the frequency banks “1” to “20” has been factory- preset to a fixed frequency (frequency preset). The factory-preset frequencies within one frequency bank are intermodulation-free. These frequencies cannot be changed. -
Page 6: Delivery Includes
Delivery includes Delivery includes The packaging contains the following items: 1 SKM 2000 radio microphone 2 AA size batteries, 1.5 V 1 microphone clamp 8 color-coded protection rings 1 pouch 1 instruction manual 1 frequency information sheet 1 RF power information sheet... -
Page 7: Product Overview
Product overview Product overview Overview of the SKM 2000 radio microphone Microphone head (interchangeable) Operation and battery status indicator, red LED: Name and pick-up pattern of the lit = microphone head flashing = LOW BATT Body of radio microphone Charging contacts... -
Page 8: Overview Of The Displays
Overview of the displays After switch-on, the radio microphone displays the “Frequency/Name” standard display. For further illustrations and examples of the different standard displays, refer to page 15. The display backlighting is auto- matically reduced after approx. 20 seconds. 543.200... -
Page 9: Putting The Radio Microphone Into Operation
When screwing the lower part of the radio microphone back to the radio microphone’s body, the muting is canceled. Slide back the lower part of the radio microphone as far as it will go. Open the battery compartment cover... -
Page 10: Charging The Accupack
Putting the radio microphone into operation Insert the batteries or the BA 2015 accupack as shown on the battery compartment cover. Observe correct polarity when inserting the batteries/accupack. Close the battery compartment cover Push the battery compartment into the radio microphone’s body. -
Page 11: Changing The Microphone Head
Putting the radio microphone into operation Changing the microphone head Unscrew the microphone head Do not touch the contacts of the radio microphone nor the contacts of the microphone head . The contacts can become dirty or damaged if touched. -
Page 12: Changing The Color-Coded Protection Ring
Protection rings in different colors are available as accessories (see “Accessories” on page 31). The protection rings allow you to clearly identify each radio microphone. Remove the color-coded protection ring as shown. Put on a new protection ring... -
Page 13: Using The Radio Microphone
The transmission link is established and the display backlighting of the receiver changes from red to orange. It is vital to observe the notes on frequency selection on page 27. If you cannot establish a transmission link between transmitter and receiver, read the chapter “Synchronizing the radio microphone with a... - Page 14 Mute” appears on the receiver’s display panel. 543.200 **2000** MUTE Use this function to save battery power or to prepare a radio microphone for use during live operation without causing interference to existing transmission links. activate signal: Briefly press the ON/OFF button.
-
Page 15: Holding The Radio Microphone Correctly
You can activate or deactivate the automatic lock mode via the “Auto Lock” menu item (see page 23). If the lock mode is activated, you have to temporarily deactivate it in order to be able to operate the radio microphone:... -
Page 16: Activating/Deactivating The Rf Signal
Using the radio microphone Activating/deactivating the RF signal Deactivating the RF signal on switch-on For information on deactivating the RF signal on switch-on, refer to the chapter “Switching the radio microphone on/off” on page 12. Deactivating the RF signal during operation... -
Page 17: Using The Operating Menu
A special feature of the Sennheiser 2000 series is the consistent, intuitive menu structure of transmitters and receivers. As a result, adjustments to the settings can be made quickly – even in stressful situations, for example on stage or during a live show or presentation. -
Page 18: Overview Of The Operating Menu
Activates/deactivates the automatic lock mode Advanced Calls up the extended menu “Advanced Menu” Exit Exits the operating menu and returns to the – current standard display Extended menu “Advanced Menu” Tune Sets the transmission frequencies for the frequency banks “U1” to “U6”... -
Page 19: Working With The Operating Menu
Using the operating menu Working with the operating menu If the lock mode is activated, you have to deactivate it In order to be able to work with the operating menu (see page 14). By way of example of the “Sensitivity” menu, this section describes how to use the operating menu. - Page 20 ON/OFF The current standard display appears on the display panel. To subsequently return to the last edited menu item: Press the multi-function switch so many times until the last edited menu item appears. Exiting a menu item Change to the “Exit” menu item.
-
Page 21: Adjusting Settings Via The Operating Menu
Adjusting settings via the operating menu Make use of the possibility to adjust settings via the operating menu of your receiver and to transfer these settings to the radio microphone. For more information, refer to the instruction manual of the receiver. - Page 22 ... too low The transmission link is undermodulated. This results in a signal with high background noise. The following figures are a guide to the best settings: Transmission situation Sensitivity setting −48 to −18 dB Loud music/vocals −18 to −12 dB...
- Page 23 Enter a character; and confirm store the setting “Stored” Via the “Name” menu item, you can enter a freely selectable name (e.g. the name of the performer) for the radio microphone. The name can be displayed on the “Frequency/Name” and “Name/ Channel”...
- Page 24 The lock mode icon on the current standard display indicates that the lock mode is activated. Move the multi-function switch to select the desired setting. For information on how to use the lock mode, refer to page 14.
-
Page 25: The Extended Menu "Advanced Menu
Via the “Tune” menu item, you can: 1. set a transmission frequency to be stored in the current channel of the frequency bank (“U1” to “U6”) select a frequency bank (“U1” to “U6”) and a channel and assign this channel a transmission frequency. - Page 26 Select the desired Store the setting “RF Power” setting “Stored” Via the “RF Power” menu item, you can adjust the transmission power in three steps (Low, Standard, High). It is vital to observe the notes on the enclosed frequency information sheet!
- Page 27 “Pilot Tone” setting “Stored” The radio microphone adds an inaudible signal, known as the pilot tone, to the transmitted signal. The receiver detects and evaluates the pilot tone. The pilot tone supports the receiver’s squelch function, thus protecting against interference due to RF signals from other devices.
-
Page 28: Synchronizing The Radio Microphone With A Receiver
Make sure that you set the radio microphone to the same frequency bank and the same channel as the receiver (see page 21). If you still cannot establish a transmission link, read the chapter “If a problem occurs ...” on page 30. -
Page 29: Cleaning The Radio Microphone
Only clean the upper sound inlet basket. Remove the foam insert. To clean the sound inlet basket: – Use a slightly damp cloth to clean the upper sound inlet basket from the inside and outside. – Scrub with a brush and rinse with clear water. -
Page 30: Recommendations And Tips
... for optimum reception • Transmission range depends to a large extent on location and can vary from about 10 m to about 150 m. There should be a “free line of sight” between transmitting and receiving antennas. • To avoid overloading the receiver, observe a minimum distance of 5 m between transmitting and receiving antennas. -
Page 31: If A Problem Occurs
If a problem occurs that is not listed in the above table or if the problem cannot be solved with the proposed solutions, please contact your local Sennheiser partner for assistance. To find a Sennheiser partner in your country, search at... -
Page 32: Accessories
Accessories Accessories The following accessories are available from your specialist dealer: Cat. No. Product name and description 004839 MZW 1 wind and pop shield 002155 MZQ 1 microphone clamp Microphone heads 502575 MMD 835-1 microphone head, dynamic, cardioid 502576 MMD 845-1 microphone head,... -
Page 33: Specifications
Modulation wideband FM Frequency ranges 516–558, 558–626, 626–698, 718–790, 790–865 MHz (Aw to Dw, Gw, see page 4) Transmission frequencies up to 3,000 frequencies, tuneable in steps of 25 kHz 20 frequency banks, each with up to 64 factory-preset channels... - Page 34 Specifications Power consumption: • at nominal voltage typ. 180 mA (30 mW) • with switched-off ≤ 25 μA radio microphone Operating time typ. 8 hrs ∅ Dimensions approx. 50 x 265 mm Weight (incl. batteries) approx. 450 g In compliance with...
-
Page 35: Manufacturer Declarations
Manufacturer Declarations Manufacturer Declarations Warranty Sennheiser electronic GmbH & Co. KG gives a warranty of 24 months on this product. For the current warranty conditions, please visit our website at www.sennheiser.com or contact your Sennheiser partner. In compliance with the following requirements •... - Page 36 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 37: Index
Index Index Accessories Displays adjusting the contrast of the dis- Accupack play panel (LCD Contrast) charging charge status inserting overview Activating/deactivating standard displays lock mode (Auto Lock) pilot tone Factory default settings (resetting Adjusting the settings in the operating input sensitivity... - Page 38 Radio microphone mode) cleaning Using switching on/off operating menu synchronizing with receiver radio microphone Reset (resetting the settings in the operating menu) RF Mute On/Off (activating/ deactivating the RF signal) RF Power (adjusting the transmission power) RF signal activating (online...
- Page 39 Sennheiser electronic GmbH & Co. KG Printed in Germany Am Labor 1, 30900 Wedemark, Germany Publ. 01/09 www.sennheiser.com 529674/A01...
