Summary of Contents for Monte Carlo Fan Company 5SBR56 Series
- Page 1 Owner’s Manual Ceiling Fan Installation Instructions Total fan weight with light kit included For 5SBR56 Series Fans READ AND SAVE THESE INSTRUCTIONS Quality Ceiling fans...
-
Page 2: Installation
Installation AFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70- 1999), including fire-rated construction. - Page 3 Loosen 2 screws and remove gate. Secure mounting neck to the mount- Lift mounting neck to mounting Plate Save gate for use later. ing plate with four screws to become and align screws. a complete mounting bracket. Use 3 screws removed to attach arch Remove 3 screws on arch hub.
- Page 4 Safety cable installation Safety Cable Lag Screw safety cable washer lock 3” lag washer screw Fan and light kit combinations over 35 lbs, in both flush and downrod mode the safety Hang assembled fan from the mounting bracket cable must be installed into the house struc- installed to ceiling in previous step.
- Page 5 Lift light kit to the fan motor assembly. Align Plug white wire from fan to white Install the 2x50 watt halogen bulbs. the 3 screws with the key hole slot holes in the wire from light kit. Then plug black Do not touch bulb surface as oily light kit (see inset).
-
Page 6: Fan Speed
Remote Control Transmitter Features: FAN REVERSE LED LIGHT (Press once to change direction of MEDIUM SPEED the fan)Fanmust be running to reverse. LOW SPEED HIGH SPEED FAN OFF SETTING UPLIGHT ON/OFF SET- (Turns fan off only) TING AND DIMMER (Press and hold to dim light infinitively) DOWNLIGHT ON/OFF SETTING AND DIMMER... -
Page 7: Troubleshooting
Trouble Shooting If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet. - Page 8 REV. 1 2/4/04 Step 8 in safety tips & step 2 page 2 & battery remote...
