- Page 1 Power Ramp Up Setting Procedure – Solis Grid Tied Inverters V1.0 29/07/2022...
- Page 2 CONTENTS Setting Procedure for Power Ramp Up on 3 Phase Grid Tied Inverters Procedure Overview Quick Reference Guide Detailed Reference Guide...
- Page 3 100kW or more to the grid, a power ramp up of no more than 10% of the active output power is required. This would include all Solis 110kW inverters or any other combination of Solis inverters connected in parallel that are equal to or greater than 100kW of generation capacity.
- Page 4 Setting Procedure (SOP) Inverter Power Ramp Rate Setting Procedure: 03. Quick Reference Guide: 1.Enter into the inverters Advanced Settings using password 0 0 1 0 2.Scroll down and select STD. Mode Settings 3.Enter 4.Select Power Rate Limit 5.Select Power Rate: 600% 6.Use up arrow until 10% 7.Press ESC X2 8.Select Save &...
- Page 5 Setting Procedure (SOP) Inverter Power Ramp Rate Setting Procedure: 04. Detailed Reference Guide: 1. Enter into the inverters Advanced Settings and enter password 0 0 1 0 2. Scroll down and enter into menu STD. Mode Settings...
- Page 6 Setting Procedure (SOP) Inverter Power Ramp Rate Setting Procedure: 3. Enter into menu Power Rate Limit...
- Page 7 Setting Procedure (SOP) Inverter Power Ramp Rate Setting Procedure: 4. Select the menu item Power Rate: 600%...
- Page 8 Setting Procedure (SOP) Inverter Power Ramp Rate Setting Procedure: 5. Use the inverters up arrow until 10% is selected...
- Page 9 Setting Procedure (SOP) Inverter Power Ramp Rate Setting Procedure: 6. Press the inverters ESC button twice (X2) 7. Select Save & Send The inverters power ramp up settings have now been adjusted and saved. Test if the inverter slowly ramps up to full power.
- Page 10 Ningbo Ginlong Technologies Co.,Ltd NO.57 Jintong Road, Xiangshan,Ningbo, Zhejiang, THANKS China Ningbo Ginlong Technologies Co.,Ltd www.ginlong.com Solis Solis Ginlong Solis Ginlong Solis...
